Garmin GPSMAP® 1242xsv Plus Touchscreen GPS/Fishfinder Combo

Transform your time on the water with a chartplotter that puts precision navigation and crystal-clear fishfinding right at your fingertips. This powerhouse device blends a vibrant 12-inch touchscreen with cutting-edge sonar tech, making it a go-to for serious anglers, cruisers, and sailors who demand reliability in rough seas or calm bays. Whether you're plotting a coastal run or hunting trophy fish in deep water, its seamless integration elevates your entire boating setup without the clutter of extra screens.

Superior Navigation with Preloaded Coastal and Inland Charts

Hit the water confident with detailed BlueChart g3 coastal charts and LakeVü g3 inland maps right out of the box. These aren't just basic outlines—they pack Garmin and Navionics data for spot-on detail, including marinas, hazards, and points of interest. The Auto Guidance feature simplifies route planning by suggesting safe paths around shallows and obstacles, saving you headaches on unfamiliar waters. Anglers love customizing Quickdraw Contours to map their own hotspots, turning every trip into a personal chart-building adventure.

For those chasing upgrades, optional premium charts layer in high-res satellite imagery and relief shading, helping you visualize underwater contours like never before. Real-world tip: Zoom in on wrecks or drop-offs during scouting runs to pinpoint prime fishing zones before the bite turns on.

Advanced Sonar for Unmatched Fishfinding Clarity

Dive deep into what's below with built-in 1 kW CHIRP traditional sonar that separates targets like baitfish from structure with surgical precision. Add ClearVü and SideVü scanning at up to 260 kHz, and you can peer 1,000 feet around your boat—perfect for mapping reefs or spotting schools hugging the bottom. For live-action views, pair it with Panoptix or LiveScope transducers to watch fish react in real time, giving tournament pros the edge they've been craving.

• CHIRP frequencies: 50/77/83/200 kHz for versatile coverage
• Max depth: Up to 5,000 ft, depending on conditions
• Bonus features: Bottom lock, water temp graphs, sonar rewind for replaying scans

Pro anglers swear by SideVü for its wide swath, revealing hidden ledges that traditional sonar misses. Pair transducers easily via the 12-pin port and adapter included.

Build a Connected Helm with Effortless Networking

Why stop at standalone? Link up via Garmin Marine Network to share maps, radar overlays, and IP camera feeds across multiple units. NMEA 2000 and 0183 connect autopilots, VHF, AIS, weather stations, and FUSION audio for one-screen control. J1939 engine data pulls RPM, fuel, and trim from Yamaha or others, while OneHelm unifies third-party gear like digital switches.

ANT+ pairs with quatix watches or wireless remotes for hands-free operation, and built-in Wi-Fi hooks into the ActiveCaptain app. From your phone, access software updates, community Quickdraw data, or smart notifications—keeping your system sharp without docking.

Intuitive Touchscreen Built for Real Boating Demands

The 12.1-inch diagonal WXGA display (1280x800) shines even under direct sun, with glove-friendly touch controls that respond in choppy conditions. IPX7 waterproofing shrugs off splashes, and mounting options—bail or flush—fit any console. At 5.8 lbs, it's sturdy yet manageable for installs.

Sailors get SailAssist tools like laylines, set/drift, and wind overlays for tactical racing advantages. Customize SmartModes for fishing, cruising, or anchoring views tailored to your style.

Everything You Need to Get Started

• Main unit with power cable
• 8-pin to 12-pin transducer adapter
• NMEA 2000 drop cable and T-connector
• Bail and flush mount kits with gaskets
• Protective cover and trim snaps
• Full documentation

Quick setup tip: Route NMEA cables first for backbone stability, then test sonar in shallow water to calibrate baselines.

Technical Highlights at a Glance

Category	Details
Display	12.1" diagonal, 1280 x 800 WXGA, sunlight-readable
Dimensions & Weight	13" x 8.9" x 3.1", 5.8 lbs
Sonar Power	1 kW CHIRP traditional & scanning
Ports	2 Garmin Marine Network, 1 NMEA 2000, J1939, HDMI out, BNC video in
Memory	5,000 waypoints, 100 routes, 50K track points; dual SD slots
Water Rating	IPX7

Frequently Asked Questions

What types of sonar does the GPSMAP 1242xsv Plus support?

It features built-in 1 kW CHIRP traditional sonar, plus ClearVü and SideVü scanning sonars. It also pairs seamlessly with Panoptix and LiveScope for live views (transducers separate).

Are maps included with this chartplotter?

Yes, preloaded with BlueChart g3 coastal and LakeVü g3 inland maps, including Navionics data and Auto Guidance for safe routing.

Is the display touchscreen and sunlight-readable?

Absolutely—a bright 12-inch WXGA touchscreen optimized for marine use, readable in direct sunlight and responsive even with gloves.

What networks does it connect to?

Supports Garmin Marine Network, NMEA 2000, NMEA 0183, J1939 for engines, plus ANT+ and Wi-Fi for apps and accessories.

Can it integrate with engines and third-party devices?

Yes, J1939 handles Yamaha and others; OneHelm consolidates EmpirBus switching and more on one screen.

What mounting options are available?

Bail mount with knobs or flush mount kit included, both with protective covers for secure, clean installs.

Does it work with the ActiveCaptain app?

Yes, via built-in Wi-Fi—unlock OneChart, updates, Quickdraw Community, and remote helm control.

Is it suitable for sailing?

Definitely, with SailAssist features like laylines, race timers, wind data, and set/drift tracking.

GPSMAP® 1242xsv Plus Touchscreen GPS/Fishfinder Combo

SideVü, ClearVü and Traditional CHIRP Sonar with Mapping

Advanced navigation. Ultimate integration. This compact 12” GPSMAP® 1242xsv Touch Plus touchscreen combo seamlessly integrates into your Garmin marine system for full control of your connected helm. It supports 1 kW CHIRP traditional sonar, ClearVü and SideVü scanning sonars and Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar. Preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps give you the best of Garmin and Navionics® data and Auto Guidance* technology. Share maps, user data, radar and IP cameras among multiple units using the Garmin Marine Network. NMEA 2000® and NMEA 0183 networking connect you to autopilots, digital switching, weather, media, VHF, AIS and other sensors. Plus, this unit uses ANT® technology to pair with compatible Garmin devices, such as marine watches, transducers, wireless remote controls and more. It also includes built-in Garmin SailAssist™ features, such as laylines, race features, set and drift, wind data and more. Add the free all-in-one ActiveCaptain® app to manage your marine experience from nearly anywhere.

Features:

• Bright, sunlight-readable 12” intuitive touchscreen is easy to use in any environment
• Built-in 1 kW CHIRP traditional and ClearVü scanning sonar (transducers sold separately)
• Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar

• J1939 engine connectivity for easy integration with engines, such as Yamaha, and our exclusive OneHelm™ feature for connecting to third-party devices, such as EmpirBus™ digital switching
• Easily build your marine system — from sonar and autopilots to cameras and multimedia — using NMEA 2000® and NMEA 0183 network connectivity and the Garmin Marine Network

• Preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps with integrated Navionics® data and Auto Guidance* technology
• Built-in Garmin SailAssist™ features, including laylines, race features, set and drift, wind data and more
• Add free all-in-one ActiveCaptain® app to manage your marine experience from nearly anywhere
• Integrated ANT® technology support for use with quatix® marine watches, gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and wireless remote controls

Traditional & Scanning Sonars

Get built-in support for 1 kW CHIRP traditional sonar for superior target separation and ClearVü and SideVü scanning sonars to see up to 1,000’ below and around your boat at 260 kHz (transducer sold separately).

Panoptix™ Sonar Support

Pair with Panoptix or Panoptix LiveScope™ easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time.

Preloaded Mapping

Experience unparalleled coverage and detail with preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps featuring integrated Garmin and Navionics® content and Auto Guidance¹ technology.

Optional BlueChart® g3 Vision® Charts

Upgrade to our reliable premium charts, which add even more industry leading features, such as high-resolution relief shading, to help you on each trip.

Garmin Marine Network

If you have multiple Garmin devices on your boat, you can share information — such as maps, user data, radar and IP cameras — among them.

NMEA 2000® & NMEA0183 Networks

Connect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.

ActiveCaptain® App

Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications², software updates, Garmin Helm, Garmin Quickdraw™ Community data and more.

Integrated ANT® Technology

Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.

JI939 Connectivity

Now you can connect your chartplotter to different kinds of engines, including Yamaha engines.

OneHelm™ Feature

This exclusive feature brings together all the operations and capabilities of third-party devices, such as EmpirBus™ digital switching, on one screen.

In The Box

• GPSMAP 1242xsv Plus chartplotter
• Power cable
• 8-pin transducer to 12-pin sonar adapter cable
• NMEA 2000 T-connector
• NMEA 2000 drop cable (2 m)
• Bail mount kit with knobs
• Flush mount kit with gasket
• Protective cover
• Trim piece snap covers
• Documentation

Connections

• Garmin Marine Network™ Ports: 2
• Transducer Ports: 1 (12 Pin)
• NMEA 2000® Port: 1
• NMEA 0183 Input Ports: 1
• NMEA 0183 Output Ports: 1
• J1939 Port: 1
• Video Input Ports:  1 BNC
• Video Output Ports: 1 HDMI
• Wireless Connectivity: Yes

¹ Auto Guidance is for planning purposes only and does not replace safe navigation operations

² When paired with a compatible smartphone

Wi-Fi is a registered trademark of the Wi-Fi Alliance.

The bright, sun-readable 12-inch intuitive touch screen chartplotter can be easily used in any environment and can be seamlessly integrated into the Garmin navigation system. The Garmin plotter has pre-installed BlueChart g3 coastal chart and LakeVu g3 inland chart. These maps integrate Garmin and Navionics content and automatic navigation technology: if multiple Garmin devices are installed on board, information such as maps, user data, radars and IP cameras can be shared.
SKU: NVN-80822
MPN: 010-02322-03
UPC: 753759240875
