Sea-Dog Spring-Gate Quick Link 3/8 in Galvanized
Sea-Dog Spring-Gate Quick Link 3/8 in Galvanized — Product description
The Sea-Dog spring-gate quick link gives you a fast, self-closing connection for rigging, anchor gear, and everyday deck jobs. Electro-galvanized mild steel body with a 3/8 inch gate opening and a 7700 pound capacity.
This Sea-Dog spring-gate quick link is the kind of fitting you end up reaching for all over the boat. Push the gate open against the spring, clip it where you need it, and it snaps shut on its own. The interlocking gate seats into the nose of the link so it won't work loose with the motion of the water.
It's an oval link, 2-15/16 inches long with a 3/8 inch gate opening, so it takes a decent-sized shackle, ring, or line eye. The body is electro-galvanized mild steel, which gives you a clean, corrosion-resistant finish for general rigging, anchor connections, flag halyards, fender lines, and all the little connect-and-go jobs around the deck.
Rated at 7700 pounds, it's got plenty of margin for the loads most boaters throw at it. And it's a quick, one-handed connection that beats fumbling with a threaded shackle pin out on the water. Keep a few in the dock box and you'll find a use for them.
Key Features
- Spring-loaded interlocking gate snaps shut on its own for fast, one-handed connections
- 3/8 inch gate opening fits common shackles, rings, and line eyes
- 2-15/16 inch oval body gives a balanced shape for rigging and anchor gear
- Electro-galvanized mild steel resists corrosion out on the water
- 7700 pound capacity leaves plenty of margin for everyday deck and rigging loads
Why Buy from NVN Marine
- Authorized Sea-Dog reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | Interlocking/ Spring Loaded Gate; Oval; 3/8 Inch Opening; 2-15/16 Inch Length; Electro-Galvanized Mild Steel; 7700 Pound Capacity |
|---|---|
| Brand | Sea-Dog |
| Manufacturer Part Number | 158008-1 |
| UPC | 035514158404 |
| Gate Type | Interlocking / Spring Loaded |
| Shape | Oval |
| Gate Opening | 3/8 Inch |
| Length | 2-15/16 Inch |
| Material | Electro-Galvanized Mild Steel |
| Capacity | 7700 Pound |
Frequently asked questions
How does the spring gate work?
You push the gate open against its spring, clip it onto a ring, shackle, or eye, and let go. The gate snaps shut and the interlocking nose keeps it closed, so you get a quick one-handed connection with no threaded pin to fumble with.
What size opening does this link have?
The gate opening is 3/8 inch and the oval body is 2-15/16 inches long overall, so it takes a decent-sized shackle, ring, or line eye.
What is it made of and will it rust?
It's electro-galvanized mild steel. The galvanized finish resists corrosion for general rigging and deck use, though like any plated steel fitting it holds up best when you rinse it after heavy saltwater exposure.
How much load can it take?
It's rated at a 7700 pound capacity, which leaves good margin for typical anchor, rigging, and deck jobs. For life-safety or overhead lifting, use hardware specifically rated and marked for lifting instead.
