Ancor 270400 NMEA 2000 Network Cable Kit Assortment

If you're wiring up an NMEA 2000 network from scratch, or filling out one you already run, the Ancor 270400 gets you most of the way there in a single box. It's what Ancor calls a plan-o-gram assortment. In plain terms, that's a curated grab-bag of the core NMEA 2000 building blocks: backbone cable, a power cable with a tee, drop cables, tee and inline connectors, terminators, and a single-device starter kit. Instead of chasing ten separate part numbers across three order screens, you get one of each key piece and start rigging.

Here's what's in the box. One 270000 1-meter power cable with tee, which is how you feed 12-volt power into the middle of your backbone. One 270010 10-meter backbone cable, the color-coded trunk line that every device drops off of. One 270101 single tee connector for adding a device. One 270105 female terminator and one 270106 male terminator, the pair that caps both ends of the backbone. One 270109 female and one 270110 male field-serviceable connector, so you can build custom-length runs on the boat instead of ordering a fixed cable. One 270201 single-device starter kit. And two drop cables, a 270301 1-meter and a 270305 5-meter, for reaching instruments that sit away from the trunk.

The power conductors are 22 AWG and super flexible, which matters more than it sounds when you're feeding cable through a stuffed lazarette or around a tight console corner. The fittings are NMEA 2000 approved, so this gear talks to any certified sensor, display, or engine gateway you hang off the network, no matter whose badge is on it. That's the whole point of the standard. One backbone, one language, every brand of instrument playing nice.

Who's this for? Boat riggers and installers who want a ready assortment on the bench. DIY owners building a first network on a center console or a cruiser. And anyone who wants a sensible spares kit aboard, because a terminator or a tee is exactly the five-dollar part that strands you at the worst time. The 10-meter backbone covers a lot of boats, and the two terminators and the tee mean you can light up a working network the day it arrives.

A couple of honest install notes. Put the power tee near the center of your backbone, not out at one end. NMEA 2000 feeds power from the middle so voltage drops evenly to both sides, and a power feed way out at an end is the classic cause of instruments dropping offline on a longer boat. Both terminators go at the literal ends of the backbone, one female, one male, and you need both. A backbone missing a terminator throws constant errors on the display even when every device looks wired right. And if your battery switch sits far from the run, that 1-meter power cable can come up short. It's easy to extend with a longer Ancor power cable, so plan the feed point before you commit.

The 5-meter drop cable and the field-serviceable connectors are the pieces that make this assortment flexible. Drop cables reach instruments mounted away from the trunk, and NMEA 2000 allows drops up to 6 meters, so the 5-meter piece handles a flybridge helm or a bow-mounted sensor without splicing. The field-serviceable connectors let you cut a run to length and terminate it yourself, which is how the pros get clean, tucked-away wiring instead of a coil of excess cable behind the dash.

Bottom line: it's a complete, no-guesswork starting point for an NMEA 2000 network, backed by Ancor's marine-grade cable and our authorized-reseller warranty. Build it, expand it, or keep it aboard as spares. Either way you're not stuck waiting on a single missing connector.
