Garmin ECHOMAP UHD 64cv US Offshore g3 w/o Tranducer

SKU: 83252 - UPC: 753759241889 - MPN: 010-02331-00
$340.89 $549.99 ( / )

We are sorry, this product sold out!

ECHOMAP UHD 64cv US Offshore g3 without TranducerJOIN THE CLUB. FIND MORE FISH.The sunlight-readable 6 touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.Features: See below your boat in incredible detail with optional transducer  Navigate any waters with preloaded...
Garmin
Same Day

Shipping (3PM)

Free Returns

Within 30 days

Garmin ECHOMAP UHD 64cv US Offshore g3 w/o Tranducer Product Description


ECHOMAP UHD 64cv US Offshore g3 without Tranducer

JOIN THE CLUB. FIND MORE FISH.

The sunlight-readable 6 touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.

Features:

  • See below your boat in incredible detail with optional transducer
  • Navigate any waters with preloaded BlueChart g3 coastal charts
  • Manage your marine experience from nearly anywhere
  • Create your own maps on the fly and tailor them to fit your needs

INCLUDED TRANSDUCER

This chartplotter comes with a GT24 transducer for Ultra High-Definition ClearV scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.

PRELOADED MAPPING

Experience unparalleled coverage and detail with preloaded LakeV g3 inland maps featuring integrated Navionics data that covers more than 17,000 lakes with up to 1' contours.

QUICKDRAW CONTOURS

Create personalized fishing maps on-screen with 1' contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect.

NMEA 2000 AND NMEA 0183 NETWORKS

Connect to autopilots, digital switching, weather, FUSION-Link audio system, media, VHF, AIS and more from one screen.

ACTIVECAPTAIN APP

Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature, smart notifications1, software updates, Garmin Quickdraw Community data and more.

In The Box

  • ECHOMAP UHD 64cv with BlueChart g3 for U.S.
  • Power/data cable
  • Tilt/swivel mount with quick release cradle
  • Flush mount
  • Protective cover
  • Hardware
  • Documentation

1 When paired with a compatible smartphone

2 In compliance with ISO standard 13342

Wi-Fi is a registered trademark of the Wi-Fi Alliance.

Garmin ECHOMAP 64cv UHD Combo US Offshore g3, No transducer

Model: 010-02331-00
  • See below your boat in incredible detail with optional transducer
  • Navigate any waters with preloaded BlueChart® g3 coastal charts
  • Manage your marine experience from nearly anywhere
  • Create your own maps on the fly and tailor them to fit your needs

The sunlight-readable 6" touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.

This chartplotter comes with a GT24 transducer for Ultra High-Definition ClearVü scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.

Experience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours.

Create personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™.

Connect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.

Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more.

Specifications
General
Physical dimensions 8.6" x 5.1" x 2.6" (21.8 x 13.0 x 6.2cm)
Display size 5.4" x 3.1"; 6.2" diagonal (13.7 x 7.7 cm; 15.2 cm diagonal)
Display resolution 480 x 800 pixels
Display type WVGA display
Weight 1.6 lbs (0.7 kg)
Water Rating IPX7
Power consumption 12W
Antenna Internal or external over NMEA 2000
Mounting options Bail or flush
Receiver 5 Hz
Garmin Marine Network™ ports None
Maps & Memory
Preloaded maps BlueChart® g3 (coastal maps)
Accepts data cards 1 microSD™ card; 32 GB maximum size
Waypoints 5,000
Routes 100
Track log 50,000 points; 50 saved tracks
Outdoor Recreation Features
Tide tables Yes
Chartplotter Features Yes
Garmin Sonar compatible
Supports AIS (tracks target ships position) Yes
Supports DSC (displays position data from DSC-capable VHF radio) Yes
ActiveCaptain compatible Yes
Sailing Features Yes
Sonar Features & Specifications
Dual-frequency (50/200 kHz) sonar capable Yes
Dual-beam (77/200 kHz) sonar capable Yes
Transmit power 500 W (RMS) / 4,000 W (peak to peak)
CHIRP sonar technology Yes (Built-in)
ClearVü Yes with CHIRP (built-in)
SideVü No
Maximum depth 2,300 ft @ 77 kHz, freshwater
Bottom lock (shows return from the bottom up) Yes
Water temperature log and graph Yes
Sonar recording Yes
Sonar history rewind Yes
Connections
NMEA 2000® compatible Yes
Transducer pin numbers 4
NMEA 0183 input ports 1
NMEA 0183 output ports 1
Video input ports None
Video output ports None
Wireless connectivity Yes

What's in the Box:
  • ECHOMAP UHD 64cv with BlueChart g3 for U.S.
  • Power/data cable
  • Tilt/swivel mount with quick release cradle
  • Flush mount
  • Protective cover
  • Hardware
  • Documentation




Frequently Asked Questions (FAQ) About Garmin ECHOMAP UHD 64cv US Offshore g3 w/o Tranducer

Who is the Garmin?

Who is the Garmin?

Garmin is a leader in Global Positioning System (GPS) technology and an innovator in consumer electronics. Garmin serves both the aviation and consumer markets. Garmin's products are used in flying, boating, driving, hiking, and many other activities. Specifically, Garmin aims to enrich the lives of customers, suppliers, distributors, and employees by providing the very best products that offer superior quality, safety, and operational features at affordable prices.


Save $209 when you buy the Garmin ECHOMAP UHD 64cv US Offshore g3 w/o Tranducer for only $340 from NVN Marine! Same day shipping before 3pm.

Garmin ECHOMAP UHD 64cv US Offshore g3 w/o Tranducer Technical Specifications

Type:

Marine Navigation & Instruments | GPS - Fishfinder Combos

Vendor:

Garmin

Weight:

4.7 lb

Transducer Included:

No

Touchscreen:

No

Screen Size:

6"

Included Transducer:

n/a

Cartography Brand:

Garmin

Categories v2:

Marine Navigation & Instruments | GPS - Fishfinder Combos

Category v1:

GPS FISHFINDER COMBO

UPC:

753759241889

Product Manual:

Download PDF

Product Installation:

Download PDF
