Lewmar V1 Vertical Windlass W/Gypsy F/5/16 Chain 9/16 Li

Lewmar V1 Vertical Windlass W/Gypsy F/5/16 Chain 9/16 Li Product Description

The V Series represents the pinnacle of Lewmar's windlass development. Robust stainless steel deck units combined with powerful motors, the V Series is capable of withstanding the toughest conditions. Designed as the ideal anchoring companion for all serious boaters, the V Series windlasses are strong, beautiful and dependable.

Lewmar 1011108138 Attributes

• Mount Type: Vertical
• Maximum Pull: 1653 Pound
• Working Load Limit: 414 Pound
• Maximum Line Speed: 105 Feet Per Minute
• Size: 8-3/4 Inch Width X 6-5/8 Inch Height
• Chain/ Rope Size: 002 To 10 Millimeter DIN 766/ Campbell 3/8 Inch S4/ 5/16 Inch G40 Chain
• Material: Stainless Steel
• Ampere Rating: 80 Amp
• Voltage Rating: 12 Volt
• Motor Power: 700 Watt

Lewmar 1011108138 Features & Benefits

• Rope-Chain Gypsy
• Cone Clutch For Smooth, Easy Control
• Optional Manual Override Motor Gearbox
• W.A.R.P Drum
• Fall Safe Anchor Lock
• Worm Gearbox
• Limited 3 Year Warranty

Lewmar 1011108138 Warranties

• Limited Warranty and Key Terms of supply by Lewmar INC.pdf

For Boats 8 to 12m (28 to 40ft)
The world's first compact vertical stainless steel windlass for both power and sailboats. This beautifully styled deck unit conce conceals a robust, reliable, worm gearbox and offers maximum strength and control. plus, you can employ rope-chain or all-chain anchor rodes with the touch of a button.

This model is for use with 5/16" G4 chain and 9/16" line.  Order model 6671011107-138 V1, if you use 1/4" G4 chain and 1/2 " line

Kit includes: complete windlass, rocker switch, dual-direction contactor, circuit breaker and handle

Features

Rope-chain gypsy
Manual override & chain release
Stylish Stainless Steel deck unit
Cone clutch for smooth, easy control
Drive Train- robust & reliable
FastFit for quicker installation and less hassle
CE approved

FastFit Assembly
Lewmar's NEW super-compact V1 windlass is FastFit equipped. Fastfit ensures quick, hassle-free installation and proper drive shaft alignment. and splined shaft for maximum strength and control. Rope-chain or all-chain anchor rodes may be employed at the touch of a button, whilst the fully machined, low profile gypsy will keep your ropes in beautiful condition for years to come.


For boats from 8 to 12m to 28 to 40ft, the world's first compact vertical stainless steel windlass for power and sailing. This exquisitely shaped deck unit concession device hides a strong and reliable worm gear box and provides maximum strength and control capabilities. In addition, you can use rope chains or full-chain anchor rods at the push of a button. This model is suitable for 5/16 inch g4 chain and 9/16 inch wire. Order model number 6671011107-138 v1, if you use 1/4 inch g4 chain and 1/2 wire kit, it includes: complete winch, rocker switch, two-way contactor, circuit breaker and handle features wire chain Gypsy manual control and Chain release stylish stainless steel deck device conical clutch can achieve a smooth, easy-to-control drive train-firm and reliable quick assembly, can speed up the installation speed, reduce the hassle of quick assembly approved lewmar's new ultra-compact v1 windlass equipped with quick assembly function . Fastfit ensures quick and easy installation and correct drive shaft alignment. The spline shaft has the greatest strength and control. You can use rope chains or full-chain anchors at the push of a button, and the fully machined low-profile gypsy will keep your rope in a beautiful state for years to come.

Suitable for ships from 8 to 12m to 28 to 40ft, this is the world's first compact vertical stainless steel windlass for power and sailing. This exquisite deck unit concession equipment hides a strong and reliable worm gear box and provides maximum strength and control capabilities. In addition, you can use rope chains or full chain anchors with the push of a button. This model is suitable for 5/16 inch g4 chain and 9/16 inch metal wire. Order number 6671011107-138 v1, if using 1/4 inch g4 chain and 1/2 wire kit, it includes: complete winch, rocker switch, two-way contactor, circuit breaker and handle function wire chain gypsy manual control and The chain release stylish stainless steel deck device cone clutch can realize a smooth, easy-to-control transmission system, firm and reliable fast assembly, which can speed up the installation speed and reduce the trouble of fast assembly. Quick assembly function. Fastfit ensures quick and easy installation and correct drive shaft alignment. The spline shaft has the greatest strength and control. You can use a rope chain or a full chain anchor with the push of a button. The fully processed low gypsy will keep your rope in a beautiful state for years to come.
