Garmin PM411LWM Pocket Mount CHIRP Transducer
Garmin PM411LWM Pocket Mount CHIRP Transducer — Product description
The Garmin PM411LWM is a deep-water CHIRP transducer built for offshore boats. Pocket-mount design, 2 kilowatts of power, and a reach down to 4,000 feet when your sounder can drive it. Two CHIRP bands cover everything from hard bottom to bait up in the column.
The PM411LWM is a serious offshore transducer for boats that fish deep. It's a pocket-mount design, so it sits flush in a transducer pocket on the hull and reads clean at speed. Part number 010-13381-00, built to handle 2 kilowatts and reach down to 4,000 feet when you've got the sounder to drive it.
This one covers two CHIRP bands. Low runs 40 to 60 kHz for deep water and hard bottom returns. High wide runs 80 to 130 kHz for detail and target separation up in the water column. The 40 degree beam gives you a wide look at what's under the boat, which matters when you're marking bait and fish offshore.
It ships with bare wires and a 49 foot cable, so you'll match it to the right connector for your CHIRP sounder or black box. That's a rigging job, not plug-and-play, but it gives you flexibility on the run. Built for offshore center consoles and sportfishers that spend real time in deep water.
Key Features
- Pocket-mount design sits flush in the hull for clean readings at speed
- 2 kilowatt power rating reaches down to 4,000 feet in deep water
- Dual CHIRP bands: 40 to 60 kHz low and 80 to 130 kHz high wide
- 40 degree beam angle for a wide view of bait and fish under the boat
- 49 foot cable with bare-wire termination to match your CHIRP sounder or black box
Why Buy from NVN Marine
- Authorized GARMIN ELEC. reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | Pocket Mount CHIRP Transducer, 4000 Foot Maximum Depth, 40 To 60 kHz CHIRP Low and 80 To 130 kHz CHIRP High Wide, 40 Degree Beam Angle, 2 Kilowatt Power, 49 Foot Cable, Bare Wires |
|---|---|
| Brand | Garmin |
| Manufacturer Part Number | 010-13381-00 |
| UPC | 753759333751 |
| Model | PM411LWM |
| Mount Type | Pocket Mount |
| Cable Termination | Bare Wires |
| Maximum Depth | 4,000 feet |
| CHIRP Low Frequency | 40 to 60 kHz |
| CHIRP High Wide Frequency | 80 to 130 kHz |
| Beam Angle | 40 degrees |
| Power Rating | 2 kW |
| Cable Length | 49 feet |
Frequently asked questions
How deep will this transducer read?
Up to 4,000 feet, given a compatible high-power CHIRP sounder to drive it. The PM411LWM carries a 2 kilowatt power rating.
What CHIRP frequencies does it cover?
Two bands. Low sweeps 40 to 60 kHz for deep water and hard bottom. High wide sweeps 80 to 130 kHz for detail and target separation.
How does it mount?
It's a pocket-mount transducer, so it sits flush in a transducer pocket on the hull. That keeps it reading cleanly even at cruising speed.
Does it come with a connector?
No. It ships with bare wires and a 49 foot cable, so you'll wire it to the right connector for your CHIRP sounder or black box.
