Minn Kota Talon Tilt Bracket f/8', 10' & 12' Three-Stage Talons Product Description

Minn Kota Talon Tilt Bracket - Marine Shallow Water Anchor Accessory (1810222)

Essential Low-Clearance Solution for Talon Shallow Water Anchor Systems

Navigate low bridges, shallow passages, and boat storage challenges with confidence using the Minn Kota Talon Tilt Bracket. This marine-grade aluminum accessory provides easy-tilt action for your Talon shallow water anchor, delivering the clearance you need while maintaining the stability and strength required for marine environments.

Professional Marine Construction for Demanding Conditions

Engineered from marine-grade anodized aluminum with stainless steel hardware, this tilt bracket withstands the harsh marine environment while providing reliable operation season after season. The silver anodized finish resists corrosion and maintains its appearance in saltwater and freshwater applications.

Construction Specifications:

• Material: Marine-grade anodized aluminum construction
• Finish: Silver anodized for corrosion resistance
• Hardware: Stainless steel fasteners and components
• Mounting Location: Transom mount with 6" setback clearance
• Weight: 7.1 lbs for stable mounting
• Dimensions: 4"H x 8"W x 21"L (shipping box)

Easy-Tilt Action for Maximum Versatility

The innovative tilt mechanism allows you to quickly adjust your Talon anchor for various clearance situations, from navigating under low bridges to storing your boat in covered areas. The adjustable deck support provides stability during tilting operations, ensuring safe and controlled movement.

Key Operating Features:

• Easy-tilt action for low clearance navigation
• Adjustable deck support for stability during tilting
• Talon crutch support included for secure positioning
• Designed for temporary clearance adjustments
• Smooth operation in all weather conditions

Universal Talon Compatibility

Compatible with all Minn Kota Talon three-stage shallow water anchor models including 8', 10', and 12' lengths. This universal design ensures your investment works with current and future Talon anchor upgrades.

Compatibility Specifications:

• Compatible Models: All three-stage Talon shallow water anchors (2013-Present)
• Anchor Lengths: 8-foot, 10-foot, and 12-foot models
• Mounting Requirement: Requires Talon Adapter Bracket (not included)
• Installation Type: Not compatible with direct hull-mounted Talons

Important Installation and Usage Guidelines

Professional installation ensures optimal performance and safety. This tilt bracket requires a Talon Adapter Bracket for proper installation and is specifically designed for temporary clearance adjustments, not continuous transport operations.

Installation Requirements:

• Adapter Bracket Required: Must use Talon Adapter Bracket (sold separately)
• Mounting Type: Transom mount installation only
• Clearance: Provides 6" setback from transom
• Professional Installation: Recommended for optimal performance
• Not for Direct Hull Mount: Incompatible with direct hull-mounted Talon systems

Usage Limitations and Safety Guidelines

This tilt bracket is engineered for temporary clearance situations and boat storage. Understanding proper usage ensures safe operation and extends the life of your Talon anchor system.

Usage Guidelines:

• Temporary Clearance Only: Designed for low bridges, shallow areas, and storage
• Not for Transport: Not intended for use during trailering or on-water transport
• Storage Application: Ideal for boat storage in covered areas
• Clearance Navigation: Perfect for navigating under low bridges and obstacles
• Safety Operation: Follow all manufacturer guidelines for safe tilting procedures

Complete Hardware Package Included

Everything needed for professional installation is included in the package, from the main bracket components to specialized hardware and support accessories.

What's Included:

• Talon Tilt Bracket Assembly
• Deck Support Pivot and Support Leg
• Leg Tip Support
• Talon Crutch Support
• Complete Stainless Steel Hardware Kit
• Installation Instructions and Documentation

Professional Installation Support

Comprehensive installation documentation ensures proper setup and safe operation. Professional marine electronics installation is recommended to ensure compatibility with your specific Talon anchor configuration and boat setup.

Installation Support:

• Detailed installation instructions included
• Technical documentation available online
• Professional installation recommended
• Compatibility verification with existing Talon system
• Safety guidelines for proper operation

Enhanced Boating Flexibility

The Talon Tilt Bracket transforms your shallow water anchor system into a more versatile tool, allowing you to access previously challenging areas while maintaining the superior anchoring power of your Talon system.

Applications:

• Low bridge navigation on inland waterways
• Shallow water passage clearance
• Boat storage in covered facilities
• Marina navigation with height restrictions
• Temporary anchor positioning adjustments

Warranty and Support

• Limited 5-Year Manufacturer Warranty
• Comprehensive installation documentation
• Technical support for installation questions
• Minn Kota authorized dealer network support

Frequently Asked Questions

Q: Do I need an adapter bracket to install the Talon Tilt Bracket?

A: Yes, the Talon Tilt Bracket requires a Talon Adapter Bracket for proper installation. It cannot be used with Talon anchors that are directly mounted to the hull of the boat.

Q: Can I use this tilt bracket while trailering my boat?

A: No, this tilt bracket is designed for temporary clearance only and is not intended for transport operations, whether on water or while trailering. It should be used only for navigating low clearance areas and boat storage.

Q: What Talon anchor models are compatible with this tilt bracket?

A: This tilt bracket is compatible with all three-stage Minn Kota Talon shallow water anchors, including 8', 10', and 12' models manufactured from 2013 to present.

Q: How much additional clearance does the tilt bracket provide?

A: The tilt bracket allows you to adjust your Talon anchor position for temporary clearance needs. The exact clearance will depend on your specific installation and tilting position, but it provides sufficient adjustment for most low bridge and storage situations.

Q: Is professional installation required for the Talon Tilt Bracket?

A: While not strictly required, professional installation is recommended to ensure proper setup, compatibility verification with your existing Talon system, and safe operation. The installation requires mechanical knowledge and proper tools.

Q: Will the tilt bracket affect the performance of my Talon anchor?

A: When properly installed and used according to manufacturer guidelines, the tilt bracket does not affect the anchoring performance of your Talon system. It should only be used in the tilted position for clearance purposes, not for anchoring operations.

Easy-tilt action accommodates for low clearance areas and boat storage. Marine-grade, anodized aluminum construction for strength and durability. Adjustable deck support provides stability while tilting. Requires use of a Talon Adapter Bracket - not intended for use with Talon direct-mounted to hull of boat. Designed for temporary clearance - not intended for transport (on water or trailering). Stainless steel hardware and Talon crutch support included.

Minn Kota 1810222 Attributes

• Mounting Location: Transom
• Compatibility: Minn Kota Talon Shallow Water Anchor
• Rise/ Setback: 6 Inch Setback
• Finish: Anodized
• Color: Silver
• Material: Aluminum
• With Mounting Hardware: Yes

Minn Kota 1810222 Features & Benefits

• Marine-Grade, Anodized Aluminum Construction For Strength And Durability
• Adjustable Deck Support Provides Stability While Tilting
• Designed For Temporary Clearance
• Features Stainless Steel Hardware And Talon Crutch Support
• Compatible With All Talon Shallow Water Anchor Models
• Limited 5 Year Warranty

Minn Kota 1810222 Installation Instructions

• MIN_productmanual_Talon-Tilt-Bracket.pdf

Talon Tilt Bracket

Easy-tilt action accommodates for low clearance areas and boat storage. Marine-grade, anodized aluminum construction for strength and durability. Adjustable deck support provides stability while tilting. Requires use of a Talon Adapter Bracket - not intended for use with Talon direct-mounted to hull of boat. Designed for temporary clearance - not intended for transport (on water or trailering). Stainless steel hardware and Talon crutch support included. Compatible with all three-stage, 8 ft., 10 ft., and 12 ft. Talon shallow water anchors.

"Minn KotaMarine-grade anodized-aluminum construction provides enough strength to withstand the constant use of the most ardent fisherman. Adjustable deck support offers stability while tilting. Requires the use of a Talon Adapter Bracket."
