Egis MaxiBus 6250-208 250A Bus Bar
Egis MaxiBus 6250-208 250A Bus Bar — Product description
The Egis MaxiBus is a 250-amp power distribution bus for the Egis FLEX system. Two 5/16-inch main studs handle your heavy feeds, and eight #10 screw terminals land the smaller branch circuits, all in one tidy block with stainless hardware and a clear protective cover.
The Egis MaxiBus is a 250-amp power distribution bus built for the Egis FLEX system. You get two 5/16-inch main studs for your heavy feeds, the battery line and the main ground or a big inverter run, plus eight #10 screw terminals for the smaller circuits branching off. It's a clean way to land a lot of wires in one spot on the boat.
The hardware is stainless steel and self-locking, so it won't back off with engine vibration or a season of pounding across chop. That matters on a bus carrying real current. A loose stud is a hot stud. The included transparent cover snaps on with break-away tabs, which means you can pop it for a quick visual inspection without pulling the whole thing apart, and it keeps a dropped tool or a stray wire from shorting across the terminals.
Good fit for rigging a helm, a battery shelf, or an accessory panel where you need both high-current studs and a row of switched or fused circuits in a single block. It mounts as part of a FLEX layout or on its own.
Key Features
- 250-amp rating handles main battery, ground, and inverter-class feeds in one block
- Dual 5/16-inch studs for heavy-gauge primary connections
- Eight #10 screw terminals for branch and accessory circuits
- Stainless steel self-locking hardware stays tight through vibration
- Transparent cover with break-away tabs for quick inspection and short protection
Why Buy from NVN Marine
- Authorized Egis Mobile Electronics reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | EGIS MaxiBus - Dual 5/16" Studs +8 Circuits (#10) - 250 Amp Retail Pack |
|---|---|
| Brand | Egis Mobile Electronics |
| Manufacturer Part Number | 6250-208 |
| UPC | 850067590378 |
| Amperage Rating | 250 Amp |
| Main Studs | Dual 5/16" |
| Auxiliary Circuits | 8 x #10 |
| Hardware | Stainless Steel Self-Locking |
| Cover | Protective transparent cover with break-away tabs |
| System Compatibility | Egis FLEX System |
| Category | Electrical |
| Packaging | Retail Pack |
Frequently asked questions
How much current can the Egis MaxiBus handle?
It's rated for 250 amps across the main dual 5/16-inch studs, so it's sized for primary battery, ground, and inverter-class feeds.
How many circuits can I connect?
Two 5/16-inch main studs plus eight #10 screw terminals, giving you both heavy-current and branch connections on one bus.
Does it come with a cover?
Yes. A protective transparent cover is included. It snaps on with break-away tabs so you can lift it for inspection without removing the whole unit.
Is the hardware corrosion resistant?
The MaxiBus uses stainless steel self-locking hardware, which holds its torque through vibration and stands up to salt and spray.
