Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos

SKU: 1001120 - UPC: 12-24-25 - MPN: 12-24-25
It will be shipped by UPS Ground.
$785.99 $908.33 ( / )

Available Stock : 1

These "UP" converters produce 24 volts from 12 volt systems and are ideal for managing dual voltage applications on marine vessels without having to install a 24 volt battery and dedicated charging system. Choose from two types depending on your application:In the Standard, Non-Isolated Series the 12V input and 24V...
NewMar
Same Day

Shipping (3PM)

Free Returns

Within 30 days

Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos Product Description

These "UP" converters produce 24 volts from 12 volt systems and are ideal for managing dual voltage applications on marine vessels without having to install a 24 volt battery and dedicated charging system. Choose from two types depending on your application:

In the Standard, Non-Isolated Series the 12V input and 24V output share a common negative ground and are ideal when installing certain electronics that operate better on 24 volts when a robust 12 volt system exists. Models available in outputs of 7, 16 and 25 amps.

Standard, Non-Isolated Series

  • Intended for use on negative ground systems
  • 10 -15 VDC input range
  • Available in 7, 16 and 25 amp outputs
  • Current limited, voltage spike suppression, automatic thermal shutdown and recovery
Model Input
voltage
Output
voltage
Output Amps
Intermittent
Output Amps
Continuous
Case
Size
Weight
Lbs Kg
Standard - Non-Isolated
12-24-7 10-15 27.2 7 7 C-1 1.4 .64
12-24-16 10-15 27.2 16 16 C-2 3.55 1.61
12-24-25 10-15 27.2 25 25 C-3 4.1 1.86


Case Size

Case Inches Centimeters
H W D H W D
C-1 3.5 3.5 1.75 8.9 8.9 4.5
C-2 4.25 5.9 14.0 10.8 15.0 35.6
C-3 6.0 6.8 16.5 15.2 17.3 41.9

Specifications

Input: 10 - 15V DC

Output: 27.2 VDC +/-5% at extreme temperature load, input, tolerance, etc.

Ripple: <100mV P-P

Regulation: +/- 5% Line/Load

Duty Cycle:
Intermittent: 2 minutes, 20% duty
Continuous: 24 hours, 100% duty

Operating Temp: -25˚ - 30˚ C, derate linearly from 30 to 0% @ 80˚ C

Mechanical
  • Efficiency: 93% - Typical.
  • Anodized aluminum, glass filled polycarbonate, dust water and impact resistance to IP533
  • Front panel terminal block
  • Output indicator: Green LED


These "UP" converters can generate 24 volts from a 12 volt system and are ideal for managing dual voltage applications on ships without the need to install 24 volt batteries and...

Frequently Asked Questions (FAQ) About Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos

Who is the NewMar?
How to describe Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos?
What is the highlights of Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos?

Who is the NewMar?

Newmar DC Power has been a leading manufacturer of high-quality communication DC power products for over 50 years. Newmar powers essential equipment in industries such as marine, telecommunications, network, land mobile, and automation IOT industries. Newmar is dedicated to high quality with fast delivery and by maintaining a large inventory of all products and components, they can ship standard products quickly and engineer, assemble and ship complete power plants in a fraction of the time it takes most other system integrators. Providing the industry?s quickest delivery of high-quality power products is what sets Newmar apart. Newmar offers an extensive line of DC Power products with an earned reputation for high reliability and quality in powering wireless networks in Broadband, iDAS, oDAS, Microwave, Cellular, and Land Mobile applications. Available in 2V, 24V, and 48V DC, they offer solutions that include DC Power Systems, Hot Swap Rectifiers, Power Supplies, DC-DC Converters, DC-AC Inverters, DC Distribution Panels, DC Power Conditioners, DIN Rail DC UPS, DIN Rail Power Supplies, and Installation Accessories.

How to describe Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos?

These "UP" converters can generate 24 volts from a 12 volt system and are ideal for managing dual voltage applications on ships without the need to install 24 volt batteries and...

What is the highlights of Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos?



Save $122 when you buy the Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos for only $785 from NVN Marine! Same day shipping before 3pm.

Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos Technical Specifications

Type:

Electrical | DC to DC Converters

Vendor:

NewMar

Weight:

5.0 lb

Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos User Reviews

Newmar 12-24-25 Step Up DC-DC Converter 25 Amp Conitnuos Shipping & Return

Shipping Weight:

5.0 lb

Box Sizes:

1.00 (h) x 1.00 (w) x 1.00 (l)

Cubic Feet:

1.0

Returnable:

Yes

USPS First Class:

Yes

P65:

Yes

For detailed shipping policy please check our Shipping Policy and you can find our Return and Refund Policy here.
