Coleman-Mach 10 15,000 BTU RV Rooftop Air Conditioner, White
Coleman-Mach 10 15,000 BTU RV Rooftop Air Conditioner, White — Product description
The Coleman-Mach 10 puts 15,000 BTU of cooling on your RV roof in a low-profile top-mount unit. It drops into a standard 14 by 14 inch vent opening, runs on 120 volt shore or generator power, and finishes in textured white to blend with most rigs.
If your rooftop air is tired or you're building out a rig from scratch, the Coleman-Mach 10 is the workhorse a lot of RVers reach for. It's a 15,000 BTU cooling-only unit built for the standard 14 by 14 inch roof vent opening, so it drops into the hole most trailers and motorhomes already have.
Power is straight 120 volt, and the compressor pulls about 14.4 amps once it's running, so plan your generator or shore hookup accordingly. This is a top and down mount design finished in textured white to sit clean on the roof line.
Two things to know before you order. There's no heat pump and no condensate pump on this model, so it cools and that's it. And the ceiling assembly plus the thermostat aren't in the box. You order those separately to match your ducted or non-ducted setup. At 82 pounds it's a two-person job to set on the roof, but once it's bolted down and sealed, it's a straightforward swap.
Key Features
- 15,000 BTU cooling capacity keeps larger RVs and fifth wheels comfortable in summer heat
- Fits standard 14 in x 14 in roof vent openings for a direct drop-in replacement
- 120 volt power with a 14.4 amp compressor draw, runs on shore power or a properly sized generator
- Top and down mount design works with both ducted and non-ducted ceiling assemblies (sold separately)
- Textured white finish sits clean on the roof line and holds up to sun and weather
Why Buy from NVN Marine
- Authorized COLEMAN RVP reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | Coleman-Mach 10 15,000 BTU RV Rooftop Air Conditioner, Textured White |
|---|---|
| Brand | COLEMAN RVP |
| Manufacturer Part Number | 35204-0762 |
| UPC | 755790008827 |
| Weight | 82 Pounds |
| Package Dimensions (L x W x H) | 37.8 in x 27.9 in x 11.9 in |
| Cooling Capacity | 15000 BTU |
| Voltage | 120 Volt |
| Compressor Draw | 14.4 Amp |
| Mount Design | Top / Down Mount |
| Fits Vent Opening | 14 Inch x 14 Inch |
| Color | Textured White |
| Heat Pump | None (cooling only) |
| Condensate Pump | None |
Frequently asked questions
Will this fit my existing roof opening?
It's built for the standard 14 by 14 inch vent opening, which is what most RVs and trailers use. If your current air conditioner sits in a 14 by 14 hole, this drops right in.
Does the Coleman-Mach 10 include a thermostat and ceiling assembly?
No. The ceiling assembly and thermostat are ordered separately so you can match your ducted or non-ducted setup. Plan on adding both to complete the install.
Is this a heat pump, and does it have a condensate pump?
Neither. This model is cooling only, with no heat pump and no condensate pump. If you need heat, you'd pair it with your RV furnace or step up to a heat-pump model.
What kind of power does it need?
Standard 120 volt. The compressor draws about 14.4 amps running, so a 30 amp service or a properly sized generator handles it fine.
How much does it weigh?
About 82 pounds. It's a two-person lift to get it up on the roof, so grab a hand before you start.
