EGIS RT Fuse Block 8 Circuit with Cover
Shipping (3PM)
Within 30 days
EGIS RT Fuse Block 8 Circuit with Cover Product Description
Upgrade your boat's electrical system with a fuse block that stands up to the harshest marine conditions. This compact 8-circuit inline design simplifies wiring in tight spaces while delivering rock-solid protection for your critical electronics, lights, pumps, and navigation gear. Single-side wire entry keeps installations clean and professional, reducing clutter behind panels or in engine bays.
Built for the Brutal Marine World
Every detail screams durability. High-temperature thermoplastic housing shrugs off heat, vibration, and saltwater spray. Stainless steel self-locking hardware won't corrode or loosen over time, making it ideal for offshore adventures or daily coastal runs. The latching protective cover snaps shut securely, shielding fuses from accidental contact and environmental hazards—ignition protected when closed, so it's safe even in combustible areas like engine compartments.
Customize it your way with optional weather-proof labels. Snap in standard templates or order custom prints for quick circuit identification, saving headaches during troubleshooting at sea.
Unmatched Circuit Protection
Protect each branch with standard ATO/ATC blade fuses from 1 to 40 amps. It meets SAE J1171 standards for ignition protection against short circuits and thermal overloads, giving you peace of mind when running bilge pumps, VHF radios, or trolling motors. Per-circuit continuous rating hits 30 amps, with the whole block handling up to 100 amps max—plenty for most recreational vessels.
- Prevents costly damage from overloads
- Easy fuse swaps without tools
- Supports 12V or 24V DC systems up to 60V max
Effortless Installation and Versatility
Mount it anywhere—bulkheads, overhead consoles, or battery boxes—thanks to its bullet-proof build. The M5-0.8 input terminal accepts heavy power feeds securely. In cramped helm stations, the inline layout shines, routing all wires from one side for a tidy setup. Pair it with bus bars for larger systems or use standalone for auxiliary circuits.
Boat owners rave about how it organizes chaos into reliable power distribution. Whether retrofitting an older fiberglass cruiser or wiring a new center console, this fuse block cuts install time and boosts safety.
Key Specifications
| Specification | Details |
|---|---|
| Continuous Current Per Circuit | 30 Amps |
| Maximum Current (Entire Block) | 100 Amps |
| Nominal Voltage | 12/24 VDC |
| Maximum Voltage | 60 VDC |
| Input Terminal Size | M5-0.8 |
What's Included
- Fuse block with 8 circuits
- Latching protective cover with label recesses
Note: Fuses sold separately to match your exact needs.
Frequently Asked Questions
What type of fuses does this 8-circuit fuse block accept?
It accepts standard ATO/ATC blade fuses rated from 1 to 40 amps per circuit, making it compatible with common marine and automotive spares.
Is this fuse block ignition protected for engine compartments?
Yes, when the latching cover is securely closed, it meets ignition protection standards, safe for use in combustible environments like gas engine bays.
What voltage range does it support?
Nominal 12/24 VDC systems, with a maximum of 60 VDC, perfect for most boats from small runabouts to larger yachts.
How much current can it handle per circuit and overall?
Up to 30 amps continuous per circuit, with the entire block rated for 100 amps maximum—reliable for demanding setups.
What materials make it corrosion-resistant?
High-temperature thermoplastics and stainless steel self-locking hardware ensure it withstands saltwater, UV exposure, and vibration.
Can I customize labels for the circuits?
Absolutely—the integrated label recesses in the cover work with optional weather-proof standard or custom labels for easy identification.
Is the single-side wire entry helpful for tight installs?
Yes, the compact inline design with wires entering from one side excels in confined spaces like helm panels or bulkheads.
Egis Marine 8046 RT Fuse Block 8 Circuitsm with Cover
Model: 8046- Ignition protected when latching cover is secure for use in engine bay/combustible enviroments
- Harsh Enviroment Design with stainless steel self-locking hardware and optional weather-proof labels in standard and customized options
- Includes latching protective cover with integrated label recesses.
Compact inline 8 position fuse block has single side wire entry for tight installations spaces.
Harsh Environment design with stainless steel self-locking hardware and optional weather-proof labels in standard or customized options
Protects Branch Circuits by accepting ATO style fuses ranging from 1 through 40 Amps.
Bullet-proof Construction: Designed with high temperature materials and stainless steel self-locking hardware allow mounting anywhere on vehicle.
Supports SAE Circuit Protection Standards for thermal/short circuit events.
Includes Latching Protective Cover with integrated label recesses for easy circuit/fuse identification
Specifications| CONTINUOUS CURRENT Per Circuit (AMPS) | 30 |
| Maximum Current (Entire Block) Amps | 100 |
| Nominal Voltage | 12/24Vdc |
| Maximum Voltage | 60Vdc |
| Input terminal size | M5-0.8 |
What's in the Box:
- Fuse Block
- Cover
SKU: NVN-1004384
MPN: 8046
UPC: 850067590033
