Rigid 360 Connect 50-Inch LED Light Bar with RGB Pods
Rigid 360 Connect 50-Inch LED Light Bar with RGB Pods — Product description
The Rigid Industries 360 Connect is a 50-inch combo-beam LED light bar that throws 30,600 raw lumens down the water and across the shoreline. This is the full assembly, so you also get ten 4-inch RGB accent pods, the connect harness, black covers and mounting hardware in the box. One kit, a wall of usable light.
The Rigid Industries 360 Connect 50-inch light bar is built for boaters who want to turn night into day. It's a single 50-inch bar packing 40 LEDs, and it runs a combo beam, so you get spot-style distance and flood-style spread out of the same housing. Rated at 30,600 raw lumens, this thing lights up a whole cove. The housing is black, the lens is clear, and the bar stands about 3.9 inches tall.
What makes this the 360 Connect assembly and not just a bare bar is everything that ships with it. You get ten 4-inch RGB light pods, six set up as spot and four as drive beams, so you can push light exactly where the bar doesn't reach. Think stern corners, cockpit spreaders, the underside of a hardtop. The RGB part means those pods aren't just white work lights. You can run color for dock ambiance, for night fishing, or just to match the boat. Black covers come in the box to protect the pods when they're parked.
Out on the water, the combo beam is the part you'll notice first. The spot section reaches way out ahead, so you can pick up a channel marker or a crab pot line long before you're on top of it. The flood section washes the near water, so the deck and the surface right around the boat stay lit. Running both at once from a single 50-inch bar is what makes this a real offshore tool and not just a novelty. Add the RGB pods around the cockpit and you've got usable light in every direction, which is exactly what 360 Connect is named for.
Now let's talk power, because this is where people get themselves in trouble. The bar alone pulls 17.9 amps at 14 volts DC, and once you add all ten pods you're asking a lot of a stock harness. Wire it in the right way. Run it through a relay, feed it with heavy-gauge wire sized for the full load, and put it on its own fused switch. On a 22 to 26 foot center console with a dual-battery setup, don't tap into an existing accessory circuit and hope for the best. Give it a clean, dedicated run and you'll never see the voltage drop that dims a bar like this at the far end.
Mounting hardware is included, and it works great for a flat surface like the front of a T-top or a hardtop lip. If you're going onto a radar arch or a rounded tube, plan on picking up a set of aftermarket L-brackets, because the included hardware is sized for straightforward flat mounts. A combo beam like this reads best up high. Put it on the hardtop or the T-top looking forward and down. Mounted low on a bow rail, that much output can bounce glare right back at the helm, so height is your friend here.
So who buys a light bar this size? Offshore crews running home after dark. Bowfishing boats that need to flood the water. Night divers, commercial guys, anyone working the deck once the sun's gone down. And because Rigid builds these for hard use on and off the water, the same assembly ends up on plenty of overland trucks, side-by-sides and utility rigs too. If your world is dark and you need to own it, that's the job this kit was built for.
A couple of honest notes. This is a lot of light, more than you need for close-in docking, so a lot of owners wire in a dimmer or split the pods onto a second switch to knock it back when they don't want to blind the boat next to them. And like any light you mount in salt air, rinse it, keep the covers on when it's parked, and it'll give you seasons of service. Buy it once, wire it right, and light up the whole horizon.
Key Features
- 50-inch bar with 40 LEDs and a combo beam, distance and spread from one housing
- 30,600 raw lumens, enough output to light an entire cove or work deck after dark
- 17.9 amp draw at 14 volts DC, plan a relay and dedicated fused circuit for a clean install
- Ten 4-inch RGB light pods included, six spot and four drive, to fill the gaps the bar can't reach
- RGB color control on the pods, run white for work or color for dock and night-fishing ambiance
- Clear lens over a black housing, low profile at about 3.9 inches tall
- Connect harness, black covers and mounting hardware in the box, it's a complete assembly not a bare bar
- Combo beam pattern built for high mounting on a T-top, hardtop or radar arch
Why Buy from NVN Marine
- Authorized Rigid Industries reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | Rigid Industries 360 Connect 50-Inch LED Light Bar Assembly |
|---|---|
| Brand | Rigid Industries |
| Manufacturer Part Number | 36310 |
| UPC | 849774036729 |
| Product Line | 360 Connect |
| Length | 50 Inch |
| LED Count | 40 LED Bulbs |
| Power | 250.6 Watt |
| Current Draw | 17.9 Amp at 14 Volt DC |
| Voltage Rating | 14 Volt |
| Beam Pattern | Combo Beam |
| Raw Lumens | 30,600 |
| Lens | Clear |
| Housing Color | Black |
| Height | 3.9 Inch |
| Included Light Pods | Ten 4-Inch RGB Pods (6 Spot, 4 Drive) |
| Included Accessories | Black Covers, Mounting Hardware, Connect Harness |
Frequently asked questions
How bright is the 360 Connect 50-inch bar?
The bar puts out 30,600 raw lumens from 40 LEDs. That's a serious amount of light, plenty to flood a cove, a work deck or the water ahead of the boat at speed.
How much power does it draw?
The bar alone draws 17.9 amps at 14 volts DC. Add the ten RGB pods and the total climbs, so wire the system through a relay on its own heavy-gauge, fused circuit rather than tapping an existing accessory line.
What beam pattern is it?
It's a combo beam, which blends spot and flood in one bar. You get distance to see far ahead plus spread to light up the area around the boat.
What's included in the assembly?
You get the 50-inch bar, ten 4-inch RGB light pods (six spot and four drive), black covers for the pods, mounting hardware and the connect harness. It's a full kit, not a bare bar.
Are the light pods color-changing?
Yes. The ten 4-inch pods are RGB, so you can run them as white work lights or switch to color for dock ambiance or night fishing.
Where should I mount a bar this size?
High and forward. A T-top, hardtop or radar arch works best so the combo beam throws out and down. Mounting it low on a bow rail can bounce glare back at the helm.
Does it come with mounting brackets?
Mounting hardware is included and works well for flat surfaces like a T-top or hardtop lip. For a rounded tube or radar arch you may want to add aftermarket L-brackets.
Can I use it on a truck or side-by-side instead of a boat?
Yes. Rigid builds the 360 Connect for hard use, and the same assembly is popular on overland trucks, side-by-sides and utility rigs, not just boats.
What's the manufacturer part number?
This is Rigid Industries part number 36310, UPC 849774036729.
Is it too bright for close-in docking?
It can be. Many owners wire in a dimmer or split the pods onto a second switch so they can dial the output down when maneuvering near other boats.
