Hella Marine Blade 9" LED Driving Light Set of 2

SKU: 2007661 · UPC: 760687183457 · MPN: 358228811
4.7 · 0 reviews
Authorized dealer33% off
$373.99
$558.60Save $184.61
or 4 payments of $93.49 with Affirm · See disclosures
Low stock — 1 left — Ships today Pickup Tuesday · Fort Lauderdale (FL)
SAME-DAY SHIPPING · 14:23 EST
Order in time, ships today
Ships from your nearest warehouse. UPS Ground 2–4 business days.
Free shipping
Orders $500 or more
Free returns
Within 30 days
Same day shipping
Order before 3 PM (EST)
Ask anything
We're here to help
$373.99
02 · Overview

Hella Marine Blade 9" LED Driving Light Set of 2 — Product description

The Hella Marine Blade is a 9-inch round LED driving light, and this set gives you a matched pair. Each lamp runs six LEDs behind a polycarbonate lens for a long-throw 120-watt driving beam rated at 13,200 lumens. Built for saltwater in a black aluminum housing, with black stone shield covers and mounting instructions in the box.

If you run at night, dawn, or in fog, you already know how much a good pair of driving lights changes the boat. The Hella Marine Blade is a 9-inch round LED lamp built for exactly that, and this listing is the matched set of two so both sides of the bow or hardtop throw the same beam. Each Blade packs six LEDs behind a polycarbonate lens and puts out a driving-beam pattern rated at 120 watts and 13,200 lumens. That's a long, reaching beam, the kind you want for spotting a channel marker, a crab pot line, or the dock at the end of a long run home.

Hella Marine builds these to their "Fit and Forget" standard, and out on the water that reputation matters. The housing is black aluminum, the lens is polycarbonate, and the whole lamp is sealed to take spray, wash-down, and the constant pounding a planing hull hands out. This isn't an automotive light someone re-labeled for boats. It's designed from the start to sit exposed to salt air season after season.

The beam here is a driving pattern, which means it's tuned for distance rather than a wide close-in wash. On the water that's a real trade-off worth understanding. A driving beam reaches way out ahead, which is perfect running offshore or down a long channel. Up close and slow, that same tight beam can throw glare back off the water, so a lot of boaters run these for the run and switch to their existing flood or deck lights for docking. Think of the Blade as your distance eyes, not your close-quarters work light.

Mounting is upright, and each lamp comes with instructions in the box. The bracket sets the lamp on top of a hardtop, tower, bow pulpit, or A-frame. A pair of 9-inch rounds looks right on boats in the 25 to 35 foot range, symmetric off the centerline. On smaller express cruisers, check your clearance to the radar dome and windshield before you drill, because a 7.87-inch round takes up more real estate than it looks like on the bench. Measure twice.

A couple of rigging notes from people who've installed these. The upright brackets live in a high-vibration spot, so back up the hardware with lock washers and a dab of thread locker, and re-check them after your first season. Add a little dielectric grease at the mounting points and on the connections to keep the aluminum from starting to corrode where it meets a stainless bolt or a wet deck. Small steps, but they're the difference between a light that still looks new in two years and one that's chalky at the base.

On the electrical side, take these seriously. Each lamp is a 120-watt load, so on a 12-volt system you're looking at roughly 10 amps apiece, which means the pair pulls close to 20 amps when both are lit. Run them off a proper fused, relay-switched circuit with wire sized for the run so you don't fight voltage drop and dim output at the far end of a long boat. A dedicated relay harness and a switch at the helm is the clean way to do it. If you wire them straight to a small dash switch, you'll cook the switch.

Both lamps ship with a black stone shield cover. Those aren't just cosmetic. They protect the lens from spray, UV, and debris when the lights aren't in use, and they tidy up the look of a pair of bright lenses sitting on your hardtop in the daylight. Polycarbonate lenses can haze over time from sun and salt, and keeping the shields on when you're not running helps the lenses stay clear longer.

So who's this set for? Anyone rigging a center console, express, or sportfish that runs before sunup or after dark and wants serious reach out front. Two matched 9-inch Blades, factory stone shields, and a mounting kit, ready to wire into a relay circuit. If you only need a soft, wide wash for cleaning fish at the dock, a driving beam is the wrong tool. But for punching a hole in the dark a long way out ahead of the bow, this is the pair you want.

Key Features

  • Matched set of two 9-inch round Hella Marine Blade LED lamps, symmetric mounting off the centerline
  • Six LEDs per lamp behind a polycarbonate lens for a clean, bright output
  • Driving-beam pattern rated 120 watts and 13,200 lumens per lamp for long-range reach
  • Black aluminum housing sealed for saltwater spray, wash-down, and constant hull vibration
  • Upright bracket mount suits hardtops, towers, bow pulpits, and A-frames
  • Two black stone shield covers included to protect the lenses from UV, salt, and debris
  • Mounting instructions included in the box
  • Roughly 10 amps per lamp on 12 volts, wire into a fused, relay-switched circuit

Why Buy from NVN Marine

  • Authorized Hella Marine reseller, full manufacturer warranty
  • NMEA member and ABYC certified, advice from real boat techs
  • Same-day shipping before 3 PM ET on in-stock items
  • NY headquarters and Fort Lauderdale flagship retail store
NVN Marine — 11 W State Road 84, Fort Lauderdale, FL 33315 Available for pickup at our Fort Lauderdale store (Tuesday) $373.99
03 · The numbers

Technical specifications

Title Hella Marine Blade 9" LED Driving Light Set of 2
Brand Hella Marine
Manufacturer Part Number 358228811
UPC 760687183457
Lamp Type LED
LEDs Per Lamp 6
Diameter 7.87 in (9 in nominal)
Power (Per Lamp) 120 Watt
Light Output (Per Lamp) 13,200 Lumens
Beam Pattern Driving Beam
Lens Material Polycarbonate
Housing Material Black Aluminum
Mount Type Upright Mount
Quantity Set of 2
Included 2 Black Stone Shield Covers, Mounting Instructions
04 · Before you buy

Frequently asked questions

How many lights come in this set?

Two. This is a matched set of two Hella Marine Blade 9-inch round LED driving lamps, so both sides of your bow or hardtop throw the same beam.

What is a driving beam good for on a boat?

A driving beam is tuned for distance rather than a wide close-in wash. It reaches far out ahead, which is what you want running offshore, down a long channel, or spotting a marker at range. Up close and slow it can glare off the water, so many boaters switch to a flood or deck light for docking.

How do I wire these on a boat?

Each lamp is a 120-watt load, so on 12 volts figure roughly 10 amps apiece and close to 20 amps for the pair. Run them through a fused, relay-switched circuit with wire sized for the run so you avoid voltage drop and dim output. Don't wire them straight to a small dash switch, it won't handle the load.

Will a 9-inch round fit my boat?

A pair of 9-inch Blades suits boats in the roughly 25 to 35 foot range with room on the hardtop, tower, or bow. The lamp is 7.87 inches round, so on smaller express cruisers check clearance to your radar dome and windshield before drilling.

Are these built for saltwater?

Yes. Hella Marine builds the Blade to their Fit and Forget standard with a sealed black aluminum housing and polycarbonate lens made to take salt spray and wash-down. Adding dielectric grease at the mounting points helps prevent corrosion where aluminum meets stainless hardware.

What are the stone shield covers for?

The two included black stone shield covers protect the lenses from spray, UV, and debris when the lights aren't in use. They also clean up the look of the lamps in daylight and help the polycarbonate lenses stay clear longer.

How are the lamps mounted?

They use an upright bracket mount that sets the lamp on top of a surface like a hardtop, tower, bow pulpit, or A-frame. Mounting instructions are included. Because the brackets sit in a high-vibration spot, back up the hardware with lock washers and thread locker and re-check after the first season.

What comes in the box?

Two Hella Marine Blade 9-inch LED lamps, two black stone shield covers, and mounting instructions.

How bright are they?

Each lamp is rated at 120 watts and 13,200 lumens in a driving-beam pattern, driven by six LEDs behind a polycarbonate lens. That's a long, reaching beam built for distance rather than a wide close-in flood.
