Garmin ECHOMAP UHD 64cv US Offshore g3 w/GT24 Transducer
Garmin ECHOMAP UHD 64cv US Offshore g3 w/GT24 Transducer — Product description
Discover Crystal-Clear Waters with Advanced Sonar Imaging
Imagine gliding through offshore waters, spotting fish schools and underwater structures with pinpoint accuracy right from your helm. The ECHOMAP UHD 64cv transforms your boating trips into productive adventures with its Ultra High-Definition ClearVü scanning sonar paired with the GT24 transducer. This setup paints a vivid picture of the seafloor, revealing baitfish, wrecks, and ledges that traditional sonar might blur together. Anglers rave about how the high wide CHIRP traditional sonar separates targets effortlessly, even in murky conditions, helping you drop lines exactly where the action is.
Beyond fishfinding, this combo shines in navigation. Preloaded BlueChart g3 charts blend Garmin's precision with Navionics' depth data, covering U.S. coastal areas with contours that guide you safely through inlets and around hazards. Whether you're chasing tuna offshore or cruising bays, the intuitive interface keeps your focus on the horizon.
Mapping Your Way: Custom Charts and Community Insights
One standout feature is Quickdraw Contours, letting you map uncharted spots in real-time at 1-foot intervals. As you explore, the system logs depth data, creating personalized maps you can save privately or share via the Garmin Connect community. This is a game-changer for repeat trips to productive honey holes—revisit them with confidence, contours and all.
For broader coverage, the integrated Navionics data in BlueChart g3 delivers over 17,000 lakes and coastal zones with exceptional detail. No more guessing depths; zoom in on marinas, buoys, and wrecks with clarity that rivals professional setups.
Seamless Connectivity for a Smarter Boat
Stay wired into your vessel's ecosystem with NMEA 2000 and NMEA 0183 support. Pull in engine vitals, link to autopilots, monitor weather, or even control audio from brands like FUSION—all from one vibrant 6-inch touchscreen. Pair it with a Force trolling motor for waypoint navigation and track following without lifting a finger.
The ActiveCaptain app takes it further. Connect via built-in Wi-Fi for software updates, smart notifications, and OneChart access to swap maps effortlessly. It's like having a marine command center in your pocket, perfect for planning trips onshore.
Rugged Design Built for Real-World Boating
With an IPX7 water rating, this unit laughs off splashes and sprays. The sunlight-readable WVGA display (480 x 800 pixels) stays sharp under the harshest glare, while the quick-release bail mount lets you stow it securely or take it home. At just 1.6 lbs, it's portable yet tough, ideal for smaller consoles or kayaks.
Pro tip: Flush mounting keeps your deck sleek, and the tilt/swivel cradle adjusts for perfect viewing angles during those long days on the water.
Key Specifications at a Glance
| Category | Details |
|---|---|
| Physical Dimensions | 8.6" x 5.1" x 2.6" |
| Display | 6.2" diagonal WVGA, 480 x 800 pixels |
| Sonar Power | 500W RMS / 4,000W peak-to-peak |
| Max Depth | 2,300 ft @ 77 kHz (freshwater) |
| Water Rating | IPX7 |
| Connections | NMEA 2000/0183, Wi-Fi |
| Preloaded Maps | BlueChart g3 coastal |
What's in the Box for Easy Setup
- ECHOMAP UHD 64cv unit with BlueChart g3
- GT24UHD-TM transducer
- Power/data cable
- Tilt/swivel quick-release mount
- Flush mount kit
- Protective cover and hardware
- Documentation
Everything you need arrives ready to install, minimizing downtime and getting you on the water faster.
Frequently Asked Questions
What makes ClearVü sonar different from traditional sonar?
ClearVü provides photo-like down and side imaging for detailed views of structures and fish, while traditional CHIRP sonar excels at target separation across a wider cone, spotting schools deeper and faster.
Can I use this on saltwater offshore trips?
Absolutely—preloaded BlueChart g3 coastal charts with Navionics data are tailored for U.S. offshore and inshore waters, including depth contours and hazards.
Is the screen visible in direct sunlight?
Yes, the 6-inch WVGA display is sunlight-readable, ensuring clear visuals even on bright days at sea.
How does Quickdraw Contours work?
It automatically creates 1-foot contour maps as you fish, which you can customize, save, or share with the Garmin Quickdraw Community for collective insights.
Does it integrate with other boat systems?
Yes, NMEA 2000/0183 compatibility connects to engines, autopilots, AIS, VHF, and even Force trolling motors for full control.
What's the installation like for beginners?
Straightforward with included mounts and cables; transom-mount the GT24 transducer, wire to power, and you're scanning in under an hour.
Can I add LiveScope sonar?
It supports Panoptix LiveScope for real-time forward-facing views, expanding your fishfinding arsenal.
Why Boaters Choose This Combo for Offshore Success
From weekend warriors to serious offshore anglers, this unit delivers pro-level performance without complexity. It spots fish hiding in structure, navigates tricky reefs, and networks your gear—all on a rugged, portable package. Elevate your time on the water with tools that work as hard as you do.
ECHOMAP UHD 64cv US Offshore g3 with GT24 Transducer
Find more fish using the ECHOMAP UHD 64cv combo with a bright, sunlight-readable 6 screen. The optional GT24 included transducer provides Ultra High-Definition ClearV scanning sonar, so you get a crystal-clear image of what is below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. This combo comes preloaded with BlueChart g3 coastal charts with the best of Garmin and Navionics data. It features a quick-release bail mount, making it easy to remove and take with you. NMEA 2000 and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP UHD 64cv is even compatible with the Force trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.
Features:
- Bright, sunlight-readable 6 combo
- Optional GT24 transducer for Ultra High-Definition ClearV scanning sonar and Garmin high wide CHIRP traditional sonar
- Preloaded BlueChart g3 charts with integrated Navionics data for the coastal U.S.
- Supports Panoptix all-seeing sonar, including Panoptix LiveScope sonar
- NMEA 2000 and NMEA 0183 network support for autopilot and engine data
- Quick-release bail mount for fast and easy mobility
- Compatible with Force trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more
Included Transducer
This chartplotter comes with a GT24 transducer for Ultra High-Definition ClearV scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.
Preloaded Mapping
Experience unparalleled coverage and detail with preloaded LakeV g3 inland maps featuring integrated Navionics data that covers more than 17,000 lakes with up to 1' contours.
Quickdraw Contours
Create personalized fishing maps on-screen with 1' contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect.
NMEA 2000 & NMEA0183 Networks
Connect to autopilots, digital switching, weather, FUSION-Link audio system, media, VHF, AIS and more from one screen.
ActiveCaptain App
Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature, smart notifications1, software updates, Garmin Quickdraw Community data and more.
1 When paired with a compatible smartphone
2 In compliance with ISO standard 13342
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
Garmin ECHOMAP 64cv UHD
Combo US Offshore g3 with GT24 Transducer
Model: 010-02331-01- See below your boat in incredible detail with optional transducer
- Navigate any waters with preloaded BlueChart® g3 coastal charts
- Manage your marine experience from nearly anywhere
- Create your own maps on the fly and tailor them to fit your needs
The sunlight-readable 6" touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.
This chartplotter comes with a GT24 transducer for Ultra High-Definition ClearVü scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.
Experience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours.
Create personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™.
Connect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.
Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more.
Specifications| General | |
| Physical dimensions | 8.6" x 5.1" x 2.6" (21.8 x 13.0 x 6.2cm) |
| Display size | 5.4" x 3.1"; 6.2" diagonal (13.7 x 7.7 cm; 15.2 cm diagonal) |
| Display resolution | 480 x 800 pixels |
| Display type | WVGA display |
| Weight | 1.6 lbs (0.7 kg) |
| Water Rating | IPX7 |
| Power consumption | 12W |
| Antenna | Internal or external over NMEA 2000 |
| Mounting options | Bail or flush |
| Receiver | 5 Hz |
| Garmin Marine Network™ ports | None |
| Maps & Memory | |
| Preloaded maps | BlueChart® g3 (coastal maps) |
| Accepts data cards | 1 microSD™ card; 32 GB maximum size |
| Waypoints | 5,000 |
| Routes | 100 |
| Track log | 50,000 points; 50 saved tracks |
| Outdoor Recreation Features | |
| Tide tables | Yes |
| Chartplotter Features | Yes |
| Garmin Sonar compatible | |
| Supports AIS (tracks target ships position) | Yes |
| Supports DSC (displays position data from DSC-capable VHF radio) | Yes |
| ActiveCaptain compatible | Yes |
| Sailing Features | Yes |
| Sonar Features & Specifications | |
| Dual-frequency (50/200 kHz) sonar capable | Yes |
| Dual-beam (77/200 kHz) sonar capable | Yes |
| Transmit power | 500 W (RMS) / 4,000 W (peak to peak) |
| CHIRP sonar technology | Yes (Built-in) |
| ClearVü | Yes with CHIRP (built-in) |
| SideVü | No |
| Maximum depth | 2,300 ft @ 77 kHz, freshwater |
| Bottom lock (shows return from the bottom up) | Yes |
| Water temperature log and graph | Yes |
| Sonar recording | Yes |
| Sonar history rewind | Yes |
| Connections | |
| NMEA 2000® compatible | Yes |
| Transducer pin numbers | 4 |
| NMEA 0183 input ports | 1 |
| NMEA 0183 output ports | 1 |
| Video input ports | None |
| Video output ports | None |
| Wireless connectivity | Yes |
What's in the Box:
- ECHOMAP UHD 64cv with BlueChart g3 for U.S.
- GT24UHD-TM transducer
- Power/data cable
- Tilt/swivel mount with quick release cradle
- Flush mount
- Protective cover
- Hardware
- Documentation
With the ECHOMAP UHD 64cv combination and a bright sun-readable 6-inch screen, you can find more fish. The optional GT24 sensor provides ultra-high-definition ClearVu scanning sonar, so you can clearly see the image of the bottom of the ship, while Garmin CHIRP traditional high sonar CHIRP sonar can achieve excellent target separation. The combination is pre-installed with the BlueChart g3 coastal chart, which contains the best data from Garmin and Navionics. It has a quick-release basket holding device, which can be easily removed and carried with you. NMEA 2000 and NMEA 0183 network support provides you with engine data, sensor connections, autopilot integration, etc. ECHOMAP UHD 64cv is even compatible with the "power drag" motor, which can be fully controlled from the screen, and has functions such as routing to waypoints and tracking routes.
SKU: NVN-80825
MPN: 010-02331-01
UPC: 753759241438
Technical specifications
| Brand | Garmin |
| Model | Garmin ECHOMAP UHD 64cv US Offshore g3 w/GT24 Transducer |
| SKU / MFR# | 80825 |
