Inv/Chgr, 4000W 24V 105A T-Sine 120/240V
Inv/Chgr, 4000W 24V 105A T-Sine 120/240V — Product description
The MS-PAE 120/240 Volt Series Inverter / Charger from Magnum Energy is a pure sine wave inverter designed specifically for the most demanding renewable energy applications. The MS-PAE Series is powerful, easy-to-use, and best of all, cost effective. No series stacking required: The unique design of the MS-PAE Series can provide 120 and 240 Volts output in one unit, eliminating the need to stack two units together to get 240 Volts. Parallel stacking: You can parallel up to four inverter / chargers for up to 17.6 Kilo Watts of power at 120/240 Volt. The magnum panels and router are required for parallel stacking the MS-PAE Series. Power Factor Corrected (PFC) Charger: Our Power Factor Corrected Charger is built into all of our inverter chargers. It uses less energy from a generator than a standard charger – using 25 To 30 Percent less AC current than standard chargers.
Magnum Energy MS4024PAE Attributes
- Output Voltage: 120/ 240 Volt AC
- Input Voltage: 18-34 Volt DC
- Continuous Output Power (W): 4000 Watt
- Peak Output Power (W): 5800 Watt
- Ampere Rating: 105 Amp
- Efficiency: 93 Percent
- Number Of AC Outlets: 2
- Length (IN): 13-3/4 Inch
- Width (IN): 12.65 Inch
- Height (IN): 8 Inch
- Remote On/Off Capable: Yes
- With USB Port: No
- With Volt/Watt Meter: No
- With Short Circuit: No
- With Reverse Battery Protection: No
- With Thermal Protection: Yes
- With Battery Cables: No
- With Built-In Charger: Yes
- With Fuse: No
Magnum Energy MS4024PAE Features & Benefits
- Pure Sine Wave
- Lightweight
- Multiple Ports
- Accessible Design
- Convenient Switches
- Versatile Mounting
- Limited 3 Year Warranty
4000 Watt, 24V, Parallel Inverter/Charger, MFG# MS4024PAE, 4000 Watts true sine wave, twin 120VAC ouputs with 180 deg phase difference to yield 240VAC between L1&L2. 24VDC input, 105 Amp charger. For renewable energy systems.
"Magnum-DimensionsMagnum MS4024PAE parallel inverter is designed to streamline off-grid renewable energy systems. It's two-way output ratings and parallel configuration makes it one of the most flexible inverters on the block."
SKU: NVN-2000433
MPN: MS4024PAE
UPC: 892608001387
