Raymarine Axiom Pro 16 S Combo w/Lighthouse North America Chart
Raymarine Axiom Pro 16 S Combo w/Lighthouse North America Chart — Product description
Discover Unmatched Performance on the Water
Imagine commanding your vessel with a crystal-clear view of everything around you—fish below, charts ahead, and radar sweeps scanning the horizon. The Raymarine Axiom Pro 16 S sets a new benchmark for marine multifunction displays, blending powerhouse sonar capabilities with intuitive controls tailored for serious boaters. Whether you're chasing trophy fish in deep waters or navigating busy coastal routes, this 15.6-inch beast delivers responsive operation and vivid visuals that keep you ahead of the game.
Crafted for those who demand reliability in harsh marine environments, it combines single-channel High CHIRP sonar for pinpoint target separation with preloaded Lighthouse North America charts covering intricate lakes and coastal areas complete with tide data. No more guesswork—just precise, actionable intelligence to elevate your boating adventures.
Why Boaters Trust the Axiom Pro 16 S
- Lightning-Fast Responsiveness: Powered by a quad-core processor, it handles multiple apps—like sonar scrolling, chart plotting, and radar overlays—without a hitch, ensuring split-second decisions when conditions turn.
- Superior Visibility: The optically bonded IPS panel pumps out 1,200 nits of brightness, eliminating glare even under direct sun or through polarized lenses. Wide viewing angles mean your crew stays informed from any angle.
- Versatile Control: HybridTouch lets you swipe, tap, or twist the rotary dial—adapt to gloves, waves, or preference for effortless handling during rough seas.
- Fishfinding Excellence: Built-in High CHIRP sonar reaches up to 900 feet, revealing bottom structure and bait schools with exceptional clarity. Pair it with CPT-S transducers for optimal performance, and scroll back through sonar history to revisit missed opportunities.
- Seamless Expansion: Network up to multiple displays, Evolution autopilots, Quantum radars, FLIR thermal cameras, and more via RayNet Ethernet, NMEA2000, and Wi-Fi. It's the hub of a fully integrated helm.
Build Your Ultimate Navigation Network
Expand beyond basics effortlessly. Integrate AIS for collision avoidance, control digital switching systems like EmpirBus, or stream video from up to 10 IP cameras plus one analog input. Weather overlays via GRIB files keep you storm-free, while future updates promise even more like Bluetooth audio and C-MAP compatibility. With 16GB internal storage and dual microSD slots supporting up to 2TB, store waypoints (10,000+), routes, and tracks without limits.
Perfect for offshore anglers spotting wrecks at depth or cruisers plotting safe passages through tide-influenced inlets, its built-in 10Hz GNSS (GPS/GLONASS/Beidou) ensures rock-solid positioning.
Built to Withstand the Elements
Rated IPX6/IPX7 waterproof, it shrugs off heavy spray and submersion. Operating from -25°C to +55°C (-13°F to 131°F), it's ready for arctic runs or tropical heat. Compact at 17.8 x 10.2 x 2.72 inches and just 6.25 lbs, mounting options include bail, flush, or RAM ball for any console setup.
Everything You Need to Get Started
- Axiom Pro 16 S display unit
- Lighthouse North America Lakes and Coastal Charts (microSD)
- Power/Video/NMEA0183 cable (1.5m straight)
- RayNet networking cable (2m)
- NMEA2000 to DeviceNet cable (1m)
- Sun cover, trim kit, and mounting hardware
- Quick start guide and warranty essentials
Technical Specifications at a Glance
| Feature | Details |
|---|---|
| Display | 15.6" IPS, 1920x1080 FHD, 1200 nits, multitouch |
| Sonar | High CHIRP (built-in, up to 900ft), CPT-S transducers |
| Networking | 2x RayNet Ethernet, NMEA2000, NMEA0183 (1 Tx/2 Rx), Wi-Fi, Bluetooth (future) |
| Power | 12/24V DC (8-32V), ~45W draw |
| Dimensions & Weight | 17.8" x 10.2" x 2.72" (452x258x69mm), 6.25lbs (2.84kg) |
Frequently Asked Questions
What transducers work with the Axiom Pro 16 S?
It pairs exclusively with CPT-S transducers via the 25-pin connector for built-in High CHIRP sonar. For advanced setups, use the A80490 adapter with CP470 modules.
Can I connect radar to this display?
Yes, compatible with Quantum CHIRP, HD, and Super HD radars over RayNet Ethernet for seamless overlay on charts and sonar.
Does it support autopilot control?
Absolutely—full integration with Raymarine Evolution autopilots via NMEA2000 for point-and-go navigation.
How waterproof is the Axiom Pro 16 S?
IPX6 for high-pressure water jets and IPX7 for 1m submersion up to 30 minutes, ideal for open-water exposure.
What charts are included, and can I add more?
Preloaded with Lighthouse North America covering lakes and coasts with tides. Supports Navionics, Lighthouse, and future C-MAP via microSD slots.
Is remote control possible?
Yes, via optional RMK-10 keypad or RCU-3 remote for helm stations away from the display.
What's the maximum sonar depth?
Up to 900 feet (974m) with High CHIRP, depending on conditions and transducer.
Axiom™ Pro 16 S MFD with Single Channel High CHIRP Sonar - Lighthouse North America Chart
With single channel high CHIRP Sonar and Raymarine HybridTouch control, Axiom Pro 9 is the new standard for “all-in-one” display. And with a blazing fast quad core processor, a super bright IPS display, and the smart LightHouse OS, Axiom Pro delivers a fluid and intuitive navigation experience.
Axiom Pro is engineered for captains that want it all. The new standard for “all in-one” multifunction devices. And with a blazing fast quad core processor, a super bright high-definition IPS display, and the smart LightHouse OS, Axiom Pro delivers a fluid and intuitive navigation experience. Axiom Pro is easy to expand into an advanced navigation network that includes multiple Raymarine Axiom displays, CHIRP radar, Evolution autopilot, FLIR thermal night vision technology, and more.
Blazing Fast
Quad core processor delivers instantaneous response and the ability to run multiple apps simultaneously without any slowdowns.
Bold & Bright
Optical bonding technology and IPS display panels give you stunning Color, clarity, and contrast in all lighting conditions. Axiom Pro looks great even through polarized sunglasses.
HybridTouch™
Control Axiom Pro from its multi-touch screen, its buttons and rotary knob, or any combination of both. This choice is yours.
Custom Key
Get instant access to your favorite function with user-programmable Custom Key.
Lighthouse 3 OS
Fast, fluid and easy to learn. The Lighthouse 3 interface is uncluttered and easy to personalize for your style of boating.
Specifications:
- Screen Size: 15.6"
- Display Resolution: 1920 x 1080
- Screen Type: Super bright IPS display with optical bonding. Multitouch support
- Mounting Options: Front
- Waterproofing: IPX6 / IPX7
- Memory: 16GB Internal / x2 microSDXC slots
- USB: 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440)
- Voltage: 12 / 24 V dc
- Weight: 6.25lbs / 2.84kg
- Operating Temperature: -25ºC to +55ºC (13ºF to 131ºF)
- Wi-Fi
- Ethernet: 2 x 10/100 Mbits/ Network (RayNet)
- NMEA 0183: x2 NMEA 0183 input and x1 NMEA 0183 output (part of power cable)
- NMEA2000: 1 x NMEA2000 port (DeviceNet microC)
- Radar Compatible
- Thermal Night Vision Compatible
- Video Cameras: 1 x Analogue input (BNC). Up to 10 IP Cameras
- Built-in Sonar: High CHIRP Sonar built in – S models only - Uses CPT-S Transducers Only
- External Sonar Compatible
- GPS: Built-in GNSS Receiver: GPS/GLONASS/Beidou - 10Hz 167 Channel | External Accessory: GA150 (A80288)
- Optional Remote Controls
- AIS
- Audio Integration
- Autopilot Control: Evolution Autopilot Control
- Digital Switching: Empirbus compatible
- Dimensions (w x h x d): 17.8" x 10.2" x 2.72" / 452 x 258 x 69 mm
In the Box:
- MFD Display (E70483)
- Lighthouse North America Chart (R70794)
- RayNet (F) to Raynet (F) Cable – 2M (A62361)
- Micro-C DeviceNet (F) to STNG (F) Cable - 1M (A06075)
- Suncover (A80534)
- Panel Seal Gasket
- Power / Video / NMEA0183 Cable - Straight, 1.5M (R62379)
- Mounting Fixings
- Bezel Pieces and Home / Menu Button
- Quick Start Guide
- Warranty Card
- Raymarine window decal
Axiomâ„¢ Pro 16 S MFD with single-channel high CHIRP sonar-North American Lighthouse Chart Axiom Pro 9 with single-channel high CHIRP sonar and Raymarine HybridTouch control is...
SKU: NVN-88436
MPN: E70483-00-102
UPC: 723193838235
Technical specifications
| Brand | Raymarine |
| Model | Raymarine Axiom Pro 16 S Combo w/Lighthouse North America Chart |
| SKU / MFR# | 88436 |
