Garmin ECHOMAP Ultra 2 102sv LIVESCOPE Plus Bundle Worldwide Basemap No Transduce
Garmin ECHOMAP Ultra 2 102sv LIVESCOPE Plus Bundle Worldwide Basemap No Transduce — Product description
Imagine spotting fish in real-time with crystal-clear forward-facing sonar, all from a vibrant 10-inch touchscreen that dominates your boat's helm. The Garmin ECHOMAP Ultra 2 102sv paired with LiveScope Plus delivers that edge for serious anglers chasing trophy bass or navigating tricky coastal waters. This bundle skips the transducer so you can pair it with your preferred setup, unlocking unparalleled live-scanning power alongside built-in CHIRP sonar and high-definition scanning. Whether you're drifting live bait over structure or trolling deep for walleye, this system turns guesswork into precision strikes.
Standout Features That Elevate Your Fishing Game
- Sunlight-Readable Brilliance: A 10-inch WXGA IPS display (1280 x 800 pixels) with keyed touchscreen assist ensures quick adjustments even in harsh glare, while IPX7 waterproofing laughs off splashes and spray.
- LiveScope Ready: Seamlessly integrates with LiveScope sonar systems for real-time views of fish reactions—watch bait drop and hooks set without looking away from the screen.
- Wireless Sharing Magic: Connect multiple ECHOMAP Ultra 2 units on your boat to share sonar data, waypoints, and routes instantly, perfect for tournament teams or family outings.
- Capture the Action: Record sonar screens to relive big catches or analyze patterns later, sharing clips via compatible apps for bragging rights on the dock.
- Multi-Band GPS Precision: Tracks with GPS, GLONASS, Galileo, and BeiDou for pinpoint accuracy, even under heavy tree cover or in crowded marinas.
Unmatched Sonar Capabilities for Deeper Insights
Built-in sonar isn't just an add-on—it's a powerhouse. Dual-frequency CHIRP (70/83/200 kHz, L/M/H bands) cuts through thermoclines to reveal bait schools and bottom huggers. Pair it with ClearVü and SideVü scanning at multiple frequencies (260/455/800/1000/1200 kHz) for photo-like images of wrecks, drop-offs, and submerged timber. The 600-watt output handles depths up to 800 feet traditional or 200 feet scanning, with vivid color palettes that make targets pop against structure.
LiveScope Plus takes it further with enhanced clarity and reduced clutter, ideal for finesse fishing in shallow bays or ice fishing setups. Forward, down, or perspective views let you see fish evade lures or school up on your jig—real-time intel that hooks more fish.
Rugged Design Built for the Water
| Category | Details |
|---|---|
| General | |
| Dimensions | 11.6" x 7.7" x 3.9" (29.5 x 19.5 x 9.8 cm) |
| Weight | 4.0 lbs (1.8 kg) |
| Waterproof Rating | IPX7 |
| Display | 10" diagonal WXGA IPS, 1280 x 800 pixels |
| Memory & Navigation | |
| Waypoints / Tracks / Routes | 5,000 / 50,000 points in 50 tracks / 100 |
| Connections | |
| Ports | 1 NMEA 2000, 2 Garmin Marine Network, 1 12-pin sonar, ANT+, Wi-Fi |
| Power | |
| Input | 9-18 Vdc, Max 34W at 10V |
Complete Bundle Contents
- ECHOMAP Ultra 102sv chartplotter
- LiveScope Plus system
- Power/data cable
- Bail mount with quick-release cradle and flush mount option
- Protective sun cover
- 8-pin to 12-pin transducer adapter
- Mounting hardware
- Documentation
Everything you need to mount and power up—add your transducer and hit the water.
Real-World Wins from Fellow Anglers
In bass tournaments, this setup shines by revealing suspended fish over humps others miss. Offshore, SideVü scans wrecks for snapper holds. Kayak anglers love the compact bail mount and wireless sharing to a second screen. Customize palettes for low-light dawn patrols, and the multi-constellation GPS keeps you locked on even in slot canyons.
Frequently Asked Questions
Does this bundle include a transducer?
No, this is a no-transducer bundle, allowing you to select the LiveScope or other sonar transducer that best fits your boat and fishing style.
Can I share sonar data between multiple units?
Yes, wirelessly share sonar, waypoints, and routes with other compatible ECHOMAP Ultra 2 or UHD2 units on your boat via one-to-one connections.
What mapping options are supported?
It comes with a worldwide basemap and supports Garmin Navionics+, Vision+, BlueChart, LakeVü, and more via microSD cards for detailed inland, coastal, or topo charts.
Is the display suitable for bright sunlight?
Absolutely—the 10-inch IPS touchscreen is sunlight-readable with high contrast, and keyed assist ensures reliable operation in all conditions.
What sonar types does it support?
Built-in CHIRP traditional, ClearVü, SideVü scanning, plus full compatibility with Panoptix and LiveScope systems for comprehensive coverage.
How accurate is the GPS?
Multi-band, multi-constellation GPS (GPS, GLONASS, Galileo, BeiDou) at 10 Hz provides superior position accuracy, even in challenging environments.
Can I record sonar screens?
Yes, capture screen recordings directly to review fish behavior or share exciting moments with others.
Garmin ECHOMAP™ Ultra 2 102sv 10"" Chartplotters LiveScope Plus Bundle without Transducer
Model: 010-02879-00/LIVESCOPE- SUPPORTS LIVESCOPE™ SONAR1 AND MORE
- WIRELESSLY NETWORK; SHARE SONAR, WAYPOINTS AND ROUTES2
- CAPTURE SCREEN RECORDINGS TO SHARE FISH CATCHES
- MULTI-BAND GPS FOR IMPROVED POSITION ACCURACY
With big, crisp, sunlight-readable touchscreen displays, these versatile chartplotters put a world of fishfinding capability at your fingertips. They’re available with built-in Garmin Navionics+™ mapping, and the transducer bundle adds Ultra High-Definition scanning sonars as well as CHIRP traditional sonar.
The ECHOMAP Ultra 2 series supports the full lineup of LiveScope live-scanning sonar products (transducers sold separately).
High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.
Bring a fresh new look and feel to your chartplotter with optional Garmin Navionics Vision+™ premium mapping (sold separately), featuring high-resolution relief shading, satellite imagery and more.
If you have another compatible ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotter on your boat, you can wirelessly share information — such as sonar3, waypoints and routes — with them.
1LiveScope™ System sonar transducer sold separately 2Via one-to-one unit wireless connection only 3LiveScope sonar cannot be shared wirelessly between two ECHOMAP Ultra 2 or ECHOMAP UHD2 chartplotters 4Requires the ActiveCaptain app on your compatible smartphone paired to your ECHOMAP Ultra 2 series chartplotter
Specifications| General | |
| DIMENSION | 11.6"" x 7.7"" x 3.9"" (29.5 x 19.5 x 9.8 cm) |
| WEIGHT | 4.0 lbs (1.8 kg) |
| WATERPROOF | IPX7 |
| TOUCHSCREEN | Yes |
| DISPLAY TYPE | WXGA, IPS |
| DISPLAY SIZE | 8.5"" x 5.4""; 10"" diagonal (21.7 x 13.6 cm; 25.4 cm diagonal) |
| DISPLAY RESOLUTION | 1280 x 800 pixels |
| MOUNTING OPTIONS | Bail or flush |
| INPUT | Touchscreen with Keyed Assist |
| Maps & Memory | |
| ACCEPTS DATA CARDS | 2 microSD cards |
| WAYPOINTS | 5000 |
| TRACK POINTS | 50,000 |
| TRACKS | 50 saved tracks |
| NAVIGATION ROUTES | 100 |
| Sensors | |
| GPS | Yes |
| GLONASS | Yes |
| GALILEO | Yes |
| BEIDOU | Yes |
| HAS BUILT-IN RECEIVER | Yes |
| RECEIVER | 10 Hz |
| NMEA 2000 COMPATIBLE | Yes |
| NMEA 0183 COMPATIBLE | Yes |
| SUPPORTS WAAS | Yes |
| SUPPORTS MULTI-BAND, MULTI-CONSTELLATION GPS | Yes |
| Built-in Maps | |
| BUILT-IN AUTO GUIDANCE+ | Yes |
| GARMIN NAVIONICS+ INLAND & COASTAL | No |
| TIDE TABLES | No |
| Optional Map Support | |
| BLUECHART G3 | Yes |
| BLUECHART G3 VISION | Yes |
| LAKEVü G3 | Yes |
| LAKEVü G3 ULTRA | Yes |
| GARMIN NAVIONICS+™ | Yes |
| GARMIN NAVIONICS VISION+™ | Yes |
| TOPO 100K | Yes |
| STANDARD MAPPING | Yes |
| GARMIN QUICKDRAW CONTOURS | Yes |
| Electrical Features | |
| POWER INPUT | 9 to 18 Vdc |
| TYPICAL CURRENT DRAW AT 12 VDC | 2.3 A |
| MAXIMUM CURRENT DRAW AT 12 VDC | 5.0 A |
| MAXIMUM POWER USAGE AT 10 VDC | 34 W |
| Connections | |
| NMEA 2000® PORTS | 1 |
| GARMIN MARINE NETWORK PORTS | 2 (large connector) |
| 12-PIN TRANSDUCER PORTS | 12-pin scanning sonar |
| ANT+ (CONNECTIVITY) | Yes |
| GARMIN WI-FI NETWORK (LOCAL CONNECTION) | Yes |
| Sonar Features | |
| DISPLAYS SONAR | Yes |
| POWER OUTPUT | 600 watt |
| TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) | built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) |
| CLEARVü | built-in 260/455/800/1000/1200 kHz |
| SIDEVü | built-in 260/455/800/1000/1200 kHz |
| PANOPTIX™ SONAR | Yes |
| LIVESCOPE | Yes |
What's in the Box:
- ECHOMAP Ultra 102sv
- Power/data cable
- Bail mount with quick release cradle
- Protective sun cover
- 8-pin transducer to 12-pin sounder adapter cable
- Hardware
- Documentation
- LIVESCOPE Plus
SKU: NVN-1003647
MPN: 010-02879-00/LIVESCOPE
