Scanstrut LMB-F1 Self Leveling Radar Mount - Backstay (F) - f/ 2kW 4kW Raymarine/Garmin Domes Product Description

Forward of backstay

Scanstrut LMB-F1 Self-Leveling Backstay Radar Mount - Professional Forward-Leaning Marine Radar Solution

Maximize your radar performance with the Scanstrut LMB-F1 Self-Leveling Backstay Radar Mount, the ultimate marine radar mounting solution for sailing vessels. This innovative forward-leaning backstay mount keeps your 2kW-4kW Raymarine or Garmin radar dome perfectly level with the horizon, ensuring optimal antenna performance and crystal-clear radar images regardless of heel angle or sea conditions.

Advanced Self-Leveling Technology

  • Hydraulic Damping System: Fine-tuned hydraulic system reacts to major heel changes while eliminating minor oscillations
  • Passive Operation: Completely maintenance-free with no electrical power required
  • Optimal Performance: Maintains radar horizontal orientation preventing target loss and signal degradation
  • Forward Mounting: 2.6m (8'6") height positions radar away from interference and clears deck space
  • Universal Compatibility: Engineered for Raymarine, Garmin, and B&G radar domes up to 4kW

Technical Specifications

Installed Height: 2.6m (8.5 feet)
Mounting Direction: Forward Leaning
Construction: Anodized Aluminum
Base Dimensions: 55mm x 43.5mm (2.2" x 1.5")
Exterior Color: White
Backstay Compatibility: 7mm, 8mm, 10mm, 12mm diameter cables
Maximum Backstay Adjuster: 60mm diameter
Country of Origin: United Kingdom

Premium Marine Construction

  • Anodized Aluminum Pole: Finest quality machined and anodized aluminum for lifetime durability
  • 316 Stainless Steel Components: Marine-grade stainless steel cradle and base plate for corrosion resistance
  • Sealed Hydraulic System: Completely sealed and maintenance-free damping mechanism
  • Modular Design: Pole supplied in 1.3m lengths with hidden joiner for easy transport and installation
  • Integrated Cable Management: Built-in cable channel for clean, protected wiring runs

Installation Versatility

Mounting Options:

  • Deck mounting
  • Transom mounting
  • Chainplate mounting

Backstay Compatibility:

  • Standard single backstays
  • Adjustable backstays
  • Split backstays (with specific installation procedures)
  • Wire diameters from 7mm to 14mm

Extension Options:

  • Additional 0.6m extensions available
  • Additional 1.3m extensions available
  • Customizable height for optimal radar placement

Complete Installation Kit Includes

  • 1x Self-leveling mount with integral backstay bushes
  • 2x 1.3m lengths of mounting pole
  • 1x Joiner piece for mounting pole
  • 1x Universal base for mounting pole
  • 1x Complete fastening pack
  • Nylon backstay bushings (fits 7, 8, 10, and 12mm diameter cables)
  • Stainless radome cradle with fine-tune angle adjustment

Radar System Compatibility

Raymarine Radar Domes:

  • 2kW dome radars
  • 4kW dome radars
  • Quantum series radars

Garmin Radar Domes:

  • GMR series 2kW-4kW domes
  • xHD series radar domes
  • Fantom series compact domes

B&G Radar Systems:

  • Compatible dome radar units
  • 2kW-4kW power ranges

Rigorous Marine Testing Standards

  • 30G Shock Testing: Tested to withstand forces 30 times gravity
  • 100-Hour Salt Spray: Accelerated marine environmental testing
  • IP Water Protection: Tested from IPX4 (waterjet) to IP68 (submersion)
  • Heel Angle Testing: Validated performance across sailing heel angles
  • Vibration Resistance: Engineered to eliminate minor oscillations and vibrations

Why Choose Scanstrut LMB-F1?

  • Clear Deck Space: Forward mounting eliminates deck clutter and trip hazards
  • Reduced Weight Aloft: Lightweight head unit minimizes impact on boat stability
  • No Interference: Optimal positioning away from sails and rigging for clear radar performance
  • Maintenance-Free: Sealed hydraulic system requires zero ongoing maintenance
  • British Engineering: Scanstrut's renowned quality and marine expertise
  • Easy Cable Adjustment: Nylon bushings allow backstay tension adjustment without mount removal

Professional Installation Guidelines

  • Backstay Assessment: Verify backstay diameter and adjuster compatibility
  • Mounting Location: Choose optimal base mounting position for load distribution
  • Cable Routing: Plan cable runs through integrated management system
  • Extension Planning: Determine if additional pole sections needed for height clearance
  • Fine Tuning: Adjust radome cradle angle to match backstay geometry

Frequently Asked Questions

Does the LMB-F1 require electrical power to operate?

No, the LMB-F1 is a completely passive system using hydraulic damping technology. It requires no electrical power and is entirely maintenance-free.

What radar power ratings are compatible with this mount?

The LMB-F1 is designed for 2kW and 4kW radar domes from Raymarine, Garmin, and B&G. It accommodates the weight and wind load of these professional radar systems.

Can I install this mount on boats with adjustable backstays?

Yes, the LMB-F1 is compatible with adjustable backstays. The nylon bushings allow cable tension adjustment without removing the mount, and the system accommodates backstay adjusters up to 60mm diameter.

How does the self-leveling system work in rough seas?

The fine-tuned hydraulic damping system responds to major heel angle changes while filtering out minor oscillations and vibrations. This ensures your radar remains level for optimal performance even in challenging sea conditions.

Can the mount height be customized?

Yes, while the standard kit provides 2.6m height, additional 0.6m and 1.3m extension sections are available separately to achieve optimal radar placement height for your specific vessel.

Model Number: LMB-F1

UPC: 5060114790940

Manufacturer: Scanstrut

Category: Boat Outfitting | Radar/TV Mounts

Self-Levelling Radar Mount - Backstay - Fwd (F) - Made Specifically for Raymarine & Garmin Domes

Our Self-Levelling Backstay Mount ensures your radar stays level with the horizon at all times for optimum antenna performance. As the boat heels or rolls, the radar is kept horizontal preventing target loss and giving the best possible radar picture.

Using our own fine-tuned hydraulic damping system, the radar mount reacts to major changes in heel angle of the boat whilst eliminating all small oscillations.

Features:

  • Hydraulic damping to eliminate minor oscillations
  • Sealed system - entirely maintenance free
  • Passive system - no power required
  • Lightweight head unit - reduced weight aloft
  • Stainless radome cradle with fine tune adjustment for backstay angle - suitable for any yacht
  • Nylon backstay bushing supplied - clamps around backstay allowing cable tension to be adjusted

Dimensions:

  • 2.6m pole - supplied in lengths of 1.3m
  • Additional 0.6m and 1.3m lengths available

Materials:

  • Finest quality machined an anodised aluminum pole and head unit - lasts the lifetime of your yacht.
  • Marine grade 316 stainless steel cradle and base plate

Kit includes:

Scanstrut LMB-F1 Self Leveling Radar Mount - Backstay (F) - f/ 2kW 4kW Raymarine/Garmin Domes Technical Specifications

Type:

Boat Outfitting | Radar/TV Mounts

Vendor:

Scanstrut

Weight:

28.0 lb

Construction:

Anodized Aluminum

Type:

Self Leveling

User Guide:

Download PDF

Product Installation:

Download PDF
