Camco 55433 PowerGrip 30A to Dual 15A Y-Adapter
Camco 55433 PowerGrip 30A to Dual 15A Y-Adapter — Product description
The Camco 55433 PowerGrip adapter takes the single 30-amp plug on your generator and splits it into two standard 15-amp household outlets. It's a simple, non-locking Y-adapter that lets you run a couple of everyday 120-volt cords straight off a 30-amp source. CSA approved and built for the generator bag.
If you run a portable generator, you've probably hit this wall. The generator's got a 30-amp outlet sitting right there, but everything you actually want to plug in, a work light, a battery charger, a fan, a phone brick, ends in a regular household plug. The Camco 55433 PowerGrip adapter bridges that gap. It takes the single 30-amp generator plug and splits it into two standard 15-amp household receptacles, so you can run a couple of everyday 120-volt loads straight off the generator without hunting for the right cord.
The shape is a simple Y. One 30-amp male end goes into the generator, or any 30-amp source with a matching non-locking outlet, and the body branches into two 15-amp female outlets. Plug in two things, done. It's the kind of adapter you toss in the generator bag and forget about until the day you really need it, which is usually the day the power's out and you've got a cooler and a couple of lights to keep running.
Camco built this one into their PowerGrip line, the same family of RV and generator power adapters you'll find on dealer shelves and parts counters. The connectors use solid blades and a molded housing that stands up to being dragged in and out of a storage bin season after season. This particular model comes without the oversized plug-head grip handle, so it's a compact, no-frills Y that stays out of the way when it's hanging off the side of a generator.
A few things worth knowing before you buy. This is a non-locking adapter. The 30-amp end uses straight blades, not a twist-lock collar, so it matches the common non-locking 30-amp outlet you'll see on most portable generators and RV power pedestals, often called a TT-30. If your generator has a round twist-lock 30-amp outlet instead, this won't be the right fit. Check the outlet on your unit first.
It's also not waterproof. The housing isn't sealed against rain or spray, so keep it dry. Use it under an awning, inside a garage, on a covered porch, or anywhere the connection stays out of the weather. That's standard practice for any non-sealed power adapter, and it keeps everything safe and corrosion-free.
On the safety side, the 55433 is CSA approved, which means it's been tested and certified to recognized North American electrical safety standards. That matters when you're moving real current through a connection. One thing this adapter does not add is overcurrent or ground-fault protection. It's a passive splitter, so the circuit protection still comes from your generator's breaker and whatever ground-fault protection the source outlet provides. If you're powering sensitive gear or working around damp ground, plug into a protected outlet upstream.
Load is the other thing to keep in your head. You've got two 15-amp outlets hanging off a 30-amp source, so there's plenty of headroom for normal household loads. Just don't try to pull more than the generator's 30-amp circuit can give across both outlets at once. Spread a heavy load, say a space heater on one side, across the two outlets rather than piling everything onto one, and you'll keep the connection cool and happy.
Who's this for? RVers who want to run a couple of 120-volt accessories off a generator at a dry camp. Homeowners with a portable generator for storm backup who need to split that 30-amp outlet into usable household plugs. Jobsite crews, tailgaters, anybody with a generator that has a 30-amp outlet and a handful of ordinary cords to plug in. It's a cheap, simple piece of gear that solves a specific, annoying problem, and it does it without any fuss.
If your setup is the other way around, meaning you're trying to power a 30-amp RV from two 15-amp house outlets, this isn't that adapter. This one sends power out of a 30-amp source and into two 15-amp plugs, not the reverse. Match the direction to your situation and you'll be set.
Key Features
- Splits a single 30-amp generator plug into two 15-amp household receptacles for running everyday 120-volt gear
- Y-type design with one male 30-amp input and two female 15-amp outputs
- Non-locking straight blades match the common 30-amp generator and RV pedestal outlet
- Molded housing and solid blades hold up to repeated plug-and-unplug cycles in a generator bag
- CSA approved to recognized North American electrical safety standards
- Compact build with no oversized grip handle, so it stays out of the way on the generator
- Passive splitter needs no wiring or tools, just plug the 30-amp end in and go
- Part of Camco's PowerGrip line of RV and generator power adapters
Why Buy from NVN Marine
- Authorized Camco reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | Adapt 30 Amp Generator Plug Receptacles To Two 15 Amp Receptacles; Y-Type; Non Locking; Not Waterproof; Without Plug Head Handle; CSA Approved; With English Language Packaging |
|---|---|
| Brand | Camco |
| Manufacturer Part Number | 55433 |
| UPC | 014717554336 |
| Product Line | PowerGrip |
| Adapter Type | Y-Type |
| Input Connector | 30 Amp generator plug (male) |
| Output Receptacles | Two 15 Amp receptacles (female) |
| Locking | Non-Locking |
| Weatherproof | Not Waterproof |
| Plug Head Handle | Without Plug Head Handle |
| Safety Certification | CSA Approved |
| Packaging | English Language Packaging |
Frequently asked questions
What does the Camco 55433 actually do?
It takes a single 30-amp generator plug and splits it into two standard 15-amp household outlets, so you can run two ordinary 120-volt cords off your generator's 30-amp receptacle.
Which way does the power flow?
Out of the 30-amp source and into the two 15-amp outlets. You plug the 30-amp male end into your generator, then plug two regular appliances into the 15-amp outlets. It isn't meant for combining two 15-amp house outlets into one 30-amp supply.
Will it fit my generator's 30-amp outlet?
It fits the common non-locking straight-blade 30-amp outlet, the same style found on most portable generators and RV power pedestals. If your generator uses a round twist-lock 30-amp outlet, this adapter won't match, so check your outlet first.
Can I use this in the rain?
No. It's not waterproof, so keep the connection dry and under cover. Use it in a garage, under an awning, or anywhere out of the weather.
Does it have GFCI or breaker protection built in?
No. It's a passive splitter with no overcurrent or ground-fault protection of its own. Your protection comes from the generator's breaker and any ground-fault protection on the source outlet. Plug into a protected outlet when you're near damp ground or powering sensitive gear.
How much can I run through it?
The two 15-amp outlets share whatever the 30-amp source can supply, so there's plenty of room for normal household loads. Just don't exceed the generator's 30-amp rating across both outlets, and spread heavy loads across the two outlets instead of piling everything onto one.
Is it a locking adapter?
No, it's non-locking with straight blades. It plugs in and pulls out like a standard plug rather than twisting to lock.
Does it have a grip handle?
This model comes without the oversized plug-head grip handle, which keeps it compact. The blades and molded body are still easy to grab for plugging and unplugging.
Is it safety certified?
Yes, it's CSA approved, which means it's been tested to recognized North American electrical safety standards.
