Raymarine Axiom XL 22 Glass Bridge Multifunction Display Kit with RCR-SD, Alarm & Cable
Raymarine Axiom XL 22 Glass Bridge Multifunction Display Kit with RCR-SD, Alarm & Cable — Product description
Imagine commanding your vessel from a sleek, expansive command center that turns every journey into a seamless adventure. The Raymarine Axiom XL 22 elevates glass bridge setups with its massive 21.5-inch full HD display, delivering crystal-clear visuals even under the harshest sunlight or roughest seas. Perfect for flybridges, wheelhouses, or open cockpits, this multifunction display kit blends cutting-edge power with intuitive controls, making navigation feel effortless whether you're chasing horizons on a yacht or tracking fish on a sportfisher.
Crafted for boaters who demand reliability without compromise, it thrives in extreme marine conditions thanks to its IPX6 and IPX7 waterproof ratings and rugged all-glass construction. No more squinting at cluttered screens—optical bonding and in-plane switching technology ensure sharp contrast and wide viewing angles from any position at the helm.
Blazing Performance Meets Intuitive Control
Powered by a quad-core processor, the Axiom XL 22 handles complex tasks like a dream: overlay radar returns on charts, process real-time sonar data, or switch between video feeds without a hitch. Raymarine's LightHouse operating system shines here—fluid gestures, customizable layouts, and quick-access menus mean you spend less time fiddling and more time boating.
Swipe to wake the buttonless touchscreen, and let the built-in ambient light sensor adapt brightness automatically. Pair it with the included RCR-SD remote control for precise adjustments from afar, or integrate the optional RMK-10 keypad for pro-level helm management during those long passages.
Ultimate Connectivity for a Connected Helm
Three RayNet Ethernet ports open the door to a fully networked ecosystem. Link up Quantum radar for Doppler-enhanced target tracking, RVX1000 sonar for RealVision 3D fishfinding, or FLIR thermal cameras with ClearCruise object recognition to spot hazards day or night. Monitor up to four video streams simultaneously—keep tabs on the engine room, crew areas, or docking maneuvers with onboard DVR recording.
HDMI input lets you mirror a PC for planning routes or entertainment, while output extends the display below deck. Bluetooth streams alarms to wireless speakers, Wi-Fi powers mobile apps, and digital switching via YachtSense simplifies onboard systems like lights and pumps. Autopilot integration with Evolution keeps you locked on course with just a waypoint tap.
- Stream apps like weather services or music directly on the helm.
- Connect with partners for stability aids, lighting, or advanced sensors.
- Overlay charts from top providers for unmatched situational awareness.
Built Tough for Real-World Boating
This isn't just a screen—it's engineered for the elements. Operating from -25°C to +55°C, it shrugs off salt spray, heavy rain, and vibrations. Flush or surface mount it seamlessly into your helm design, with dimensions that fit modern glass bridges perfectly. The kit's extras, like the external alarm and video/alarm cable, ensure you're alerted instantly to critical events.
Boaters rave about its reliability on extended cruises: no lag during high-speed maneuvers, superior readability in glare, and easy personalization for solo sailors or crewed operations. Whether you're navigating crowded marinas, offshore fishing, or coastal exploring, it adapts to your style.
Key Specifications at a Glance
| Specification | Details |
|---|---|
| Display Size | 21.5-inch IPS Full HD (1920 x 1080) |
| Power Draw | Max 84W (12/24V DC) |
| Dimensions (W x D x H) | 534 x 75 x 326 mm |
| Weight | 9.9 kg |
| Waterproof Rating | IPX6 / IPX7 |
| Storage | 64 GB Solid State |
Everything You Need to Get Started
The kit arrives ready for action:
- Axiom XL 22 MFD unit
- Complete mounting hardware
- Right-angle power and RayNet cables
- STNG DeviceNet adapter
- RCR-SD remote SD card reader
- External alarm module
- Video/alarm cable
- Sun cover, gaskets, and docs
Pro tip: Plan your cable runs early for a clean install—route Ethernet through conduits to future-proof your setup for expansions like additional displays.
Why Boaters Choose Axiom XL 22 for Their Glass Bridge
In a sea of compact plotters, this 22-inch beast stands out for captains prioritizing visibility and versatility. It's not just gear; it's the nerve center that boosts confidence on night watches or in fog, with features like thermal overlays spotting unlit vessels before they spot you. Customize dashboards for fishing (sonar prominence) or cruising (chart/radar splits), and enjoy peace of mind from its proven track record in professional fleets.
Axiom XL displays offer superior performance, large format visibility and elegant simplicity. Engineered to perform in extreme conditions, the fully waterproof Axiom XL family of glass bridge chartplotters can be installed in both open cockpits and enclosed bridge stations. Each model uses in-plane switching technology (IPS) and Raymarine optical bonding to deliver wider viewing angles, sharp contrast and unmatched readability in bright sun.
Raymarine T70429 Attributes
- Maps: No Pre-Loaded Maps
- Display Size: 21-1/2 Inch
- Display Type: FHD 1920 x 1080 Pixels Resolution
- Interface: Touchscreen Interface
- Dimensions: 21 Inch Width X 12.85 Inch Height
- Waterproof: IPX6/ IPX7 Waterproof
Raymarine T70429 Features & Benefits
- Flagship Performance: At The Heart Of Each Axiom XL Display Is A Blazing Fast Quad-Core Processor That Delivers A Responsive And Powerful All-In-One Big Screen Navigation Experience
- Elegant Simplicity: Axiom XL Displays Are Powered By Raymarine's LightHouse Operating System And Offer A Fast, Fluid And Uncluttered Interface That Is Easily Personalized For Your Navigation Style
- Superior Integration: A Powerful Network And Video Integration Platform, Feature Three Ethernet Ports For Connecting Radar, CHIRP And 3D Sonar Modules, Plus Additional Axiom Family Displays
- Smart And Rugged All-Glass Display Is Optimized For Flush Or Surface Mounting
- Features A Sleek Buttonless Design With Swipe-To-Power Touch Control
- Keep Watch On The Crew Or Engine Room With Marine Video Cameras
- Get Underway Faster With The Intuitive LightHouse Operating System
- Axiom XL And YachtSense Technology Offer Simple Touch Screen Control Of Onboard Electrical Devices
- Stay On Course With Evolution Autopilot Integration, Plot A Waypoint On Axiom XL And Engage Evolution's Intelligent Sensor To Keep You On The Perfect Course
- Limited 2 Year Warranty
Raymarine T70429 Installation Instructions
Raymarine T70429 Warranties
Raymarine T70429 Technical Bulletins
- AXIOM XL22 MDF E70515 3D Surface Mount PDF.pdf
- Axiom XL Installation instructions 87344-2-EN.pdf
- AXIOM XL22 MDF E70515 3D Surface Mount PDF.pdf
- Axiom XL Supplementary information 82400-2-EN.pdf
Axiom XL 22 Glass Bridge Multifunction Display Kit w/RCR-SD, Alarm & Cable
The Axiom XL range is the pinnacle of Raymarine navigation and modern helm integration.
Designed for glass bridge installations, Axiom XL displays offer superior performance, large format visibility and elegant simplicity. Engineered to perform in extreme conditions, the fully waterproof Axiom XL family of glass bridge MFDS can be installed in both open cockpits and enclosed bridge stations. Each model uses in-plane switching technology (IPS) and Raymarine optical bonding to deliver wider viewing angles, sharp contrast, and unmatched readability in bright sun.
Available in 16, 19, 22 and 24-inch display sizes, Axiom XL’s edge-to-edge glass construction gives vessel designers the ability to create integrated and elegant navigation helm appearance.
Flagship Performance
At the heart of each Axiom XL display is a blazing fast quad core processor that delivers a responsive and powerful all-in-one big screen navigation experience. Axiom XL brings together multiple technologies and sensors into single or multi display helm solution. Integrate Axiom XL with additional Axiom XL displays or connect seamlessly with Raymarine’s family of Axiom and Axiom Pro displays at remote stations.
Elegant Simplicity
Axiom XL displays are powered by Raymarine’s LightHouse 3 OS and offer a fast, fluid, and uncluttered interface that is easily personalized for your navigation style. Enjoy multi-touch screen control or add the Raymarine RMK-10 keypad for complete remote system control.
Superior Integration
A powerful network and video integration platform, Axiom XL displays feature three Ethernet ports for connecting radar, CHIRP and 3D sonar modules, plus additional Axiom family displays. FLIR thermal camera support enhances awareness and HDMI input enables Axiom XL to serve as a remote PC or entertainment display.
Features:
- Smart and Rugged All-Glass Display is optimized for flush or surface mounting and features sleek buttonless design with swipe-to-power touch control. A built-in ambient light sensor automatically adjusts display brightness based on lighting conditions.
- Connect Even More with LightHouse Apps. Expand the power and capabilities of Axiom XL by streaming mobile entertainment apps and connect with leading marine technology partners like Seakeeper, Mazu and Lumishore.
- Keep Watch on the crew or engine room with marine video cameras. Connect both analog and video over IP to view 4 simultaneous video streams. Built in recording capability transforms Axiom XL into an onboard DVR.
- Access Axiom Everywhere using Axiom XL’s HDMI video output. Monitor Axiom from the big screen below deck or stream Axiom XL to your phone or tablet with Raymarine mobile apps.
- Vessel Automation with Raymarine Digital Switching solutions for boat builders. Axiom XL Digital Switching technology offers simple touch screen control of onboard electrical devices.
- Get Underway Faster with the intuitive LightHouse 3 OS. Spend seconds, not minutes, plotting your next course. LightHouse 3 is easy to learn and easy to customize.
- Elevate Awareness with Quantum 2 CHIRP radar and Doppler target tracking, the easier way to keep a watchful eye on potentially dangerous targets.
- An Extra Set of Eyes for safer navigation with FLIR ClearCruise™ thermal object recognition. Let Axiom XL and FLIR be your sixth sense on the water so you can navigate safer, both night and day.
- Ready to Fish with the optional RVX1000 remotely mounted 3D CHIRP sonar module. Experience Raymarine CHIRP sonar and award winning RealVision™ 3D on the big the screen.
- Bring your computer to the helm. Axiom XL lets captains view and control a remote personal computer using a computer’s HDMI output and USB touch screen control.
- Navigate with the Best Charts from Navionics, C-MAP, and Raymarine’s library of LightHouse raster and vector charts from leading map makers.
- Stay on Course with advanced Evolution autopilot integration. Plot a waypoint on Axiom XL and let Evolution’s 9-axis intelligent sensor keep you on the perfect course.
Raymarine Axiom XL 22" MFD Kit includes RCR-SD, Alarm and Cable
Model: T70429- Full HD (1080p) multi-touch display with IPS technology
- Blazing fast quad core processor delivers a powerful all-in-one big screen navigation experience
- Powered by Raymarine’s LightHouse 3 OS. Fast, fluid, and easy-to-learn
- Users can enjoy multi-touch screen control or add the Raymarine RMK-10 keypad
- 3 Raynet Ethernet ports for connecting radar, CHIRP sonar, cameras, and additional Axiom, Axiom Pro, and Axiom XL family displays
- View 4 video camera streams simultaneously with IP camera support and analog video input for visible light and FLIR thermal cameras
- Ready-to-fish with the optional RVX1000 remotely mounted 3D CHIRP sonar module.
- Bring your computer to the helm. Axiom XL lets users view and control a remote personal computer using a computer’s HDMI output and USB touch screen control.
- Axiom XL’s HDMI input also supports full integration with B ning PC Based Digital Switching systems
- HDMI video output lets users monitor Axiom XL from the big screen below deck
- Be entertained with LightHouse Apps. Stream movies and music from Netflix and Spotify on Axiom XL’s full HD display
- Axiom XL and LightHouse Apps lets you integrate with marine technology partners like Theyr weather and Lumishore LED lighting
- Integrated Wi-Fi for mobile apps and Bluetooth for streaming audio and alarms to remote speakers
At the heart of each Axiom XL display is a blazing fast quad core processor that delivers a responsive and powerful all-in-one big screen navigation experience. Axiom XL brings together multiple technologies and sensors into single or multi display helm solution. Integrate Axiom XL with additional Axiom XL displays or connect seamlessly with Raymarine’s family of Axiom and Axiom Pro displays at remote stations.
Axiom XL displays are powered by Raymarine’s LightHouse 3 OS and offer a fast, fluid, and uncluttered interface that is easily personalized for your navigation style. Enjoy multi-touch screen control or add the Raymarine RMK-10 keypad for complete remote system control.
A powerful network and video integration platform, Axiom XL displays feature three Ethernet ports for connecting radar, CHIRP and 3D sonar modules, plus additional Axiom family displays. FLIR thermal camera support enhances awareness and HDMI input enables Axiom XL to serve as a remote PC or entertainment display.
Smart and Rugged All-Glass Display is optimized for flush or surface mounting and features sleek buttonless design with swipe-to-power touch control. A built-in ambient light sensor automatically adjusts display brightness based on lighting conditions.
Connect Even More with LightHouse Apps. Expand the power and capabilities of Axiom XL by streaming mobile entertainment apps and connect with leading marine technology partners like Seakeeper, Mazy and Luminshore.
Keep Watch on the crew or engine room with marine video cameras. Connect both analog and video over IP to view 4 simultaneous video streams. Built in recording capability transforms Axiom XL into an onboard DVR.
Access Axiom Everywhere using Axiom XL’s HDMI video output. Monitor Axiom from the big screen below deck or stream Axiom XL to your phone or tablet with Raymarine mobile apps.
Vessel Automation with Raymarine Digital Switching solutions for boat builders. Axiom XL Digital Switching technology offers simple touch screen control of onboard electrical devices.
Get Underway Faster with the intuitive LightHouse 3 OS. Spend seconds, not minutes, plotting your next course. LightHouse 3 is easy to learn and easy to customize.
Elevate Awareness with Quantum 2 CHIRP radar and Doppler target tracking, the easier way to keep a watchful eye on potentially dangerous targets.
An Extra Set of Eyes for safer navigation with FLIR ClearCruise™ thermal object recognition. Let Axiom XL and FLIR be your sixth sense on the water so you can navigate safer, both night and day.
Ready to Fish with the optional RVX1000 remotely mounted 3D CHIRP sonar module. Experience Raymarine CHIRP sonar and award winning RealVision™ 3D on the big the screen.
Bring your computer to the helm. Axiom XL lets captains view and control a remote personal computer using a computer’s HDMI output and USB touch screen control.
Navigate with the Best Charts from Navionics, C-MAP, and Raymarine’s library of LightHouse raster and vector charts from leading map makers.
Stay on Course with advanced Evolution autopilot integration. Plot a waypoint on Axiom XL and let Evolution’s 9-axis intelligent sensor keep you on the perfect course.
Specifications| General Specifications | |
| Display Size | 21.5" |
| Display type | IPS (In-Plane Switching) |
| Color Depth | 24 bit |
| Display Resolution | 1920 x 1080 FHD |
| Display Aspect Ratio | 16:9 |
| Viewing Angle | Top 89’ / Bottom 89’ / Left 89’ / Right 89’ |
| Power | |
| Nominal supply voltage | 12 / 24 Vdc |
| Operating voltage range | 8 Vdc to 32 Vdc |
| Fuse Requirements | Inline fuse = 15Amp, or Thermal breaker = 15Amp |
| Max. Power | 84W |
| Enviromental | |
| Operating Temperature Range | -25°C to + 55°C |
| Storage temperature range | -30°C to +70°C |
| Humidity | Up to 93% @40°C |
| Water Ingress Protection | IPx6 and IPx7 |
| Overall Dimensions W x D x H (mm) | 534 x 75 x 326 |
| Product Weight (Kg) | 9.9 |
| Other | |
| Internal Storage | 64 GB Solid State (62 GB usable) |
What's in the Box:
- Axiom XL 22 MFD
- Mounting Kit
- Right Angle Power Cable
- STNG - Devicenet Adapter
- RayNet Cable
- Gasket Material
- Silicon Sun Cover
- Documentation Pack
- RCR-SD
- Alarm
- Video/Alarm Cable
The Axiom XL series is the pinnacle of Raymarine navigation and modern helmet integration. Axiom XL monitor is specially designed for glass bridge installation, with excellent performance, large-format visibility and simple appearance. Designed for working under extreme conditions, the fully waterproof Axiom XL series glass bridge MFDS can be installed in open cockpits and closed bridges. Each model uses in-plane switching technology (IPS) and Raymarine optical bonding to provide a wider viewing angle, sharp contrast, and unparalleled readability in bright sunlight. The edge-to-edge glass structure of the Axiom XL enables ship designers to create an integrated and elegant navigation helmet look.
SKU: NVN-83934
MPN: T70429
UPC: 723193826638
Technical specifications
| Brand | Raymarine |
| Model | Raymarine Axiom XL 22 Glass Bridge Multifunction Display Kit with RCR-SD, Alarm & Cable |
| SKU / MFR# | 83934 |
