Garmin ECHOMAP UHD 94sv Combo GPS/Fishfinder - Preloaded US Offshore BlueChart g3 w/GT56UHD-TM
Garmin ECHOMAP UHD 94sv Combo GPS/Fishfinder - Preloaded US Offshore BlueChart g3 w/GT56UHD-TM — Product description
Imagine spending less time scanning charts and more time reeling in the big ones. The Garmin ECHOMAP UHD 94sv transforms your boating adventures with its crisp 9-inch touchscreen, delivering stunning visuals even under direct sunlight. Paired with the GT56UHD-TM transducer, it unleashes Ultra High-Definition scanning sonar that paints a crystal-clear picture of what's lurking below and beside your boat—perfect for serious anglers chasing bass in shallow bays or trolling deep offshore.
Crystal-Clear Sonar Imaging for Precision Fishing
At the heart of this combo unit is the GT56UHD-TM transducer, offering CHIRP traditional sonar alongside UHD ClearVü and SideVü scanning. With three frequencies and a 20% extended range on SideVü, you can peer deeper into structures without missing a beat. Vivid color palettes cut through clutter, making fish arches and bottom contours pop against weeds or rocks. Whether you're in freshwater lakes or salty coastal waters, this setup reveals hidden spots competitors overlook.
- Ultra High-Definition scanning for down and side views up to impressive depths.
- CHIRP sonar excels in varied conditions, from shallow flats to 2,300 ft freshwater max.
- Real-time Panoptix LiveScope compatibility (transducer sold separately) for live-action fish tracking.
Comprehensive Coastal Navigation with BlueChart g3
Preloaded with BlueChart g3 charts covering U.S. coasts, Gulf of Mexico, and Great Lakes (U.S. and Canadian sides), you'll navigate confidently from marinas to open water. Integrated Navionics data means detailed bathymetry, port plans, and smart curves—essential for avoiding hazards during low light or fog. No more fumbling with paper maps; just pinch-to-zoom and go.
Build Your Own Fishing Hotspot Maps
Quickdraw Contours lets you generate 1-foot contour maps on the fly as you explore. Save private intel on your secret honey holes or contribute to the Garmin Quickdraw Community via the app. It's like having a personal cartographer aboard, adapting maps to your exact fishing style—whether jigging wrecks or drifting edges.
Stay Connected and in Control
Networking shines here: share sonar, waypoints, and charts across compatible ECHOMAP UHD devices. NMEA 2000/0183 integration pulls in engine data, AIS targets, VHF positions, and even SteadyCast heading. Built-in Wi-Fi links to the ActiveCaptain app for OneChart swaps, software updates, and smart notifications—manage it all from your phone dockside or mid-trip.
Pair it with a FORCE trolling motor for pinpoint waypoint navigation and track following, turning your boat into a self-guided predator.
Rugged Build for Real-World Waters
IPX7 water-rated and weighing just 2.3 lbs, this unit mounts easily with quick-release bail or flush options. The 400x800 WVGA display stays readable in glare, powered efficiently at 18W. Internal GPS receiver (or external via NMEA 2000) locks 5 Hz updates for smooth tracking.
Detailed Specifications
| Category | Specification |
|---|---|
| General | |
| Physical Dimensions | 11.4" x 6.5" x 2.4" (28.2 x 16.4 x 6.0 cm) |
| Display Size | 9" diagonal (7.8" x 4.8") |
| Display Resolution | 400 x 800 pixels (WVGA) |
| Water Rating | IPX7 |
| Transmit Power | 500 W (RMS) / 4,000 W (peak to peak) |
| Maps & Memory | |
| Preloaded Maps | BlueChart g3 (U.S. coastal) |
| Waypoints / Routes / Tracks | 5,000 / 100 / 50,000 points (50 saved) |
| Sonar | |
| CHIRP Traditional | Yes (built-in) |
| ClearVü / SideVü UHD | Yes (with GT56UHD-TM) |
| Max Depth | 2,300 ft freshwater (77 kHz) |
| Connections | |
| NMEA 2000 Compatible | Yes |
| Wireless | Wi-Fi (ActiveCaptain app) |
Everything You Need Right Out of the Box
- ECHOMAP UHD 94sv with preloaded BlueChart g3
- GT56UHD-TM transducer
- Power/data cable
- Tilt mount with quick-release cradle
- Flush mount kit
- Protective cover
- Hardware and documentation
Frequently Asked Questions
Ready to elevate your fishing game? This unit delivers pro-level insights in an intuitive package, helping you find fish faster and fish smarter.
ECHOMAP UHD 94sv Combo GPS/Fishfinder - Preloaded US Offshore BlueChart g3 with GT56UHD-TM
LESS TIME FINDING. MORE TIME FISHING.
The sunlight-readable 9 touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.
Features
- See below your boat in incredible detail with the transducer bundle.
- Navigate any waters with preloaded BlueChart g3 coastal charts.
- Share data and maps with select ECHOMAP devices on your network.
- Manage your marine experience from nearly anywhere1.
- Control the most powerful trolling motor available2.Create your own maps on the fly and tailor them to fit your needs.
Sonar Support
This chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope scanning sonar system, which lets you see all around your boat in real time.
Vivid Color Palettes
High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.
Included Transducer
This chartplotter comes with a GT56 transducer for Garmin CHIRP traditional sonar and Ultra High-Definition ClearV and SideV scanning sonars. With three scanning sonar frequencies and 20% greater range for our UHD SideV sonar, you'll get top performance at all depths.
Preloaded Charts
Experience unparalleled coverage and detail with preloaded BlueChart g3 coastal charts featuring integrated Navionics data. Charts cover the coastal U.S., including the East and West coasts, Gulf of Mexico and the U.S. and Canadian sides of the Great Lakes.
Quickdraw Contours
Create personalized fishing maps on-screen with 1' contours. Keep the data to yourself, or share it with the Quickdraw Community on the Garmin Connect app3.
Network Capable
If you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, the and 9 models can share information such as sonar, user data and charts with them.
NMEA 2000 and NMEA 0183 Networks
Connect to your compatible autopilots, digital switching, weather, Fusion-Link audio system, media, VHF, AIS, engine data, heading sensors such as the SteadyCast sensor and more from one screen.
ActiveCaptain APP
Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature, smart notifications, software updates, Garmin Quickdraw Community data and more1.
FORCE Trolling Motor Compatibility
Take control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.
Connections
- Garmin Marine Network Ports: 1
- NMEA 2000 Compatible: Yes
- Transducer Pin Numbers: 12
- NMEA 0183 Input Ports: 1
- NMEA 0183 Output Ports: 1
- Video Input Ports: None
- Video Output Ports: None
- Wireless Connectivity: Yes
In The Box
- ECHOMAP UHD 94sv with BlueChart g3 for U.S.
- GT56UHD-TM transducer
- Power/data cable
- Tilt mount with quick release cradle
- Flush mount
- Protective cover
- Hardware
- Documentation
1 Requires the ActiveCaptain app on your compatible smartphone paired to the ECHOMAP UHD 94sv
2 In compliance with ISO standard 13342
3 Requires app on your compatible smartphone
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
Garmin ECHOMAP™ UHD 94sv With GT56UHD-TM Transducer with preloaded Bluechart g3
Model: 010-02524-01- See below and around your boat in incredible detail with the transducer bundle.
- Navigate any waters with preloaded BlueChart® g3 coastal charts.
- Share data and maps with select ECHOMAP devices on your network.
- Manage your marine experience from nearly anywhere.
- Control the most powerful trolling motor available.
- Create your own maps on the fly and tailor them to fit your needs.
The sunlight-readable 9" touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.
This chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.
High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.
Transducer bundle with GT56 transducer for Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü and SideVü scanning sonars. With three scanning sonar frequencies and 20% greater range for our UHD SideVü sonar, you’ll get top performance at all depths.
Experience unparalleled coverage and detail with preloaded BlueChart® g3 coastal charts featuring integrated Navionics® data. Charts cover the coastal U.S., including the East and West coasts, Gulf of Mexico and the U.S. and Canadian sides of the Great Lakes.
Create personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on the Garmin Connect™ app3.
If you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, the 7" and 9" models can share information — such as sonar, user data and charts — with them.
Connect to your compatible autopilots, digital switching, weather, Fusion-Link™ audio system, media, VHF, AIS, engine data, heading sensors — such as the SteadyCast™ sensor — and more from one screen.
Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Garmin Quickdraw™ Community data and more1.
Take control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.
Specifications| General | |
| PHYSICAL DIMENSIONS | 11.4" x 6.5" x 2.4" (28.2 x 16.4 x 6.0 cm) |
| DISPLAY SIZE | 7.8" x 4.8"; 9" diagonal (19.9 x 11.3 cm; 22.9 cm diagonal) |
| DISPLAY RESOLUTION | 400 x 800 pixels |
| DISPLAY TYPE | WVGA display |
| WEIGHT | 2.3 lbs (1.0 kg) |
| WATER RATING | IPX7 |
| POWER CONSUMPTION | 18W |
| ANTENNA | Internal or external over NMEA 2000 |
| MOUNTING OPTIONS | Bail or flush |
| RECEIVER | 5 Hz |
| GARMIN MARINE NETWORK™ PORTS | 1 Panoptix™ port |
| TRANSMIT POWER | 500 W (RMS) / 4,000 W (peak to peak) |
| Maps & Memory | |
| PRELOADED MAPS | BlueChart® g3 (coastal maps) |
| ACCEPTS DATA CARDS | 1 microSD™ card; 32 GB maximum size |
| WAYPOINTS | 5,000 |
| TRACK LOG | 50,000 points; 50 saved tracks |
| ROUTES | 100 |
| Outdoor Recreation | |
| TIDE TABLES | Yes |
| Chartplotter Features | |
| GARMIN SONAR COMPATIBLE | Yes |
| SUPPORTS AIS (TRACKS TARGET SHIPS POSITION) | Yes |
| SUPPORTS DSC (DISPLAYS POSITION DATA FROM DSC-CAPABLE VHF RADIO) | Yes |
| GCV™ BLACK BOX SONAR SUPPORT | Yes |
| ACTIVECAPTAIN COMPATIBLE | Yes |
| ACTIVECAPTAIN COMPATIBLE | Yes |
| Sonar Features & Specifications | |
| DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE | Yes |
| DUAL-BEAM (77/200 KHZ) SONAR CAPABLE | Yes |
| CHIRP SONAR TECHNOLOGY | Yes (Built-in) |
| CLEARVü | Yes with CHIRP (built-in) |
| SIDEVü | Yes with CHIRP (built-in) |
| MAXIMUM DEPTH | 2,300 ft @ 77 kHz, freshwater 1,100 ft @ 77 kHz, saltwater (depth capacity is dependent on water bottom type and other water conditions) |
| BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) | Yes |
| WATER TEMPERATURE LOG AND GRAPH | Yes |
| SONAR RECORDING | Yes |
| SONAR HISTORY REWIND | Yes |
| Connections | |
| NMEA 2000® COMPATIBLE | Yes |
| TRANSDUCER PIN NUMBERS | 12 |
| NMEA 0183 INPUT PORTS | 1 |
| NMEA 0183 OUTPUT PORTS | 1 |
| VIDEO INPUT PORTS | None |
| VIDEO OUTPUT PORTS | None |
| WIRELESS CONNECTIVITY | Yes |
What's in the Box:
- ECHOMAP UHD 94sv with BlueChart g3 for U.S.
- GT56-TM transducer
- Power/data cable
- Tilt/swivel mount with quick release cradle
- Flush mount
- Protective cover
- Hardware
- Documentation
SKU: NVN-86501
MPN: 010-02524-01
UPC: 753759264475
