Simrad Xsonic SS260 50/200KHZ 9-PIN Connector Depth/Temp

Discover the Power of Precision with the Simrad SS260 Thru-Hull Transducer

Anglers chasing trophy fish in deep waters know that reliable sonar performance can make or break a trip. The Simrad SS260 stands out as a rugged stainless steel thru-hull transducer designed for sportfishing boats and smaller commercial vessels up to 30 feet. Its broadband 50/200 kHz setup delivers crystal-clear imaging whether you're probing shallow reefs or scanning blue-water depths up to 3,000 feet. Combining depth measurement with integrated temperature sensing in one compact unit, it equips you with essential data without cluttering your hull.

What sets this transducer apart is its ability to maintain pinpoint accuracy even at high speeds over 30 knots. The narrow 6-degree beam at 200 kHz paints sharp details of bottom structure and fish targets, perfect for bottom bouncing or jigging. Switch to the wider 19-degree beam at 50 kHz for broader coverage in offshore pursuits, thanks to its seven-element array that excels in deeper scenarios.

Key Features That Elevate Your Fishing Game

• High-Power Output: Rated at 1,000 watts RMS, it punches through water columns for reliable returns in challenging conditions.
• Dual-Frequency Versatility: 50 kHz for wide-area sweeps and 200 kHz for high-resolution close-ups, adapting to your fishing style.
• Built Tough: Marine-grade stainless steel construction resists corrosion and impact, holding up against rough seas and constant use.
• Speed-Resilient Performance: Fairing block included to streamline installation, minimizing drag and ensuring stable readings underway.
• Extended Reach: 33-foot cable gives flexibility for routing to your display unit.
• 9-Pin Connectivity: Seamless plug-and-play with compatible Simrad sounders, supporting advanced chirp capabilities for superior target separation.

Real-World Benefits for Serious Anglers

Imagine motoring offshore at speed, confident your transducer is locking onto wrecks and schools without signal loss. The SS260's design shines in fast-displacement hulls, where thru-hull mounting with a fairing keeps the face perpendicular to the water flow. Fishermen report exceptional bottom tracking in 1,500+ feet, spotting subtle ledges that hold grouper or snapper.

For tournament pros, the temp sensor provides surface readings that correlate with baitfish movements, helping you pinpoint thermoclines. Maintenance is straightforward—periodic cleaning prevents marine growth, ensuring long-term clarity. Compared to plastic alternatives, its metal housing offers superior durability without sacrificing sensitivity.

Technical Specifications at a Glance

These specs make it a go-to for vessels needing robust sonar without complexity.

Installation Insights for Optimal Results

Thru-hull setup requires careful hull placement forward of the prop for clean water flow. Use the included fairing to angle the transducer face 12-20 degrees downward, matching your hull deadrise. Seal with marine sealant and route the 33-foot cable away from electrical noise. Post-install calibration in your sounder software fine-tunes gain and range for your local waters. Pro tip: Test at idle and planing speeds to verify bottom lock before heading out.

Frequently Asked Questions

Why Anglers Trust the SS260 for Consistent Results

From weekend warriors to charter captains, this transducer delivers where others falter—deep clarity, speed stability, and easy integration. Pair it with your Simrad multifunction display for a setup that reveals fish-holding spots others miss. Invest in gear that matches your passion for the water.
