Discover Crystal-Clear Views Beneath the Waves
Imagine gliding across a serene lake at dawn, your boat humming softly as you pinpoint schools of bass hiding in submerged structures. The Garmin ECHOMAP UHD 63cv transforms this vision into reality with its Ultra High-Definition ClearVü scanning sonar via the included GT24UHD-TM transducer. This isn't just about seeing fish—it's about understanding the underwater world in stunning detail, from weed edges to drop-offs, helping you cast with confidence every time.
Pair that with Garmin's high wide CHIRP traditional sonar, and you get exceptional target separation that distinguishes individual fish from baitfish clouds or debris. Whether you're chasing walleye in shallow bays or crappie near timber, this combo delivers the clarity serious anglers demand without the clutter of lesser systems.
Navigate 17,000+ Lakes with Precision Mapping
Preloaded LakeVü g3 inland maps bring over 17,000 U.S. lakes to life right out of the box, complete with integrated Navionics data and contours down to 1-foot intervals. No more guessing depths or missing prime spots—these maps highlight hotspots, hazards, and access points, saving you hours of pre-fish scouting.
Take it further with Quickdraw Contours, where you create custom 1-foot contour maps on the fly as you explore. Keep your secret honey holes private or contribute to the Quickdraw Community via Garmin Connect, building a shared knowledge base that evolves with every trip.
Seamless Boat Integration for Total Control
Stay connected with NMEA 2000 and NMEA 0183 support, linking effortlessly to engine data, autopilots, FUSION-Link audio, VHF radios, and AIS for a unified helm experience. Picture monitoring fuel levels, adjusting your autopilot to a waypoint, and queuing up your favorite playlist—all from one vibrant 6-inch sunlight-readable screen.
For trolling motor enthusiasts, compatibility with the Force trolling motor means full command from the display: steer precisely, follow saved tracks, or navigate to waypoints without touching the foot pedal. Add built-in Wi-Fi pairing with the ActiveCaptain app for smart notifications, software updates, and OneChart access, keeping you ahead of the curve even onshore.
Built Tough for Real-World Fishing
Rugged IPX7 waterproofing shrugs off rain, splashes, and accidental submersion, while the quick-release bail mount lets you detach and store it securely in seconds—perfect for trailered boats or multi-boat setups. The 480 x 800 WVGA display shines in direct sun, ensuring readability when it matters most.
Support for Panoptix all-seeing sonar, including LiveScope, opens doors to live-action views around your boat, revolutionizing how you detect and react to fish movement.
Technical Edge for Peak Performance
| Category | Details |
|---|---|
| Display | 6.2" diagonal WVGA (480 x 800 pixels), sunlight-readable |
| Sonar Capabilities | CHIRP traditional, Ultra High-Def ClearVü; 500W RMS / 4kW peak-to-peak; max depth 2,300 ft (freshwater) |
| Dimensions & Weight | 8.6" x 5.1" x 2.6"; 1.6 lbs |
| Memory | 5,000 waypoints; 100 routes; 50,000 track points |
| Connections | NMEA 2000/0183, Wi-Fi, microSD slot |
Angler Tips to Maximize Your ECHOMAP
- Fine-Tune Sonar Settings: Adjust CHIRP frequency for your water clarity—lower for murky lakes, higher for clear shallows—to reveal faint marks.
- Leverage Quickdraw for Tournaments: Log contours during practice, then overlay on LakeVü maps for competition-day edges.
- Network Smart: Connect a heading sensor via NMEA 2000 for accurate waypoint navigation in windy conditions.
- App Synergy: Use ActiveCaptain to preload community data before launch, ensuring you're not fishing blind.
Frequently Asked Questions
What type of sonar does the Garmin ECHOMAP UHD 63cv support?
It supports Ultra High-Definition ClearVü scanning sonar and high wide CHIRP traditional sonar with the GT24UHD-TM transducer, providing crystal-clear images and excellent target separation.
Does it come with preloaded maps for U.S. lakes?
Yes, it includes LakeVü g3 inland maps covering over 17,000 U.S. lakes with 1-foot contours and integrated Navionics data.
Is the ECHOMAP UHD 63cv waterproof?
Absolutely, it has an IPX7 rating, capable of withstanding immersion in water up to 1 meter for 30 minutes.
Can I create custom maps with this device?
Yes, Quickdraw Contours lets you generate personalized 1-foot contour maps on-screen and share them via Garmin Connect.
What networking options are available?
It supports NMEA 2000 and NMEA 0183 for connecting to autopilots, engines, audio systems, AIS, and more.
Is it compatible with trolling motors?
Yes, it's compatible with Force trolling motors, allowing control, waypoint navigation, and track following from the screen.
How does the ActiveCaptain app enhance the experience?
Via built-in Wi-Fi, it provides smart notifications, software updates, OneChart access, and Quickdraw Community data.
ECHOMAP™ UHD 63cv US LakeVü g3 with GT24UHD-TM Transducer
Find more fish using the ECHOMAP™ UHD 63cv combo with a bright, sunlight-readable 6” screen. The included GT24 transducer provides Ultra High-Definition ClearVü scanning sonar, so you get a crystal-clear image of what is below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours. It features a quick-release bail mount, making it easy to remove and take with you. NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration, FUSION-Link™ audio system and more. ECHOMAP™ UHD 63cv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.
Features:
- Bright, sunlight-readable 6” combo
- Includes GT24 transducer for Ultra High-Definition ClearVü scanning sonar and Garmin high wide CHIRP traditional sonar
- Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours
- Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar
- NMEA 2000® and NMEA 0183 network support for autopilot, FUSION-Link™ audio system and engine data
- Quick-release bail mount for fast and easy mobility
- Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more
Included Transducer
This chartplotter comes with a GT24 transducer for Ultra High-Definition ClearVü scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.
Preloaded Mapping
Experience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours.
Quickdraw Contours
Create personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™.
NMEA 2000® & NMEA0183 Networks
Connect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.
ActiveCaptain® App
Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more.
1 When paired with a compatible smartphone
2 In compliance with ISO standard 13342
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
Garmin ECHOMAP 2020 UHD 63CV
Combo US Lakevu g3 with GT24 Transducer
Model: 010-02330-01- See below your boat in incredible detail with included transducer
- Navigate any waters with preloaded LakeVü g3 inland maps
- Manage your marine experience from nearly anywhere
- Create your own maps on the fly and tailor them to fit your needs
The sunlight-readable 6" touchscreen chartplotter features a quick-release bail mount and a transducer for Ultra High-Definition scanning sonar and CHIRP traditional sonar.
This chartplotter comes with a GT24 transducer for Ultra High-Definition ClearVü scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.
Experience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours.
Create personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™.
Connect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.
Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more.
Specifications| General | |
| Physical dimensions | 8.6" x 5.1" x 2.6" (21.8 x 13.0 x 6.2cm) |
| Display size | 5.4" x 3.1"; 6.2" diagonal (13.7 x 7.7 cm; 15.2 cm diagonal) |
| Display resolution | 480 x 800 pixels |
| Display type | WVGA display |
| Weight | 1.6 lbs (0.7 kg) |
| Water Rating | IPX7 |
| Power consumption | 12W |
| Antenna | Internal or external over NMEA 2000 |
| Mounting options | Bail or flush |
| Receiver | 5 Hz |
| Garmin Marine Network™ ports | None |
| Maps & Memory | |
| Preloaded maps | LakeVü g3 (inland maps) |
| Accepts data cards | 1 microSD™ card; 32 GB maximum size |
| Waypoints | 5,000 |
| Routes | 100 |
| Track log | 50,000 points; 50 saved tracks |
| Outdoor Recreation Features | |
| Tide tables | Yes |
| Chartplotter Features | |
| Garmin Sonar compatible | Yes |
| Supports AIS (tracks target ships position) | Yes |
| Supports DSC (displays position data from DSC-capable VHF radio) | Yes |
| ActiveCaptain compatible | Yes |
| Sailing Features | Yes |
| Sonar Features & Specifications | |
| Dual-frequency (50/200 kHz) sonar capable | Yes |
| Dual-beam (77/200 kHz) sonar capable | Yes |
| Transmit power | 500 W (RMS) / 4,000 W (peak to peak) |
| CHIRP sonar technology | Yes (Built-in) |
| ClearVü | Yes with CHIRP (built-in) |
| SideVü | No |
| Maximum depth | 2,300 ft @ 77 kHz, freshwater |
| Bottom lock (shows return from the bottom up) | Yes |
| Water temperature log and graph | Yes |
| Sonar recording | Yes |
| Sonar history rewind | Yes |
| Connections | |
| NMEA 2000® compatible | Yes |
| Transducer pin numbers | 4 |
| NMEA 0183 input ports | 1 |
| NMEA 0183 output ports | 1 |
| Video input ports | None |
| Video output ports | None |
| Wireless connectivity | Yes |
What's in the Box:
- ECHOMAP UHD 63cv with LakeVü g3 for U.S.
- GT24UHD-TM transducer
- Power/data cable
- Tilt/swivel mount with quick release cradle
- Flush mount
- Protective cover
- Hardware
- Documentation
SKU: NVN-80824
MPN: 010-02330-01
UPC: 753759241421
