Airmar TM265C-LH Transom Mount CHIRP - 1kW Transducer - Requires Mix and Match Cable
Airmar TM265C-LH Transom Mount CHIRP - 1kW Transducer - Requires Mix and Match Cable — Product description
1 kW
We know that specific frequencies excel at detecting certain species of fish: Bluefin Tuna—60 kHz, squid—133 kHz, and cod—175 kHz. The TM265LH transducer includes all these frequencies plus every other frequency in the high and low bandwidths. This powerhouse delivers excellent resolution, bottom discrimination, and bait and game-fish separation at all depths.
Airmar's TM265LH is packed with a seven-element, low-frequency array that operates between 42 and 65 kHz for excellent deep-water performance. The high-frequency ceramic operates between 130 and 210 kHz with a narrow, 10° to 6°, beam—perfect for picking apart structure and pinpointing tight-holding fish in structure.
TM265C-LH Transom Mount CHIRP - 1kW Transducer
Transom-mounted 1kW dual-band CHIRP fishfinder transducer.
The TM265 is available in the Low/Medium and Low/High bands. A Low/High widebeam model exists with the designation TM275.
Specifications:
- Low/High Bands
- 1000 Watts
- Transom Mount
- Housing: Urethane
- Requires Mix and Match Cable for the Sounder its going into
Airmar TM265C low/high CHIRP tail mount sensor with mixed N matching plug Model: TM265C-LH-MM 8 Internal broadband ceramic depth and fast response water temperature sensor...
- Depth and fast-response water-temperature sensing
- 1 kW of power for great deep-water performance
- Low frequency: 42 to 65 kHz
- 25° to 16° port-starboard beamwidth
- Maximum depth of 914 m (3000')
- High frequency: 130 to 210 kHz
- 10° to 6° beamwidth
- Maximum depth of 304 m (1000')
- 103 kHz of total bandwidth from one transducer
- Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth
- Transom mount, stainless steel bracket for installation on boats of all propulsion types
- SEALCAST, seamless, urethane housing for long life in the water
- Also available as cavity/welded-tank (CM265LH), thru-hull (B265LH), in-hull (M265LH), and pocket (PM265LH) mounts
- Patented Xducer ID technology
SKU: NVN-76813
MPN: TM265C-LH-MM
UPC:
Technical specifications
| Brand | Airmar |
| Model | Airmar TM265C-LH Transom Mount CHIRP - 1kW Transducer - Requires Mix and Match Cable |
| SKU / MFR# | 76813 |
