Hella 355119702 High Carbon Vented Brake Rotor, 320mm 6x112

Hella has been making braking and lighting components for well over a century, and the 355119702 is a straightforward, well made vented disc brake rotor. It measures 320 mm across the friction surface, runs 30 mm thick, and uses a 6 x 112 mm wheel bolt pattern with a 67 mm center bore. If those numbers match what's on your car right now, this is a clean, direct replacement.

The big story here is the material. This rotor is cast from high carbon iron, and that matters more than it sounds. High carbon iron handles heat cycles better than plain gray iron. It runs quieter, damps vibration, and it's far less prone to the fine surface cracking you see on rotors that get cooked on long descents or in stop-and-go traffic. If you've ever had a set of rotors start to shudder under the pedal after a hard summer, you already know why the material choice is worth paying attention to.

It's a vented rotor, which means there are internal vanes between the two friction faces that pull air through the disc as the wheel spins. That airflow carries heat away from the pad contact area. On a heavy vehicle, or anything that tows or spends time in the hills, that cooling is the difference between consistent pedal feel and brake fade halfway down the grade. Vented rotors this size are almost always a front-axle part, but measure yours and confirm before you order.

Hella finishes the non-friction areas with a zinc coating. That's the hat, the edges, and the vent openings, the parts that don't get scrubbed clean by the pads. Left bare, cast iron flashes orange with surface rust within days of install, especially if the car sits. The zinc keeps it looking right and slows real corrosion where road salt likes to collect. The friction faces themselves ship with a light protective film that you'll clean off with brake cleaner before install.

This is a one piece design, so the hat and the rotor are cast as a single unit. That keeps runout predictable and makes the install simple. Slide it on, torque your caliper bracket and caliper to spec, and bed the pads in properly. There's no assembly and no separate hat to bolt up.

A couple of honest notes before you buy. First, this rotor is sold individually, one rotor per order. Brakes should always be replaced as an axle set, so for most jobs you'll want two of these plus a fresh set of pads. Mixing a new rotor against a worn one on the same axle gives you uneven braking, and that's not something to gamble with. Second, this is an automotive brake rotor, not a trailer part. The 6 x 112 pattern and 67 mm bore are passenger-vehicle dimensions, so verify your application by bolt pattern, hub bore, diameter, and thickness rather than guessing.

Installation is well within reach for a competent DIYer with a jack, stands, and a torque wrench. New rotors don't need machining. Clean off the protective coating, check that your hub face is clean and rust free so the rotor seats flat, fit the rotor, reinstall the caliper, and bed the brakes with a series of moderate stops to lay an even transfer layer on the pads. Skip the bedding step and you're far more likely to end up with pulsation down the road. Do it right and this rotor will give you quiet, steady stops for a long service life.

Not sure whether you actually need new rotors? A few signs point to yes. A pulsing or shuddering pedal under braking usually means the rotors have warped or built up uneven pad deposits. A deep lip on the outer edge, scoring you can catch a fingernail on, or thickness that's dropped below the minimum stamped on the rotor all mean it's time. And any time you're doing pads, it's worth checking rotor thickness, because worn rotors chew through fresh pads fast.
