Navico 120WX Ultrasonic Wind Sensor w/6m Cable Product Description
Discover Reliable Weather Monitoring for Your Vessel
Equip your powerboat with cutting-edge marine weather technology that delivers precise wind data without the hassle of mechanical components. This ultrasonic wind sensor stands out by combining solid-state wind measurement with essential environmental readings, all in a compact, rugged design built to withstand harsh marine conditions. Perfect for boaters who prioritize accuracy and simplicity, it provides real-time insights into wind speed, direction, air temperature, and barometric pressure—helping you make informed decisions on the water.
How Ultrasonic Technology Revolutionizes Wind Measurement
Unlike traditional anemometers with spinning cups or vanes that wear out over time, this sensor uses advanced ultrasonic transducers to detect wind flow. Sound waves travel between pairs of transducers, and the time-of-flight differences calculate both speed and direction with exceptional precision. This no-moving-parts approach ensures long-term reliability, even in salty, windy environments where mechanical failure is common. You'll get both apparent wind readings tailored for stationary setups, making it ideal for docks, marinas, or anchored vessels.
The integrated sensors also track air temperature for wind chill calculations and barometric pressure to anticipate weather shifts, giving you a complete picture without multiple devices cluttering your setup.
Key Features Tailored for Marine Use
- Ultrasonic Wind Detection: Accurate speed and direction without cups or vanes—superior for reliability in tough conditions.
- Comprehensive Sensors: Includes air temperature, barometric pressure, and wind chill for holistic weather awareness.
- Robust Build: IPX6-rated waterproofing protects against heavy rain and spray; compact housing fits tight spaces.
- Power Efficiency: Reduced current draw and wide 9-40 VDC range suit battery or solar-powered systems.
- Flexible Outputs: Single-cable NMEA2000 interface with Micro-C connectors for seamless integration.
- Advanced Options: Supports adjustable unfiltered data for gust monitoring; optional add-ons like humidity or heaters available.
Effortless Installation and NMEA2000 Compatibility
Setting up wind monitoring has never been simpler. The included 6-meter cable plugs directly into your NMEA2000 backbone using standard Micro-C connectors—no custom wiring required. Compatible with popular marine electronics from brands like Simrad, Lowrance, and B&G, it broadcasts data via standard PGNs, instantly populating your multifunction display with wind overlays, weather trends, and alerts.
Boaters appreciate the plug-and-play nature: mount it on a pole or rail, connect the cable, and start receiving data. Its low-profile design minimizes wind shadow effects, ensuring readings reflect true conditions around your boat.
Why Boaters Choose This Weather Sensor
In the world of marine navigation, knowing the wind is crucial for safe anchoring, sail trimming (even on powerboats for planning), or simply enjoying time on the water. This sensor excels where space is limited and reliability matters most—think coastal cruising, fishing charters, or liveaboards. Its solid-state construction outlasts mechanical alternatives, reducing maintenance and downtime. Plus, the affordability makes professional-grade weather data accessible without breaking the bank.
Real-world users report pinpoint accuracy during sudden gusts or pressure drops, helping avoid surprises like building storms. Whether you're monitoring from the helm or remotely via networked apps, it empowers confident boating every trip.
Frequently Asked Questions
What makes ultrasonic wind sensors better for boats?
Ultrasonic sensors have no moving parts, so they resist corrosion, icing, and wear from constant exposure to salt air and waves. This leads to higher uptime and accuracy compared to cup or vane styles.
Does it measure true or apparent wind?
For stationary applications, it provides apparent wind speed and direction, which is ideal for moored or docked boats. No boat speed input is needed, keeping setup simple.
Is it compatible with my existing chartplotter?
Yes, it uses standard NMEA2000 PGNs and Micro-C connectors, working seamlessly with Simrad, Lowrance, Garmin, and other NMEA2000 networks.
How waterproof is the sensor?
It carries an IPX6 rating, meaning it handles powerful water jets and heavy seas without issue, perfect for marine environments.
Can I add humidity or heating options?
Relative humidity is available via a removable, field-serviceable module (IPX4 rated with it installed), and a heater option prevents icing in cold climates.
What's the cable length, and can it be extended?
It comes with a 6-meter cable standard. For longer runs, use NMEA2000 extension cables or drop cables to reach your backbone.
Simrad 120WX Weather Sensor Measures Wind Speed and Direction, Temperature, and Barometric Pressure Reliability and superior accuracy, along with no moving parts and plug and play installation, makes the 120WX an easy and affordable choice for any weather solution. The Airmar WX Weather Station instruments are unique, as they are the only weather monitoring system to offer true and apparent wind speed and direction in one compact housing-without the need for additional sensors. Ideal for stationary applications, the 120WX model offers apparent wind speed and direction, air temperature, and barometric pressure readings.
Simrad 0011741001 Attributes
- Number Of Cups: Without Cups
- Color: White
Simrad 0011741001 Features & Benefits
- Provides Accurate And Reliable Measures Of Wind Speed And Direction
- IPX6 Waterproof Rating
- Feature Rich In A Durable, Rugged, Small Housing
- Reliability And Performance, Along With No Moving Part
- No Supplier Warranty
Simrad 0011741001 Warranties
120WX Ultrasonic Wind Sensor with 6M Cable
Aimed at powerboats that require awareness of wind strength and direction, this sensor combines ultrasonic wind sensors together with air temperature and barometric pressure sensors. This is particularly useful where space does not permit the installation of a wind vane.
Sensor uses standard PGNs and comes with MicroC connectors enabling easy connection to an NMEA2000 backbone.
The 120WX offers a truly best-in-class solution at a better price point than any other weather monitoring system on the market today.
Reliability and superior accuracy, along with no moving parts and plug and play installation, makes the 120WX an easy and affordable choice for any weather solution. The Airmar WX WeatherStation® instruments are unique, as they are the only weather monitoring system to offer true and apparent wind speed and direction in one compact housing - without the need for additional sensors. Ideal for stationary applications, the 110WX model offers apparent wind speed and direction, air temperature, and barometric pressure readings.
The many new benefits of the WX Series include:
- Removable humidity sensor that is field serviceable
- IPX6 waterproof rating (units with the relative humidity module are IPX4 waterproof rated)
- Power supply featuring a 50% reduction in current draw for use in remote locations that use solar or battery power
- Wider operating voltage range of 9-40 VDC
- Adjustable, unfiltered wind data for monitoring maximum gust conditions
- Output via a single cable (NMEA®2000) data interface
- WeatherCaster PC software for viewing and customizing data sentences
Features
- Wind speed & direction
- Barometric pressure
- Air temperature
- Wind chill
- Ultrasonic wind readings
- Optional relative humidity
- Optional heater
The ultrasonic wind sensor is combined with the air temperature and air pressure sensor. Through a single cable NMEA2000 data interface output.
Frequently Asked Questions (FAQ) About Navico 120WX Ultrasonic Wind Sensor w/6m Cable
Who is the Navico?How to describe Navico 120WX Ultrasonic Wind Sensor w/6m Cable?
What's the color of Navico 120WX Ultrasonic Wind Sensor w/6m Cable?
What is the instrument function of the product?
Who is the Navico?
How to describe Navico 120WX Ultrasonic Wind Sensor w/6m Cable?
- 120WX Ultrasonic Wind Sensor with 6M Cable
- Aimed at powerboats that require awareness of wind strength and direction, this sensor combines ultrasonic wind sensors together with air temperature and barometric pressure sensors. This is particularly useful when sailing in turbulent seas or estimating the likelihood of a storm brewing.
- Powerboats need this to make sure they're sailing in the right direction.
- With this sensor, you'll know beforehand if it's safe to sail or if it's time to turn back.
- This device is a must-have for sailors of all levels.
- 120WX Ultrasonic Wind Sensor with 6M Cable
- Aimed at powerboats that require awareness of wind strength and direction, this sensor combines ultrasonic wind sensors together with air temperature and barometric pressure sensors. This is particularly useful for those who need to monitor the weather conditions before setting sail.
- The sensor's high sensitivity enables it to detect the slightest changes in the wind, even if it's just a light breeze.
- It also calculates the direction of the wind by measuring its angle relative to magnetic north.
What's the color of Navico 120WX Ultrasonic Wind Sensor w/6m Cable?
- 120WX Ultrasonic Wind Sensor with 6M Cable
- Aimed at powerboats that require awareness of wind strength and direction, this sensor combines ultrasonic wind sensors together with air temperature and barometric pressure sensors. This is particularly useful when sailing in turbulent seas or estimating the likelihood of a storm brewing.
- Powerboats need this to make sure they're sailing in the right direction.
- With this sensor, you'll know beforehand if it's safe to sail or if it's time to turn back.
- This device is a must-have for sailors of all levels.
- 120WX Ultrasonic Wind Sensor with 6M Cable
- Aimed at powerboats that require awareness of wind strength and direction, this sensor combines ultrasonic wind sensors together with air temperature and barometric pressure sensors. This is particularly useful for those who need to monitor the weather conditions before setting sail.
- The sensor's high sensitivity enables it to detect the slightest changes in the wind, even if it's just a light breeze.
- It also calculates the direction of the wind by measuring its angle relative to magnetic north.
What is the instrument function of the product?
Save $226 when you buy the Navico 120WX Ultrasonic Wind Sensor w/6m Cable for only $722 from NVN Marine! Same day shipping before 3pm.
Navico 120WX Ultrasonic Wind Sensor w/6m Cable Technical Specifications
| Type: | |
|---|---|
| Vendor: |
Navico |
| Weight: |
2.6 lb |
| Instrument Function: |
Wind |
