Sierra 368 Marine Fuel Feed Hose 3/8 in x 50 ft Low Permeation

SKU: 2008545 · UPC: 808282266318 · MPN: 16-368-0386
4.7 · 0 reviews
Authorized dealer25% off
$98.19
$132.59Save $34.40
or 4 payments of $24.54 with Affirm · See disclosures
In stock — Ships Monday Pickup Tuesday · Fort Lauderdale (FL)
SAME-DAY SHIPPING · 14:23 EST
Order now, ships Monday
Ships from your nearest warehouse. UPS Ground 2–4 business days.
Free shipping
Orders $500 or more
Free returns
Within 30 days
Same day shipping
Order before 3 PM (EST)
Ask anything
We're here to help
$98.19
02 · Overview

Sierra 368 Marine Fuel Feed Hose 3/8 in x 50 ft Low Permeation — Product description

The Sierra Series 368 is a low-permeation marine fuel feed hose in a 50 foot coil, 3/8 inch inside diameter. It handles gasoline up to 85 percent ethanol, diesel, and biodiesel in every blend, and it's A1-15 certified so it keeps fuel vapor where it belongs. The hose you install once and forget about.

If you're re-plumbing a fuel system or just chasing down a soft, weeping old line, the Sierra Series 368 is the hose you want feeding your engine. It's a 3/8 inch inside diameter marine fuel feed hose in a 50 foot coil, built for the stuff that actually runs through boat fuel systems today. Gasoline up to 85 percent ethanol. Diesel. Biodiesel in every blend. The lining is made to live with modern fuel without going soft or gummy on you.

The number that matters most here is low permeation. Older rubber fuel line lets fuel vapor seep right through the wall, which is bad for your nose, bad for the bilge, and these days it's against the rules. This hose is A1-15 certified, the low-permeation standard that meets EPA evaporative-emission requirements for marine fuel lines. So it keeps the fuel where it belongs and keeps you legal. The A1 part of that rating also means it's a fire-resistant construction, which is why it's approved for below-deck fuel lines where a plain hose isn't. The cover is black reinforced polyester, and it shrugs off fuel, oil, and the salt-and-heat abuse of a working engine bay.

Let's talk pressure, because this is where people get tripped up. The 368 is rated to 100 PSI maximum. That's plenty for fuel feed and return lines running off a low-pressure lift pump or a primer bulb. It is not a high-pressure injection hose. If you're plumbing the high side of a modern EFI or common-rail diesel, you need dedicated high-pressure line, not this. Use the 368 where it belongs, on the supply and return side, and it'll outlast the boat.

Sizing is straightforward. The 3/8 inch ID is the fuel path, and it slips over a standard 3/8 inch barb. The 11/16 inch OD is the outside of the hose, which is what you measure for clamp sizing and for figuring clearance through a tight bulkhead. One thing we've run into: some OEM tank nipples are sized a hair different, so dry-fit before you commit and grab the right barb adapter if you need one. Better to sort that at the bench than hanging upside down in a lazarette.

A few install tips from doing this a bunch. Fifty feet of hose ships as a coil, and a cold coil can fight you on tight bilge runs. Warm it up first. A little time in the sun or a soak in warm water makes it far more willing to bend. Avoid sharp kinks, support long runs with cushioned clamps every foot or so, and double-clamp both ends on outboards and anywhere there's real vibration. That's cheap insurance against a fuel leak. And route the hose out of constant direct sunlight where you can, or sleeve it in split conduit. UV is the enemy of any hose cover over the long haul.

Fifty feet is generous. On a small runabout you'll have plenty left over, so cut what you need and store the remainder coiled flat so it doesn't take a permanent set. On a bigger inboard or a twin-engine rig, that length lets you do the whole fuel system in one shot with matching hose end to end. Pair it with a good 10-micron fuel-water separator and a primer bulb and you've got a clean, reliable feed that handles ethanol gas even when the engine compartment gets hot.

Who's this for? Outboard owners replacing brittle old primer-bulb hose, inboard owners doing a proper fuel-system refresh, sailboat auxiliary diesels, and anyone who wants one hose that covers both the gas and diesel boats in the fleet. If you run ethanol pump gas, this is the line that stops the slow degradation you get from cheap hose. And if you keep a diesel, the same coil handles biodiesel blends without a second thought.

Sierra builds parts to meet or beat the original equipment they replace, and this hose is no exception. It's the kind of unglamorous gear you install once and forget about, which is exactly what you want from a fuel line. Backed by Sierra's limited two-year warranty and our authorized-dealer support if you ever need it.

Key Features

  • 3/8 inch inside diameter and 11/16 inch outside diameter, sized for standard marine fuel feed and return runs
  • 50 foot continuous coil, enough for a full re-plumb or several shorter runs cut to fit
  • Rated to 100 PSI maximum working pressure for low-pressure fuel feed and return lines
  • Compatible with gasoline up to 85 percent ethanol, diesel, and biodiesel in all blends
  • A1-15 low-permeation certified, meets EPA evaporative-emission requirements for marine fuel lines
  • Type A fire-resistant construction, approved for below-deck fuel systems
  • Reinforced polyester braid holds its shape and resists kinking under engine-bay heat
  • Black cover stands up to fuel, oil, salt, and vibration

Why Buy from NVN Marine

  • Authorized Sierra Marine reseller, full manufacturer warranty
  • NMEA member and ABYC certified, advice from real boat techs
  • Same-day shipping before 3 PM ET on in-stock items
  • NY headquarters and Fort Lauderdale flagship retail store
NVN Marine — 11 W State Road 84, Fort Lauderdale, FL 33315 Available for pickup at our Fort Lauderdale store (Tuesday) $98.19
03 · The numbers

Technical specifications

Title Sierra Series 368 Low Permeation Marine Fuel Feed Hose
Brand Sierra Marine
Manufacturer Part Number 16-368-0386
UPC 808282266318
Series 368
Application Fuel Feed
Fuel Compatibility Gasoline up to 85% ethanol, diesel, biodiesel (all blends)
Length 50 ft
Inside Diameter 3/8 in
Outside Diameter 11/16 in
Maximum Pressure 100 PSI
Permeation Rating A1-15 Low Permeation Certified
Reinforcement Reinforced Polyester
Color Black
04 · Before you buy

Frequently asked questions

What fuels can this hose handle?

Gasoline up to 85 percent ethanol, diesel, and biodiesel in all blends. The low-permeation lining is built for modern fuels, so ethanol gas won't degrade it the way it eats cheap rubber line.

Can I use this on a high-pressure fuel injection line?

No. The 368 is rated to 100 PSI maximum, which covers fuel feed and return lines off a low-pressure lift pump or primer bulb. For the high side of an EFI or common-rail diesel you need dedicated high-pressure injection hose.

What's the difference between the 3/8 inch and 11/16 inch measurements?

3/8 inch is the inside diameter, the actual fuel path, and it slips over a standard 3/8 inch barb. 11/16 inch is the outside diameter, which you use for clamp sizing and for checking clearance through a tight bulkhead.

Is it certified for low permeation and legal to use?

Yes. It's A1-15 certified, the low-permeation classification that meets EPA evaporative-emission requirements for marine fuel lines. The A1 rating also means fire-resistant construction for below-deck use.

How do I keep it from kinking on tight runs?

Warm the coil before installing, a little sun or a soak in warm water makes it far more flexible. Avoid sharp bends, and support long runs with cushioned clamps roughly every foot.

Should I double-clamp the connections?

On outboards and anywhere there's real engine vibration, yes. Two clamps at each fitting is cheap insurance against a fuel leak working loose over time.

Will 50 feet be too much for my boat?

On a small runabout you'll likely have plenty left over. Cut what you need and store the remainder coiled flat so it doesn't take a permanent set. On a larger inboard or twin-engine boat, 50 feet lets you plumb the whole system with matching hose.

How do I make it last?

Keep it out of constant direct sunlight where you can, or sleeve it in split conduit. UV is what shortens the life of any hose cover, so a little shade goes a long way.

What fittings does it use?

The 3/8 inch ID fits a standard 3/8 inch barb. Some OEM tank nipples run a slightly different size, so dry-fit first and pick up the right barb adapter if needed.

What's the warranty?

Sierra backs it with a limited two-year warranty. We're an authorized Sierra dealer, so any warranty question runs through us.
