Hella Marine Dual-Tone Boat Horn Set, 110dB 12V
Hella Marine Dual-Tone Boat Horn Set, 110dB 12V — Product description
Hella Marine's dual-tone horn set gives your boat a serious voice. You get two trumpet horns, one tuned to 500 Hz and one to 400 Hz, that sound together for a full 110-decibel blast anyone on the water will hear. It runs on 12 volts, mounts on the included galvanized bracket, and the yellow ABS housing shrugs off spray.
A boat horn only matters when you actually need it, and that's usually the worst possible moment. Coming into a blind turn on a busy channel. Backing off a dock with a paddler you didn't see. A patch of fog rolling in faster than the forecast said. This Hella Marine dual-tone set is built for exactly those moments. You get two trumpet horns in one kit, one tuned to a 500 Hz high tone and the other to a 400 Hz low tone, and they're meant to run together. That pairing is the whole point. A single-note horn can get lost in wind and engine drone. Two tones stacked on top of each other give you a fuller, more urgent sound that carries.
Rated at 110 decibels, this set is loud. Loud enough to turn heads across a crowded anchorage, and loud enough to do its real job, which is making sure another skipper hears you before anything goes wrong. The high and low trumpets don't just add volume, they add texture. The blended note is harder to ignore than a flat beep, and it reads clearly as a boat signal instead of background noise.
Hella Marine built the housing out of yellow ABS plastic instead of metal, and that's a deliberate choice out on the water. Salt spray eats steel horns alive. Plastic doesn't corrode, doesn't streak rust down your hull, and keeps working season after season. The bright yellow also makes the horns easy to spot when you're chasing down a connection in a locker or behind the console. Each horn carries a 3.2 inch trumpet, and the kit ships with a galvanized metal bracket so you've got a solid mounting point right out of the box.
It's a 12 volt setup, which is what most boats run, and the pair draws 72 watts. That works out to right around 6 amps, so wire it like you mean it. We'd run the horns through a relay triggered by your helm button, with the horn circuit fused close to the battery. That keeps the heavy current off your dash switch and makes for a cleaner, longer-lasting install. If you're replacing a tired factory horn that's gone quiet or scratchy, this is a straightforward upgrade on the same 12 volt wiring.
Where you put them matters. Mount the horns in a spot that's protected from direct standing water but still open enough to project sound forward, behind a console, up under a gunwale, or on a vented bracket near the helm. Angle the trumpets slightly down so they shed water and don't fill up in a rain squall. Both horns should face the same general direction so the two tones combine instead of fighting each other.
Sound signals aren't optional gear. The navigation rules expect every boat to be able to make a short and a prolonged blast, and a weak or dead horn leaves you without a legal way to communicate on the water. This Hella Marine set gives you a genuine, boat-grade voice for maneuvering signals, fog signals, and the plain old "hey, I'm right here" blast when someone drifts too close. It suits everything from center consoles and bay boats to cruisers and pontoons. If your current horn sounds more like a sad kazoo than a warning, it's time.
Hella has been making acoustic warning gear for over a century, and the Marine line carries that same fit-and-forget philosophy. These are simple, sealed, purpose-built horns. There's nothing to fuss with once they're wired and mounted. You press the button, they sound, and they keep doing it trip after trip. That kind of quiet reliability is exactly what you want from a piece of safety gear you'll ignore right up until the day it saves you a very bad afternoon.
Key Features
- Dual-tone design pairs a 500 Hz high-tone horn with a 400 Hz low-tone horn for a fuller, more penetrating blast that cuts through wind and engine noise
- 110 decibel output is loud enough to be heard clearly across a crowded channel or anchorage
- 12 volt operation drops right into standard marine electrical systems
- 72 watt draw (about 6 amps) delivers strong output, so wire it through a relay for a clean install
- Yellow ABS plastic housing won't corrode or rust like metal horns exposed to salt spray
- 3.2 inch trumpets project the sound forward for maximum reach
- Galvanized metal mounting bracket included for a solid, ready-to-install setup
- Ships as a matched set of 2 horns, both tones in one kit
Why Buy from NVN Marine
- Authorized Hella Marine reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | Hella Marine Dual-Tone Trumpet Horn Set |
|---|---|
| Brand | Hella Marine |
| Manufacturer Part Number | 012010821 |
| UPC | 760687164067 |
| Configuration | Dual-Tone (High + Low) |
| High-Tone Frequency | 500 Hertz |
| Low-Tone Frequency | 400 Hertz |
| Sound Output | 110 Decibels |
| Voltage | 12 Volt |
| Power | 72 Watt |
| Trumpet Size | 3.2 Inch |
| Color | Yellow |
| Housing Material | ABS Plastic |
| Mounting Bracket | Galvanized Metal |
| Quantity | Set of 2 |
Frequently asked questions
What comes in the kit?
You get two horns, one 500 Hz high-tone and one 400 Hz low-tone, plus a galvanized metal mounting bracket. It's a matched set of 2 designed to sound together.
How loud is it?
The set is rated at 110 decibels. That's loud enough to be heard clearly across a busy channel or a crowded anchorage.
Why two horns instead of one?
The two trumpets are tuned to different pitches, 500 Hz and 400 Hz. When they sound together the blended high and low note is fuller and harder to ignore than a single flat tone, and it carries better through wind and engine noise.
What voltage does it run on?
12 volts, which is the standard electrical system on most boats.
How much power does it draw?
The pair draws 72 watts, which is right around 6 amps at 12 volts. Because of that current, we recommend wiring the horns through a relay triggered by your helm button, with the circuit fused near the battery.
What's the housing made of?
Yellow ABS plastic. It won't corrode or rust the way a metal horn does when it's exposed to salt spray, so it holds up season after season on the water.
How do I mount it?
The kit includes a galvanized metal bracket. Mount the horns in a spot protected from standing water but open enough to project sound forward, and angle the trumpets slightly down so they shed water.
How big are the trumpets?
Each horn has a 3.2 inch trumpet, sized to project the sound forward for good reach.
Can I use this to replace a weak factory horn?
Yes. It's a straightforward upgrade on the same 12 volt wiring. If your existing horn has gone quiet or scratchy, this dual-tone set gives you a much stronger signal.
