Sea-Dog SD-13 15 Amp Circuit Breaker | 830114
Sea-Dog SD-13 15 Amp Circuit Breaker | 830114 — Product description
The Sea-Dog SD-13 is a 15 amp push-to-reset thermal breaker built for marine panels. It trips on an overload, you push the white button to reset, and you're back in business. No fuse to carry, no tools needed.
The Sea-Dog SD-13 is a 15 amp thermal circuit breaker you wire into a marine panel to protect a single DC circuit. When the current climbs past 15 amps, the breaker trips and cuts power. To bring the circuit back, you just push the white reset button. That's it. No spare fuses rattling around in a drawer, no tools, no guesswork at the dock.
It's rated for 250 volts AC and 50 volts DC, so it handles standard 12V and 24V boat wiring with plenty of headroom. The housing is Bakelite, which shrugs off heat and holds up in a damp engine space. Wiring is simple with the two screw terminals, and it panel mounts with only 3/16 inch of depth behind the dash.
What makes this one right for a boat is the ignition-protected rating. It meets UL 1077 and carries the UL1500 ignition-protected listing, which means it won't throw a spark that could set off fuel vapors. That's the spec you want anywhere near a gas engine or fuel tank. Good for bilge pumps, lights, pumps, and accessory circuits up to 15 amps.
Key Features
- 15 amp thermal circuit breaker protects a single DC circuit from overload
- Push-to-reset white button, no spare fuses or tools needed
- Rated 250V AC / 50V DC, handles 12V and 24V boat wiring
- Ignition protected to UL1500 and UL 1077 listed, safe near fuel systems
- Bakelite housing with screw terminals, panel mounts in 3/16 inch depth
Why Buy from NVN Marine
- Authorized Sea-Dog reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | SD-13 Thermal Circuit Breaker; 15 Amp; 250 Volt AC/ 50 Volt DC; Push-To-Reset; Black With White Button; Bakelite; Screw Terminals; Panel Mount; 3/16 Inch Panel Depth; UL Listed: UL 1077/ UL/cUL/ Ignition Protected UL1500; Single |
|---|---|
| Brand | Sea-Dog |
| Manufacturer Part Number | 830114 |
| UPC | 035514830058 |
| Amperage | 15 Amp |
| Voltage Rating | 250 Volt AC / 50 Volt DC |
| Reset Type | Push-To-Reset |
| Color | Black With White Button |
| Housing Material | Bakelite |
| Terminals | Screw Terminals |
| Mounting | Panel Mount |
| Panel Depth | 3/16 Inch |
| Certifications | UL 1077, UL/cUL, Ignition Protected UL1500 |
| Quantity | Single |
Frequently asked questions
How do I reset the SD-13 after it trips?
Push the white button on the front. Once the circuit has cooled and the overload is cleared, the button resets and power is restored. No tools needed.
Is this breaker safe to use near a gas engine?
Yes. The SD-13 carries the UL1500 ignition-protected listing, which means it won't throw a spark that could ignite fuel vapors. That's exactly what you want in an engine space or near a fuel tank.
What voltage and amperage is this rated for?
It's a 15 amp breaker rated for 250 volts AC and 50 volts DC. That covers standard 12V and 24V marine DC circuits with room to spare.
How does it mount?
It's a panel-mount breaker with screw terminals and only 3/16 inch of panel depth behind the dash. Wire the two screw terminals and you're set.
