Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof
SKU: 29828 · UPC: 602290201404 · MPN: 206-051S
★★★★★
4.7 · 0 reviews
Authorized dealer41% off
$20.49
$34.95Save $14.46
or 4 payments of $5.12 with Affirm
Out of stock
Free shipping
Orders $500 or more
Free returns
Within 30 days
Same day shipping
Order before 3 PM (EST)
Ask anything
We're here to help
$20.49
02 · Overview
Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof — Product description
Panel Seal/Waterproof "A" Frame Magnetic Circuit Breakers
- Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
- Meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers
- UL Recognized (UL 1077) for use in th USA, and CSA Certified for use in Canada
- Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
- Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
- Handle Color - Metal with silicon rubber seal
- Maximum Aperage - 50 Amps
- Maximum Voltage/AIC - 32 VDC/2,500 amps with no back-up fuse (ABYC E-11.10.1.5.5)
- Rated Switch Cycles - 10,000 actuations at rated current and voltage
- Electrical Hardware - Hex nut 1/2-32 (supplied with circuit breaker); Lockwasher 1/2" internal tooth (supplied with circuit breaker)
- Optional Boot - Black silicone rubber (P/N 048-015)
The product is made of high-quality materials and can provide you with many years of service. Use the most advanced technology to design and consider the customer. It will meet your needs...
SKU: NVN-29828
MPN: 206-051S
UPC: 602290201404
03 · The numbers
Technical specifications
| Brand | Paneltronics |
| Model | Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof |
| SKU / MFR# | 29828 |
Set product metafields under specs.* to populate this table.
04 · Before you buy
Frequently asked questions
No questions yet. Got one? Drop us a line.
