Victron Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz

Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz

Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds.

SinusMax - Superior engineering

Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load.

Extra start-up power

A unique feature of the SinusMax technology is very high start-up power. Conventional high frequency technology does not offer such extreme performance. Phoenix inverters, however, are well suited to power up difficult loads such as refrigeration compressors, electric motors and similar appliances.

Parallel and 3-phase operation capability

Up to 6 Phoenix Inverters can operate in parallel to achieve higher power output. Six 24V 5000VA units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.

Communications interface

These larger Phoenix inverter models come with a VE.Bus port. All you need to connect to your PC is our MK3-USB VE.Bus to USB interface (see under accessories). Together with our VictronConnect or VEConfigure software,  which can be downloaded free of charge from our website, parameters of the inverters can be customized. This includes output voltage and frequency, over and under voltage settings and programming the relay. This relay can for example be used to signal several alarm conditions, or to start a generator. The inverters can also be connected to a GX device (eg Cerbo GX) for monitoring and control.

Warranty Info

Please contact your dealer for any returns, repairs or support issues related to this product.

It is built on our proven Phoenix inverter platform and now has a new ultra-thin design and an all-metal housing. The models suitable for 12, 24 or 48V systems are 1600VA, 2000VA and 3000VA. It is powerful enough to provide the most common plug-in equipment for your car, boat, caravan or home. Toroidal transformers can provide high peak power surge capability, stable voltage, frequency and high-quality sine waves. Installation is simpler than ever, and installers can now access the terminal more easily, enabling a more professional decoration. Bluetooth is built-in, making it easier than ever to set up a high-power inverter. Configure alarms, alarm relays, voltage cutoff, output voltage, frequency, energy saving mode, etc. in VictronConnect.
SKU: NVN-82608
MPN: PIN123020100
UPC: 8719076023586
