Echonautics BT87H1kW-12 1kW 130-210kHz High CHIRP 0d Tilted Element Bronze TH

SKU: 1003683 - UPC: 010407340289
$694.99 $989.00 ( / )

Available Stock : 1

Echonautics BT87H1KW 130-210kHz 1kW High CHIRP 12° Tilted ElementModel: BT87H1KW-12Superior shallow-water performance and bottom detailThe Echonautics BT87H1kW is a low-profile thru hull CHIRP transducer designed to minimize drag and to perform at high speeds.Thanks to the narrow beamwidth, it is excellent for pinpointing fish holding tight to reefs, wrecks, and...
Same Day

Shipping (3PM)

Free Returns

Within 30 days

Echonautics BT87H1kW-12 1kW 130-210kHz High CHIRP 0d Tilted Element Bronze TH Product Description

Echonautics BT87H1KW 130-210kHz 1kW High CHIRP 12° Tilted Element

Model: BT87H1KW-12
  • Superior shallow-water performance and bottom detail

The Echonautics BT87H1kW is a low-profile thru hull CHIRP transducer designed to minimize drag and to perform at high speeds.

Thanks to the narrow beamwidth, it is excellent for pinpointing fish holding tight to reefs, wrecks, and other structures.

Specifications
Function Depth and Temperature
Frequency CHIRP 130 - 210 kHz
Tilt/deadrise 12° tilted version: for 8° to 15° hull deadrise
Material Bronze
RMS Power 1 kW
Beamwidth 13° to 8° @-3db
Depth Max 304 m (1,000 ft)
Temp. sensor NTC
Acoustic window Urethane
Cable length 9 m (30 ft)
Hole diameter 87.6 mm (3.45")


Save $294 when you buy the Echonautics BT87H1kW-12 1kW 130-210kHz High CHIRP 0d Tilted Element Bronze TH for only $694 from NVN Marine! Same day shipping before 3pm.

Echonautics BT87H1kW-12 1kW 130-210kHz High CHIRP 0d Tilted Element Bronze TH Technical Specifications

Type:

Marine Navigation & Instruments | Transducers

Vendor:

ProMariner

Weight:

7.8 lb

Echonautics BT87H1kW-12 1kW 130-210kHz High CHIRP 0d Tilted Element Bronze TH User Reviews

Echonautics BT87H1kW-12 1kW 130-210kHz High CHIRP 0d Tilted Element Bronze TH Shipping & Return

Shipping Weight:

7.8 lb

Box Sizes:

(h) x (w) x (l)

Cubic Feet:

0
