Blue Sea 7044 - 187-Series 100 Amp Circuit Breaker Panel Mount

Thermal circuit breakers provide heavy duty circuit protection for 25 to 200 Amp loads when switching and circuit protection are both required. Self-trimming case eliminates need for mounting panels or trim bezels.

Blue Sea 7044BSS Attributes

• Ampere Rating: 100 Amp
• Voltage Rating: 48 Volt
• Reset Type: Manual
• Terminal Connection: Screw
• Type: Stud Mounted
• Quantity: Single
• Estimated Install Time (Hours): 0.25

Blue Sea 7044BSS Features & Benefits

• Combines Switching And Circuit Protection Into A Single Device
• Clear, Single Lever Operation
• Trip Free Design Cannot Be Held "ON" During Fault Current Condition
• Waterproof
• Recessed Mounting Holes For Clean Appearance
• Large Clearance Around Terminal Studs Accept Heavy Gauge Wire Lugs
• Robust 5/16 M8 Terminals Provide High Torque Connections
• Large Lever With Vertical/Horizontal Orientation Provides Indication Of Trip Status
• Ignition Protected - Safe For Installation Aboard Gasoline Powered Boats
• No Supplier Warranty

Blue Sea Systems 187-Series Circuit Breaker - Panel Mount 100A

Model: 7044-BSS

• Combines switching and circuit protection into a single device*
• Clear, single lever operation
• "Trip Free" design cannot be held "ON" during fault current condition
• Waterproof
• Recessed mounting holes for clean appearance
• Large Clearance around terminal studs accept heavy gauge wire lugs
• Robust 5/16 M8 terminals provide high torque connections
• Large lever with vertical/horizontal orientation provides indication of trip status
• Ignition protected - Safe for installation aboard gasoline powered boats

* Do not use as a switch where high inrush currents are expected.

Specifications

Amperage	100A
Maximum Voltage	48vDC
Mounting	Panel Mount
Circuit Breaker Type	Thermally responsive Bi-metal blade
Terminal Stud Torque	75 in-lb (8.47 Nm)
Interrupt Capacity	5000A @ 12V 3000A @ 24V 1500A @ 42V
Minimum Operating Temperature	-40° C
Maximum Operating Temperature	85° C
Case Material	Thermoset Polyester
Circuit Breaker Class	Type III - switchable/manual reset - trip free
Mounting Hole	Accept #10 (M5) Screw
Terminal Stud Size	5/16" - 18

"SwitchHeavy duty circuit protection when switching and circuit protection are both required. Single lever operation is clearly visible. Ignition protected (conforming to sae j1171), safe for installation aboard gas-powered boats. Weather resistant. 5\/16-18 terminal studs. Maximum voltage 42 volts dc."
SKU: NVN-1001941
MPN: 7044-BSS
UPC: 632085070441
