Garmin Panoptix PS22-TR LiveVu Forward & Down Transducer
Garmin Panoptix PS22-TR LiveVu Forward & Down Transducer — Product description
Transform Your Fishing Game with Real-Time Sonar Insights
Imagine spotting fish and underwater structures in crystal-clear, live detail—whether you're drifting silently or holding position over a prime spot. The Garmin Panoptix PS22-TR transducer brings this vision to life, mounting seamlessly on your trolling motor to deliver forward and downward views that feel like having eyes beneath the waves. Anglers who demand precision turn to this trolling motor transducer for its ability to reveal bait movement, fish reactions, and structure in real time, turning guesswork into targeted strikes.
Unlike traditional sonar that only paints a picture of what's already behind you, this unit captures the action as it unfolds. Point your trolling motor and watch the water come alive on your compatible Garmin display, helping you drop lures exactly where they need to be and react instantly to subtle fish behaviors.
Standout Features for Serious Anglers
- Dual LiveV Modes: Switch effortlessly between forward scanning to scout ahead and downward views for jigging or vertical presentations, all from one compact unit.
- Pinpoint Resolution: A focused 20-degree narrow beam slices through clutter for sharper images of fish, bait, and bottom contours up to 300 feet away.
- Trolling Motor Ready: Designed for shaft or barrel mounting, with a simple one-screw system that lets you flip modes without tools or hassle.
- Stationary or Moving: No need to troll endlessly—get live updates whether idling over structure or cruising structure lines.
- Integrated Sensing: Tracks depth and water temperature alongside stunning visuals, giving you the full environmental picture.
How LiveV Forward and Down Modes Elevate Your Approach
LiveV Forward: Peer up to 300 feet ahead and to the sides, mapping ledges, drop-offs, and cruising fish schools before you reach them. Ideal for running main lake points or following contours in current.
LiveV Down: Drop your view straight below for spotting suspended fish, watching your jig flutter, or monitoring how walleye or crappie respond to your presentation. Perfect for lock-down scenarios where every inch matters.
The magic lies in the real-time refresh—see your spoon sinking, a bass turning toward it, or the hookset pull in vivid detail. This isn't delayed history; it's the present moment, empowering split-second decisions that land more fish in the livewell.
Quick Setup for More Time on the Water
Mounting is straightforward: Choose the shaft clamp for slimmer profiles or the barrel mount for broader motors. Secure with a single screw, route the integrated Ethernet and power cables (both 13 feet long), and connect to your Garmin networking system. No drilling, no fuss—transition from forward to down in seconds. Pro tip: Position it just above the prop for optimal water flow and minimal cavitation interference, ensuring clean signals even in rough conditions.
Real Angler Wins: Scenarios Where It Shines
In deep water bass tournaments, use Forward mode to hug breaklines and id Down to pitch jigs into isolated cover. Musky hunters love watching followers trail big paddletails from afar. For panfish or crappie vertical jigging, the Down view tracks minnow imitations fluttering through the water column, revealing bites before you feel them.
Users rave about its edge in low-light or stained water, where the narrow beam cuts through murk for reliable targets. Maintenance is simple—rinse after saltwater trips and store dry to keep performance peak.
Detailed Specifications at a Glance
| Specification | Details |
|---|---|
| Frequency | 417 kHz |
| Power Output | 48 watts |
| Beamwidth (LiveV) | 20° x 100° |
| Maximum Depth | 300 ft (Down); 300 ft (Forward) |
| Sensors | Depth and Temperature |
| Connection | Ethernet |
| Cable Length | Power: 13 ft; Ethernet: 13 ft |
| Mounting Options | Trolling motor shaft or barrel |
Everything You Need to Get Started
- PS22-TR transducer with integrated 13-foot power and Ethernet cables
- Trolling motor shaft mount
- Trolling motor barrel mount
- Comprehensive documentation
Frequently Asked Questions
Panoptix PS22-TR LiveV Forward & Down Transducer
Trolling Motor Transducer with 2 Panoptix LiveV Modes
- LiveV Forward sonar shows the structure and fish ahead and around your boat
- LiveV Down sonar shows below and around your boat for vertical fishing and jigging
- Narrow beam angle (20 degrees) for crisp, improved resolution and clear images
- Mounts to the shaft or motor barrel of a trolling motor
- One-screw mount design makes it easy to change modes
Garmin is the first to bring 2 modes of Panoptix sonar imaging to 1 transducer for your boat. Panoptix all-seeing sonar is unlike anything you've ever seen on the water. It gives you the ability to see all around your boat and below it - in real time - up to 100' away.
It's Not Just Sonar It's Panoptix Sonar
Panoptix delivers a whole new perspective to fishing. Other sonar only shows images of fish your transducer has passed over. To capture those images, your boat must be moving. Everything that shows up on your screen is technically history; it's all in the past. With Panoptix LiveV Forward and LiveV Down sonars, your boat can be moving or stationary. Wherever your trolling motor is pointed, you'll see live images of what is happening under the water.
Fishing Comes Alive with Panoptix
Watch your lure as it sinks, and see its depth and movement as you retrieve it. See it move in relation to structure in the water. See fish swimming and reacting to your bait. If they attack, you'll see and feel the hit! Once on the hook, watch the fight on your screen as it happens. With Panoptix LiveV Forward and LiveV Down, you can see it all come to life up to 100' away or below your boat.
In the Box:
- Panoptix PS22-TR transducer with integrated 4 meter network and power cable
- Trolling motor shaft mount
- Trolling motor barrel mount
- Documentation
Specifications:
- Frequency: 417 kHz
- Power: 48W
- Beamwidth: LiveV: 20°x100°
- Maximum depth: 300' Down; 300' Forward
- Depth/Speed/Temperature: Depth and Temperature
- Number of pins: Ethernet
- Cable length: Power Cable 13'; Ethernet Cable 13'
- Supported deadrise/Transom angles: Trolling motor shaft. or Barrel mount
Garmin Panoptix PS22-TR Transducer
Model: 010-01945-00- LiveVü Forward sonar shows the structure and fish ahead and around your boat
- LiveVü Down sonar shows below and around your boat for vertical fishing and jigging
- Narrow beam angle (20 degrees) for crisp, improved resolution and clear images
- Mounts to the shaft or motor barrel of a trolling motor
- One-screw mount design makes it easy to change modes
Garmin is the first to bring 2 modes of Panoptix sonar imaging to 1 transducer for your boat. Panoptix all-seeing sonar is unlike anything you’ve ever seen on the water. It gives you the ability to see all around your boat and below it — in real time — up to 100’ away.
Panoptix delivers a whole new perspective to fishing. Other sonar only shows images of fish your transducer has passed over. To capture those images, your boat must be moving. Everything that shows up on your screen is technically history; it’s all in the past. With Panoptix LiveVü Forward and LiveVü Down sonars, your boat can be moving or stationary. Wherever your trolling motor is pointed, you’ll see live images of what is happening under the water.
Watch your lure as it sinks, and see its depth and movement as you retrieve it. See it move in relation to structure in the water. See fish swimming and reacting to your bait. If they attack, you’ll see and feel the hit! Once on the hook, watch the fight on your screen as it happens. With Panoptix LiveVü Forward and LiveVü Down, you can see it all come to life up to 100’ away or below your boat.
Specifications| Frequency | 417 kHz |
| Power | 48 watts |
| Beamwidth | LiveVü: 20°x100° |
| Maximum depth | 300 ft. Down; 300 ft. Forward |
| Depth/Speed/Temperature | Depth and Temperature |
| Number of pins | Ethernet |
| Cable length | Power Cable 13 ft.; Ethernet Cable 13 ft. |
| Mount Type | Trolling motor shaft. or Barrel mount |
What's in the Box:
- Panoptix PS22-TR transducer with integrated 4 meter network and power cable
- Trolling motor shaft mount
- Trolling motor barrel mount
- Documentation
Towed motor Panoptix sensor for LiveVu images! The Panoptix PS22-TR towed motor sensor is the first of its kind to provide two Panoptix sonar imaging modes in one sensor. Panoptix's WYSIWYG sonar function is unmatched by other sonars, especially to observe the bottom and front of the ship in real time, up to 100 feet. Leave once. Garmin's PS22-TR has a perfect single-screw installation design, which can easily realize the transition from forward scanning sonar to downward scanning sonar. The narrow beam angle of 20 degrees always provides clearer and enhanced images to always improve the resolution below and in front of you to help you land the next big fish. Easily describe the bait when the bait is put down, watch the fish react to the bait, and observe the start of the battle. Not only will you feel the blow online, you will also see it. For the new vision of fishing, the Garmin Panoptix PS22TR transducer shines a new light on the road to the next generation of sonar! This product is not compatible with Xi5 traction motors. Compare all Panoptix models!
SKU: NVN-66839
MPN: 010-01945-00
UPC: 753759189570
Technical specifications
| Brand | Garmin |
| Model | Garmin Panoptix PS22-TR LiveVu Forward & Down Transducer |
| SKU / MFR# | 66839 |
