Lowrance Flush Mount Kit For Elite FS 9
Lowrance Flush Mount Kit For Elite FS 9 — Product description
Seamless Integration for Your Elite FS 9 Display
Transform your boat's helm into a sleek, professional setup with this dedicated flush mount kit tailored for the Lowrance Elite FS 9. Designed for boaters who demand a clean, low-profile installation, it eliminates bulky brackets and exposed edges, creating a streamlined console that looks factory-installed. Whether you're upgrading your bass boat, center console, or offshore vessel, this kit ensures your high-resolution fishfinder sits perfectly flush, maximizing visibility while protecting the unit from harsh marine conditions.
Key Advantages of Flush Mounting
- Enhanced Aesthetics: Achieve a custom, built-in look that boosts your boat's resale value and turns heads at the dock.
- Improved Durability: Recessed mounting shields the screen from accidental impacts, UV exposure, and spray—ideal for rough waters.
- Space Efficiency: Frees up dash real estate for additional gear like radars or multifunction displays.
- Ergonomic Viewing: Positions the 9-inch display at eye level for effortless chart reading and sonar monitoring during long days on the water.
Complete Kit Contents for Easy Setup
Everything you need arrives in one package, minimizing trips to the hardware store. The kit features precision-cut stainless steel or high-grade composite bezels that match the Elite FS 9's contours exactly, along with templated gimbal covers, mounting screws, and sealing gaskets. No guesswork—just straightforward assembly that supports both standard and custom cutouts.
Pro Tip for First-Time Installers
Before cutting, double-check your console thickness; this kit accommodates panels from 1/4-inch up to 2 inches thick, common in fiberglass and aluminum dashes. Use the included paper template to trace your outline, ensuring a perfect fit on the first try.
Step-by-Step Flush Mount Installation
Installing this kit takes about 1-2 hours with basic tools like a jigsaw, drill, and screwdriver. Here's a reliable walkthrough based on real-world boating installs:
- Prep the Surface: Clean and dry your console area. Apply painter's tape over the template to prevent scratches.
- Cut the Hole: Follow the template precisely—over-cutting is a common pitfall that leads to gaps. Use a fine-tooth blade for smooth edges.
- Test Fit: Dry-fit the bezel and display to verify alignment before finalizing.
- Seal and Secure: Apply marine-grade silicone around the gasket for waterproofing, then torque screws evenly to avoid warping.
- Route Cables: Feed power, transducer, and network cables through pre-drilled rear ports for a tidy, hidden setup.
- Final Check: Power up and test all functions; adjust bezel clips if needed for a snug hold.
Bonus: For curved surfaces like newer bowriders, warm the bezel slightly with a heat gun for better conformability without cracking.
Perfect Fit for Elite FS Series and Beyond
Engineered specifically for the Elite FS 9, this kit also cross-compatibles with similar-sized Lowrance units in the lineup, making it a versatile choice for multi-display setups. It pairs seamlessly with Active Imaging transducers and Ethernet networking, ensuring no interference with your sonar performance. Boaters report zero signal loss post-install, even in high-vibration environments like tournament trails.
Common Boat Applications
- Bass boats with limited dash space
- Center consoles for saltwater angling
- Jon boats and pontoons needing a minimalist vibe
- Upgrade projects on older vessels
Long-Term Care for Peak Performance
Once mounted, routine maintenance keeps your setup looking new. Wipe the bezel with mild soap and freshwater after saltwater trips to prevent corrosion. Inspect seals annually, especially in humid climates. If trailering frequently, add foam padding behind the unit to absorb road jolts. This proactive approach extends the life of your Elite FS 9, keeping those crisp sonar returns sharp season after season.
Frequently Asked Questions
Is this flush mount kit compatible with other Elite FS models?
Yes, it's optimized for the Elite FS 9 but works with other 9-inch Elite FS displays due to shared mounting patterns. Always verify dimensions for your specific model.
What tools are required for installation?
Basic tools include a jigsaw or hole saw, drill, screwdriver set, marine sealant, and measuring tape. No specialized marine tools needed.
Does the kit include a sun cover or gimbal bracket?
It includes a matching gimbal cover for flush setups and all necessary hardware. Sun covers are sold separately for added protection.
Can I remove the display easily for storage?
Yes, quick-release clips allow tool-free removal, perfect for theft-prone areas or off-season storage.
Is this kit waterproof once installed?
With proper sealing using the included gaskets and silicone, it provides IPX7-level water resistance, handling splashes and rain effectively.
What if my console is thicker than standard?
The kit supports up to 2-inch thick panels with extension hardware. For thicker setups, spacers can be added.
Will flush mounting affect sonar performance?
No, it preserves full transducer connectivity and signal integrity, as confirmed by installers on various boat types.
SKU: NVN-1003224
MPN: 000-15786-001
UPC: 9420064118427
Technical specifications
| Brand | Lowrance |
| Model | Lowrance Flush Mount Kit For Elite FS 9 |
| SKU / MFR# | 1003224 |
