Garmin ECHOMAP Ultra 102sv w/o Transducer
Garmin ECHOMAP Ultra 102sv w/o Transducer — Product description
Discover the power of precision fishing with the Garmin ECHOMAP Ultra 102sv, a versatile 10-inch chartplotter designed for serious anglers who demand clarity on the water. This unit stands out with its keyed-assist touchscreen that's responsive even under direct sunlight, delivering crisp visuals for spotting fish and navigating confidently. Without a transducer included, it gives you the flexibility to pair it with your preferred sonar setup, making it ideal for customizing to your boat or fishing style.
Unlock Real-Time Insights with Advanced Sonar Integration
At the heart of the ECHOMAP Ultra 102sv lies support for Garmin's top-tier sonar technologies. Dive into the forward-facing views of Panoptix LiveScope, which reveals fish movements as they happen—no black box needed. Pair it with CHIRP traditional sonar for deep-water scans, or ClearVü and SideVü for detailed images beneath and beside your boat. Anglers love how Ultra High-Definition scanning sonar cuts through clutter, helping you pinpoint structure and baitfish schools with unmatched detail. Whether trolling offshore or finesse fishing in shallows, these tools transform guesswork into targeted strikes.
Create Your Personal Fishing Maps On the Fly
Quickdraw Contours is a game-changer for mapping uncharted waters. As you motor across a lake or river, the software generates 1-foot contour maps in real-time, capturing depth changes, hotspots, and hidden contours. Save these private maps for your eyes only, or contribute to the Garmin Quickdraw Community to benefit fellow anglers. Imagine returning to that legendary weed edge or drop-off you've dialed in over multiple trips—it's like having a custom lake chart that evolves with your experience.
Stay Connected Across Your Vessel
Networking keeps your boat's systems in sync. Share live sonar data, waypoints, and routes effortlessly with other ECHOMAP Ultra 10" or 12" units, or even ECHOMAP Plus 7" and 9" models via the Garmin Marine Network. NMEA 2000 compatibility opens doors to heading sensors for stable charts, autopilots for hands-free navigation, digital switching, and FUSION-Link audio to pump your favorite tunes. It's perfect for multi-station setups on larger boats, ensuring everyone sees the same critical info.
Built Tough for Everyday Adventures
Crafted with an IPX7 water rating, this unit shrugs off splashes and rain, while polarized lens support reduces glare for better visibility. The 1280 x 800 WXGA display shines in harsh conditions, and at just 4 lbs, it's manageable for most consoles. Power draw stays efficient at 26W, and the internal GPS/GLONASS receiver updates at 10Hz for smooth tracking. Bail or flush mounting options fit any setup, with a quick-release cradle for secure removal when trailering.
Expand Your Navigation Arsenal
Start with the preloaded worldwide basemap, then level up to BlueChart g3 or g3 Vision charts infused with Navionics data. Auto Guidance+ plots safe routes factoring in your boat's draft and clearance, displaying a visual path to waypoints. Tide tables, AIS support for collision avoidance, and DSC integration for VHF radio keep you safe and informed. Dual microSD slots handle custom maps or software updates seamlessly.
Command Your Boat from Your Phone
Built-in Wi-Fi links to the ActiveCaptain app, turning your smartphone into a boating hub. Plan routes onshore, sync Quickdraw maps, receive smart notifications, and browse community insights—all without being at the helm. Software updates push automatically, keeping your unit cutting-edge. It's like having a digital first mate that anticipates your needs.
Key Specifications at a Glance
| Feature | Details |
|---|---|
| Physical Dimensions | 11.6" x 7.7" x 3.9" (295 x 195 x 98 mm) |
| Display | 10" diagonal WXGA (1280 x 800 pixels) |
| Weight | 4.0 lbs (1.8 kg) |
| Transmit Power | 500W RMS / 4,000W peak-to-peak |
| Max Depth | 2,300 ft freshwater (77 kHz) |
| Connections | 2 Garmin Marine Network, 1 NMEA 2000, Wi-Fi |
Included Components
- ECHOMAP Ultra 102sv with worldwide basemap
- Power/data cable
- Tilt mount with quick-release cradle
- Flush mount kit
- Protective cover
- Hardware
- Documentation
- 8-pin to 12-pin transducer adapter cable
Frequently Asked Questions
Does the Garmin ECHOMAP Ultra 102sv include a transducer?
No, this model ships without a transducer, allowing you to select the best one for your fishing environment, such as GT52 or a LiveScope LVS12.
What sonar technologies are compatible with this unit?
It supports CHIRP traditional, ClearVü, SideVü scanning sonars, Ultra High-Definition scanning, and the full Panoptix lineup including LiveScope systems.
Can I share data between multiple ECHOMAP units?
Yes, share sonar, waypoints, and routes with other ECHOMAP Ultra 10"/12" or ECHOMAP Plus 7"/9" units over the Garmin Marine Network.
How does Quickdraw Contours work?
It creates personalized 1-foot contour maps in real-time as you fish, which you can save privately or share via the Quickdraw Community.
Is this chartplotter waterproof?
Yes, it has an IPX7 rating, capable of withstanding immersion in one meter of water for up to 30 minutes.
What charts can I use?
Preloaded worldwide basemap, with upgrades to BlueChart g3 or g3 Vision featuring Navionics data and Auto Guidance+.
Does it connect to the ActiveCaptain app?
Absolutely, via built-in Wi-Fi for trip planning, map syncing, notifications, and community access.
Equip your boat with the ECHOMAP Ultra 102sv and elevate every outing— from locating trophy bass in cover to charting safe paths through unfamiliar bays. It's the reliable partner that grows with your passion for the water.
ECHOMAP Ultra 102sv without Transducer
Built-in Support for Our Premium Sonar Capabilities
- 10 keyed-assist touchscreen combo with all the built-in tools you need to find and catch fish
- Built-in support for our premium sonars, including the Panoptix LiveScope scanning sonar system and Panoptix LiveScope LVS12 sonar
- Share sonar, waypoints and routes with other ECHOMAP Ultra 10 and 12 units as well as ECHOMAP Plus and 9 units
- Built-in Quickdraw Contours mapping software instantly creates personalized fishing maps on-screen with 1' contours as you fish
- Built-in Wi-Fi connectivity pairs with the free ActiveCaptain app
- NMEA 2000 connectivity and support for heading sensors, autopilots, digital switching, FUSION-Link audio system and more
The ECHOMAP Ultra 102sv combo, with its bright, sunlight-readable 10 keyed-assist touchscreen display, has all the tools you need for successful fishing. It includes built-in support for our premium Garmin sonar and optional premium BlueChart g3 charts and BlueChart g3 Vision cartography with integrated data from Navionics. All transducers are sold separately.
Our Premium Sonar Support
The ECHOMAP Ultra 102sv combo includes built-in support for optional traditional CHIRP, CHIRP ClearV and CHIRP SideV scanning sonars, Ultra High-Definition scanning sonar and Panoptix LiveScope LVS12 sonar (no black boxes required) plus the full line of Panoptix all-seeing sonar transducers. It also supports the Panoptix LiveScope system.
Share Sonar, Waypoints and Routes
Have more than one unit? You can share sonar, waypoints and routes with other ECHOMAP Ultra 10 and 12 units as well as ECHOMAP Plus and 9 units.
Quickdraw Contours to Create Your Own Maps
Instantly create personalized fishing maps on-screen with 1' contours as you fish. Tailor them to fit your needs. These are your maps you own them. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect, our online community.
Upgrade to the Best Maps on the Water
Upgrade the preloaded worldwide basemap to optional premium BlueChart g3 charts or BlueChart g3 Vision cartography with integrated data from Navionics, which add Auto Guidance technology that uses your desired depth and overhead clearance to easily calculate routes and see a suggested path to follow.
The Ultimate Connected Boating App
Built in Wi-Fi gives you access to the free all-in-one ActiveCaptain app, so you can manage your marine experience from nearly anywhere. It creates a simple yet powerful connection between your compatible mobile device and your Garmin chartplotter, charts, maps and the boating community. Wherever you are, you'll have unlimited access to your cartography, the ability to purchase new maps and charts and access to the Garmin Quickdraw Contours Community. Stay connected with smart notifications on your chartplotter screen. You can also plan a trip or prefish a lake, and ActiveCaptain will automatically sync with your chartplotter. Even get notifications for software updates, and decide when to download them on your device.
Take Your ECHOMAP Ultra with You
When you're off the water, it's easy to keep your ECHOMAP Ultra combo safe and secure. You don't have to mess with plugging and unplugging wires from the unit, because the cords plug directly into the quick-disconnect bail mount. This allows you to quickly install and remove your ECHOMAP Ultra from power and the mount.
In The Box
- ECHOMAP Ultra 102sv with worldwide basemap
- Power/data cable
- Tilt mount with quick release cradle
- 8-pin transducer to 12-pin sounder adapter cable
- Flush mount
- Protective cover
- Hardware
- Documentation
Connections
- Garmin Marine Network Ports: 2 (large connector)
- Transducer Ports: 1 (12 Pin)
- NMEA 2000 Port: 1
- NMEA 0183 Input Ports: 1
- NMEA 0183 Output Ports: 1
- Wireless Connectivity: Yes
Auto Guidance is for planning purposes only and does not replace safe navigation operations
When paired with a compatible smartphone; see Garmin.com/ble
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
Garmin ECHOMAP™ Ultra 102sv Without Transducer
Model: 010-02111-00- 10" keyed-assist touchscreen combo with all the built-in tools you need to find and catch fish
- Built-in support for our premium sonars, including the Panoptix LiveScope™ scanning sonar system and Panoptix LiveScope LVS12 sonar
- Share sonar, waypoints and routes with other ECHOMAP Ultra 10" and 12" units as well as ECHOMAP Plus 7" and 9" units
- Built-in Quickdraw Contours mapping software instantly creates personalized fishing maps on-screen with 1’ contours as you fish
- Built-in Wi-Fi® connectivity pairs with the free ActiveCaptain® app
- NMEA 2000® connectivity and support for heading sensors, autopilots, digital switching, weather, FUSION-Link™ audio system and more
The ECHOMAP Ultra 102sv combo, with its bright, sunlight-readable 10" keyed-assist touchscreen display, has all the tools you need for successful fishing. It includes built-in support for our premium Garmin sonar and optional premium BlueChart® g3 charts and BlueChart g3 Vision cartography with integrated data from Navionics®. All transducers are sold separately.
The ECHOMAP Ultra 102sv combo includes built-in support for optional traditional CHIRP, CHIRP ClearVü and CHIRP SideVü scanning sonars, Ultra High-Definition scanning sonar and Panoptix LiveScope LVS12 sonar (no black boxes required) plus the full line of Panoptix™ all-seeing sonar transducers. It also supports the Panoptix LiveScope system.
Have more than one unit? You can share sonar, waypoints and routes with other ECHOMAP Ultra 10" and 12" units as well as ECHOMAP Plus 7" and 9" units.
Have more than one unit? You can share sonar, waypoints and routes with other ECHOMAP Ultra 10" and 12" units as well as ECHOMAP Plus 7" and 9" units.
Upgrade the preloaded worldwide basemap to optional premium BlueChart g3 charts or BlueChart g3 Vision cartography with integrated data from Navionics, which add Auto Guidance technology that uses your desired depth and overhead clearance to easily calculate routes and see a suggested path to follow.
Built in Wi-Fi gives you access to the free all-in-one ActiveCaptain app, so you can manage your marine experience from nearly anywhere. It creates a simple yet powerful connection between your compatible mobile device and your Garmin chartplotter, charts, maps and the boating community. Wherever you are, you’ll have unlimited access to your cartography, the ability to purchase new maps and charts and access to the Garmin Quickdraw™ Contours Community. Stay connected with smart notifications on your chartplotter screen. You can also plan a trip or prefish a lake, and ActiveCaptain will automatically sync with your chartplotter. Even get notifications for software updates, and decide when to download them on your device.
When you’re off the water, it’s easy to keep your ECHOMAP Ultra combo safe and secure. You don’t have to mess with plugging and unplugging wires from the unit, because the cords plug directly into the quick-disconnect bail mount. This allows you to quickly install and remove your ECHOMAP Ultra from power and the mount.
Specifications| General | |
| Physical dimensions | 11.6" x 7.7" x 3.9" (295 x 195 x 98 mm) |
| Display size | 8.5" x 5.4"; 10" diagonal (21.7 cm x 13.6 cm; 25.4 cm diagonal) |
| Display resolution | 1280 x 800 pixels |
| Display type | WXGA display |
| Weight | 4.0 lbs (1.8 kg) |
| Water rating | IPX7 |
| Polarized Support | Yes |
| Power consumption | 26 W |
| Antenna | Internal only |
| Mounting options | Bail or flush |
| Receiver | 10 Hz |
| Garmin Marine Network™ ports | 2 (large connector) |
| Maps & Memory | |
| Accepts data cards | 2 microSD™ cards |
| Waypoints | 5,000 |
| Routes | 100 |
| Track log | 50,000 points; 50 saved tracks |
| Outdoor Recreation Features | |
| Tide tables | Yes |
| Chartplotter Features | |
| Garmin Sonar compatible | Yes |
| Supports AIS (tracks target ships position) | Yes |
| Supports DSC (displays position data from DSC-capable VHF radio) | Yes |
| Supports FUSION-Link™ compatible radios | Yes |
| GCV™ Black Box sonar support | Yes |
| ActiveCaptain compatible | Yes |
| Sailing Features | Yes |
| Sonar Features & Specifications | |
| Dual-frequency (50/200 kHz) sonar capable | Yes |
| Dual-beam (77/200 kHz) sonar capable | Yes |
| Transmit power | 500 W (RMS) / 4,000 W (peak to peak) |
| CHIRP sonar technology | Yes (Built-in) |
| ClearVü | Yes |
| SideVü | Yes |
| Maximum depth | 2,300 ft @ 77 kHz, freshwater 1,100 ft @ 77 kHz, saltwater (depth capacity is dependent on water bottom type and other water conditions) |
| Bottom lock (shows return from the bottom up) | Yes |
| Water temperature log and graph | Yes |
| Sonar recording | Yes |
| Sonar history rewind | Yes |
| Connections | |
| NMEA 2000® compatible | Yes |
| Transducer pin numbers | 12 |
| NMEA 0183 input ports | 1 |
| NMEA 0183 output ports | 1 |
| Wireless connectivity | Yes |
What's in the Box:
- ECHOMAP Ultra 102sv with worldwide basemap
- Power/data cable
- Tilt mount with quick release cradle
- Flush mount
- Protective cover
- Hardware
- Documentation
- 8-pin transducer to 12-pin sounder adapter cable
GARMIN EchoMap Ultra 102sv global basemap sensorless is brand new. The GARMIN EchoMap Ultra 102sv global basemap sensorless ECHOMAP Ultra 102sv combination has a bright, direct sunlight 10-inch button-assisted touch screen, providing all the tools needed for successful fishing. It includes built-in support for our premium Garmin sonar. And optional advanced BlueChart g3 chart and BlueChart g3 Vision charting, and integrated data from Navionics.
SKU: NVN-77767
MPN: 010-02111-00
UPC: 753759212872
Technical specifications
| Brand | Garmin |
| Model | Garmin ECHOMAP Ultra 102sv w/o Transducer |
| SKU / MFR# | 77767 |
