Attwood 12127-3 8-Inch Aluminum Boat Cleat, Black
Attwood 12127-3 8-Inch Aluminum Boat Cleat, Black — Product description
The Attwood 12127-3 is an 8-inch open-base rope cleat cast from aluminum and finished in black. It's sized for small boats and docks, a clean, corrosion-resistant place to make off a dinghy painter, a spring line, or a fender. Comes with two 1/4-inch fasteners and mounts in minutes.
A cleat is one of those parts you don't think about until you need it, and then it's the only thing standing between your boat and the current. The Attwood 12127-3 is an 8-inch open-base cleat cast from aluminum and finished in black. It's sized for small boats and dock edges, the spots where you're tying off a dinghy, a jon boat, a bow line, or a spring line and you want something solid to wrap around. Attwood has been building marine hardware for over a hundred years, and this is the kind of no-drama part that shows why.
The open base is the detail worth calling out. Instead of a solid casting that sits flush to the deck, the open design lifts the horns up on legs with a gap underneath. That spreads the load across a wider footprint for the same length, so the pull works against more of your mounting surface instead of concentrating on one small pad. It also gives you a second way to run a line. You can pass a rope under the horns and through the base when you need to. For an 8-inch cleat, that's a nice bit of extra holding for almost no extra weight.
Cast aluminum keeps the weight down, and that matters on a small boat where everything you bolt to the rail adds up. The black powder-coat finish does two jobs at once. It looks clean against a white hull or a weathered dock, and it lays a barrier over the aluminum so salt spray and rain have a harder time getting a foothold. Aluminum already handles life on the water well, and the coating buys you more time before you'd ever see chalking or pitting. Rinse it when you rinse the rest of the boat and it'll stay sharp for years.
Mounting is straightforward. The cleat comes with two 1/4-inch fasteners, and the two holes sit at the standard spacing you'd expect for a cleat this size. On a boat, back it up. Use a backing plate, or at least oversized fender washers on the underside, so the load pulls against a wide area of the deck instead of trying to tear through the gelcoat. A cleat is only as strong as what it's bolted to, and the quickest way to rip one out is to run bolts through thin fiberglass with nothing behind them. On a wood dock, through-bolts or lag screws into solid framing do the same job.
Who's it for? Anglers rigging a jon boat or a small aluminum skiff. Dock owners who want a tidy place to make off the dinghy. Anybody adding a spare cleat for a spring line or a fender. Eight inches is a common, useful size, big enough to take a real wrap of 1/2-inch or 5/8-inch line and small enough that it stays out of the way. Learn a proper cleat hitch, a couple of figure-eights finished with a locking hitch, and this little casting will hold a surprising amount of boat.
One thing to keep in mind. This is a small-boat and dock cleat, not a bow cleat for a 30-footer taking anchor loads offshore. Match the cleat to the job. For a dinghy painter, a dock line on a floating dock, a kayak trailer tie-down, or a light utility boat, the 8-inch aluminum casting is right in its wheelhouse. Step up in size, and to heavier hardware, when you're loading a bigger hull or leaving a boat on a mooring through weather. Used within its range, it's a clean, honest piece of gear that does exactly what a cleat should do and then gets out of the way.
A quick note on sizing and count. The base measures about 1-1/16 inches wide, so it drops onto standard small-boat and dock-board spacing without a fuss. And it's sold as a single cleat, not a pair, so if you're doing bow and stern, or both corners of a dock, just order the number you actually need.
Key Features
- 8-inch overall length, sized right for small boats, dinghies, and dock edges where a full-size bow cleat would be overkill.
- Open-base casting spreads the load over a wider footprint and gives you a second path to run a line under the horns.
- Cast aluminum construction keeps weight low, easy on a small boat's rails and deck.
- Black powder-coat finish over the aluminum resists salt spray, rain, and chalking for years with a simple rinse.
- Includes two 1/4-inch fasteners, so you can mount it straight out of the package.
- Base about 1-1/16 inches wide, fits standard cleat spacing on small-boat decks and dock boards.
- Sold as a single cleat, so you order the exact count you need for bow, stern, or both sides of a dock.
- Backed by Attwood, a marine hardware maker with over a century in the business.
Why Buy from NVN Marine
- Authorized Attwood Marine reseller, full manufacturer warranty
- NMEA member and ABYC certified, advice from real boat techs
- Same-day shipping before 3 PM ET on in-stock items
- NY headquarters and Fort Lauderdale flagship retail store
Technical specifications
| Title | Attwood 12127-3 Aluminum Boat Cleat, 8-Inch, Open Base, Black |
|---|---|
| Brand | Attwood Marine |
| Manufacturer Part Number | 12127-3 |
| UPC | 022697002310 |
| Overall Length | 8 Inch |
| Base Width | 1-1/16 Inch |
| Material | Cast Aluminum |
| Color | Black |
| Base Type | Open Base |
| Included Fasteners | Two 1/4 Inch |
| Application | Small Boats and Docks |
| Sold As | Single |
| Packaging | Aftermarket Packaging |
Frequently asked questions
What size boats is this cleat made for?
It's an 8-inch cleat sized for small boats and docks, dinghies, jon boats, small skiffs, and dock edges where you're tying off a painter, a spring line, or a fender. For bigger hulls taking heavier loads, step up to a larger cleat.
Is this an open-base or closed-base cleat?
Open base. The horns sit up on legs with a gap underneath, which spreads the load over a wider footprint and lets you run a line under the horns and through the base when you need to.
What's it made of, and will it hold up in saltwater?
It's cast aluminum with a black powder-coat finish. Aluminum handles the marine environment well on its own, and the coating adds a barrier against salt spray and rain. Give it a rinse when you wash the boat and it'll stay clean for years.
Does it come with mounting hardware?
Yes. It includes two 1/4-inch fasteners. On a boat we still recommend adding a backing plate or oversized fender washers underneath so the load pulls against a wide area of the deck.
How do I mount it so it won't pull out?
Back it up. On fiberglass, use a backing plate or large fender washers under the deck so the fasteners aren't loading bare gelcoat. On a wood dock, through-bolt or lag into solid framing. A cleat is only as strong as what it's bolted to.
What are the dimensions?
It's 8 inches long with a base about 1-1/16 inches wide, a common size that fits standard small-boat and dock-board fastener spacing.
Is this sold as a single cleat or a pair?
A single cleat. If you're rigging bow and stern, or both corners of a dock, order the count you need.
What line size works best with it?
An 8-inch cleat takes a comfortable wrap of roughly 1/2-inch to 5/8-inch line. Tie it off with a proper cleat hitch, a few figure-eights finished with a locking turn, and it'll hold well.
