Shadow-Caster RGB Super Mini Neon Strip, 16ft IP67 LED
Shadow-Caster RGB Super Mini Neon Strip, 16ft IP67 LED — Product description
The Shadow-Caster RGB Super Mini Neon Strip gives you a clean, continuous glow instead of a row of visible dots. It's a flexible 16-foot marine LED in a slim 0.2 by 0.5 inch profile, IP67 waterproof, with 16 mounting clips and 2 end caps in the box. Full RGB, so you dial in any color you want.
The Shadow-Caster RGB Super Mini Neon Strip is the accent lighting a lot of boaters reach for when they want that clean, continuous glow instead of a row of visible dots. It's a flexible neon-style LED run, 16 feet long, in a slim 0.2 by 0.5 inch profile that tucks into places a bulkier strip never could. And because it's full RGB, you're not locked into one color. Red for running the flats at dusk, cool blue for the cockpit at anchor, green in the livewell. You dial it in.
Shadow-Caster builds this gear for the water first, and it shows. The whole run carries an IP67 waterproof rating, so a wave over the gunwale or a hard rain on the mooring isn't going to kill it. The two included end caps seal the cut ends, and the 16 clips give you a mechanical hold that doesn't rely on adhesive alone. That last part matters more than people think. Sticky-back tape on cold gelcoat lets go eventually. The clips keep the strip put through a season of pounding.
Power-wise, this draws 15 watts per meter. Across the full 16-foot length that works out to roughly 73 watts, so it's not a trivial load if you're running the whole strip off a small house bank. On short accent runs you can wire it straight into your 12-volt DC system with a properly sized fuse. On longer pulls, step up your wire gauge to keep the voltage from sagging, otherwise the far end of the strip reads dimmer and the color mixing drifts. We usually run heavier wire than the length strictly calls for. It's cheap insurance for even color end to end.
Where does it go? Just about anywhere you want a soft wash of light without a hot spot. Under the gunwale and toe rail for a night-time deck glow. Around the T-top frame. Inside a livewell so you can see your bait after dark. Down the length of a hardtop or under the console lip for courtesy lighting that won't blow out your night vision. The neon-style diffuser is the whole point here, it spreads the light into an even line instead of the pinpoint dots you get from bare LED tape.
A couple of honest notes before you buy. This is an RGB strip, which means it needs a compatible RGB controller to actually change colors, and you'll want that controller and its connections to be marine-rated and sealed too. Condensation inside a cheap indoor controller is the number one reason these installs act flaky. And while the strip is flexible, it bends on one axis. It'll follow a gentle curve or a large-radius corner beautifully, but a tight 90-degree bend around thin tubing wants a proper corner connector, not a hard crease.
One more thing worth knowing: the strip cuts at fixed points along its length, not anywhere you like, so measure your space against those cut marks before you slice. Trim it too short and you can't add length back. Most boaters find the 16-foot run covers a console and a cockpit accent line with length to spare, but if you're lighting a bigger boat, plan the layout on paper first so you know exactly where each cut lands.
Bottom line, this is a well-built marine accent strip from a brand that lives in the saltwater world. If you want to add color and courtesy lighting to a center console, bay boat, or cruiser without stringing together a dozen little puck lights, the Super Mini Neon Strip is an easy call. Cut it, clip it, seal the ends, wire it up, and you've got a finished look that reads custom.
Key Features
- Full RGB (Red / Green / Blue) color mixing so you can set any accent color for the mood or task
- 15 watts per meter output for a bright, even wash of light along the whole run
- 16-foot continuous length covers a console and a cockpit accent line with room to spare
- Slim 0.2 by 0.5 inch cross section tucks under gunwales, toe rails, and hardtop lips
- IP67 waterproof rating stands up to spray, rain, and washdowns
- Neon-style diffuser spreads the light into a smooth line with no pinpoint dots
- 16 mounting clips included for a mechanical hold that doesn't rely on adhesive alone
- 2 end caps included to seal the cut ends against water intrusion
- Flexible body follows gentle curves and large-radius corners around framing
Why Buy from NVN Marine
- Authorized Shadow-Caster LED Lighting reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | Shadow-Caster RGB Super Mini Neon Strip 16ft |
|---|---|
| Brand | Shadow-Caster LED Lighting |
| Manufacturer Part Number | SCM-AL-SVMINI-NEON-16 |
| UPC | 850024342262 |
| Series | Super Mini Neon |
| Light Type | Flexible LED Neon Strip |
| Color | Red / Green / Blue (RGB) |
| Power Draw | 15 Watts Per Meter |
| Length | 16 Feet |
| Cross Section | 0.2 in x 0.5 in |
| Waterproof Rating | IP67 |
| Included Clips | 16 |
| Included End Caps | 2 |
| Product Type | Marine Accent LED Lighting |
Frequently asked questions
Is this strip really waterproof enough for an open boat?
Yes. It carries an IP67 waterproof rating, which handles spray over the gunwale, rain at the mooring, and washdowns. Seal the cut ends with the included end caps and a bead of marine silicone and it'll take a season of saltwater exposure without trouble.
What comes in the box?
The 16-foot RGB neon strip, 16 mounting clips, and 2 end caps. You'll supply the RGB controller, wiring, fuse, and any corner connectors your layout needs.
Can I cut it to length?
Yes, but only at fixed cut points along the strip, not anywhere you like. Measure your run against those marks before you slice, because you can't add length back once it's trimmed. Seal any fresh cut end with an end cap.
How do I mount it?
Use the 16 included clips for the mechanical hold. On gelcoat we like to back that up with a quality marine adhesive tape, since sticky-back backing alone tends to let go on cold, flexing surfaces over time.
What size wire and fuse should I run?
It draws 15 watts per meter, roughly 73 watts across the full 16 feet. Wire it into your 12-volt DC system through a properly sized fuse. On longer runs, step up the wire gauge so the far end doesn't dim and the colors stay even.
Does it need a controller?
Yes. Because it's a full RGB strip, you need a compatible RGB controller to change and mix colors. Pick one that's marine-rated and sealed, since condensation inside a cheap indoor controller is the most common cause of flaky color.
Where do people install it?
Under the gunwale and toe rail for deck glow, around the T-top frame, inside a livewell, or under the console lip for courtesy lighting. Anywhere you want a soft, even line of light without a hot spot.
Will it bend around tight corners?
It flexes well on one axis and follows gentle curves and large-radius corners nicely. For a tight 90-degree turn around thin tubing, use a proper corner connector rather than forcing a hard crease.
What voltage does it run on?
It's built for a standard 12-volt DC marine system. Run it off your house bank through a fuse, and size the circuit for the roughly 73-watt draw of the full strip.
