Attwood In-Line Fuel Demand Valve

Attwood's exclusive Fuel Demand Valve ensures pressurized fuel does not reach the engine preventing engine flooding and fuel spillage. New EPA portable fuel tanks are required to remain sealed up to a minimum of 5psi. The Attwood Fuel Demand Valve prevents pressurized fuel from flooding the engine.. The valve provides fuel to the engine only when demanded by the engine during start up or engine operation. Designed in partnership with OEM engine manufacturers the Attwood Fuel Demand Valve is compatible with all OEM Engine brands and helps to ensure proper engine start up and function.

Attwood Marine 9300FDV7 Attributes

• Size: 3/8 Inch Hose Barb x 5/16 Inch Hose Barb
• Numbers Of Ports: 2
• Type: Demand Valve
• Color: Black
• Material: Plastic
• Quantity: Single

Attwood Marine 9300FDV7 Features & Benefits

• Prevents Engine Flooding Due To Pressurized Fuel, Allows Only The Amount Of Fuel Requested By The Engine/ Prevents A Pressurized "Slug" Of Fuel From Reaching Engine
• Prevents Fuel Spray Down Stream From The Fuel Demand Valve
• Made Of High-Strength Composite Material Designed To Withstand Harsh Abuse Of Marine Environment
• Compatible With 3/8 Inch And 5/16 Inch Fuel Hose
• Installs Between The Fuel Tank And The Primer Bulb And OEM Quality And Performance At A Fraction Of The Price
• Low Vacuum Restriction Helps Ensure Proper Engine Function During Startup And Engine Operation
• 20psi Max Nominal Input Pressure And Protected For 40psi Pressure Spike
• Built In Manual Override
• Compatible With Ethanol Blended Fuels And With All OEM Brand Engines
• Limited 2 Year Warranty

Attwood Marine 9300FDV7 Warranties

• Attwood Warranty 2009.pdf

In-Line Fuel Demand Valve

Attwood's exclusive Fuel Demand Valve eliminates engine flooding and spillage by preventing pressurized fuel from reaching the engine. The valve ensures that fuel is supplied to the engine only when demanded during start-up or engine operation. Designed in partnership with OEM engine manufacturers,  Attwood’s Fuel Demand Valve is compatible with all OEM engine brands.

Features:

• Prevents engine flooding and fuel spillage due to pressurized fuel
• Allows only the amount of fuel requested by the engine and prevents a pressurized "slug" of fuel from reaching the engine
• Made of high-strength composite material designed to withstand the harsh marine environment
• Compatible with 3/8" and 5/16" fuel hose
• Installs between the fuel tank and the primer bulb
• Low vacuum restriction helps ensure proper engine function during startup and engine operation (less than 2kPa at 125 liters/hour)
• Built-in manual override
• Compatible with Ethanol blended fuels

Specifications:

• Operating Temperature: -4 degrees F to 176 degrees F / -20 degrees C to 80 degrees C /
• Storage Temperature: -40 degrees F to 176 degrees F / 40 degrees C to 80 degrees C
• Operating Input Pressure: 138 kPa (20 psi) protected for 276 kPa (40 psi) psi pressure spike
• Flow Performance: 125 L/H (33 GPH) at <2 kPa (10" gasoline)
• Hose Size: (inch) 5/16" – 3/8" / (mm) 8 – 10

*Fuel Demand Valve keeps all pressure at the fuel tank when the engine is off

SKU: NVN-98193
MPN: 9300FDV7
UPC:
