Raymarine Axiom 2 9 RV Chartplotter, RealVision 3D

The Raymarine Axiom 2 9 RV is the all-in-one version of Raymarine's most popular helm display, and it's built for anglers who want navigation and sonar in a single 9-inch screen. RV stands for RealVision, and that's the headline here. This unit builds in RealVision 3D, SideVision, DownVision, and CHIRP sonar, so you can scan wide, look deep, and understand the bottom instantly without adding a separate fishfinder. If you fish structure, work channel edges, or just want to know what's under the boat before you drop a line, this is the display that shows you.

Underneath the sonar is a genuinely fast chartplotter. A new 6-core processor renders charts up to 30 percent faster than the previous generation, so panning and zooming feel instant even when you're loading detailed coastal cartography. Everything runs on LightHouse OS, Raymarine's clean single-screen interface that ties navigation, sonar, radar, video, and NMEA 2000 engine data together. You spend less time in menus and more time watching the water. The 9-inch IPS display shows a widescreen HD 1280 x 720 image at 1500 nits, so it stays sharp in direct sun, and the HydroTough oleophobic coating sheds spray and fingerprints while keeping the touchscreen responsive when it's wet.

Let's talk sonar detail, because that's why you'd choose the RV. The RealVision 3D and SideVision channels run at 350 kHz, DownVision fills in a crisp photo-like view of the bottom, and a CHIRP High channel adds traditional fish arches. For deeper work you can add a 600-watt 50/200 kHz conventional sonar through the correct transducer and adapter cable. A 25-pin RealVision transducer connector on the back handles the RealVision transducer directly. Together these give you a complete picture of fish, structure, and terrain from several angles at once.

Networking keeps pace with the sonar. Gigabit RayNet Ethernet moves radar sweeps, sonar returns, and video across the system quickly, so if you run a second Axiom 2 at another station, both screens share the same live data smoothly. Built-in Wi-Fi 802.11 b/g/n and Bluetooth 4.0 let you pair a phone, stream from popular entertainment apps, and update software wirelessly. Over NMEA 2000 you can monitor leading engines including Mercury, Yamaha, and Suzuki, viewing RPM, fuel, and propulsion data right beside your chart.

Navigation tools are deep. The internal GNSS receiver tracks GPS, GLONASS, and Beidou across up to 28 satellites and fixes your position within about 5 meters with SBAS corrections. You can store up to 10,000 waypoints, 250 routes, and 15 tracks. Plot a route on the chart, or build one in the Orca mobile app and push it to the display over Wi-Fi. Sailors get a full tactical suite as well, with polar profiles, dynamic laylines, race timers, and sailing displays that help you trim for real gains.

Installation is quick. The unit ships with a trunnion bracket and knobs for a bracket mount, plus a panel-mount gasket and hardware for a flush install, so you can fit it whichever way your console prefers. A MicroSDXC card slot handles chart cards and screenshots, and 64 GB of internal storage keeps data close. It's rugged too, carrying IPX6 and IPX7 waterproof ratings, so heavy spray and brief submersion won't faze it at an open helm. Power draw is modest at just under 12 watts on 8 to 16 volts DC, which is easy on your house bank.

Chart support is broad, covering Raymarine LightHouse Charts, Navionics, C-MAP, Florida Marine Tracks, CMOR Mapping, Standard Mapping, StrikeLines, Imray Digital Charts, and S-63 encrypted charts. That range matters when you fish one region and cruise another. If you want one display that navigates confidently and finds fish just as well, the Axiom 2 9 RV is a strong, future-ready choice you can keep building on.
