Airmar B175C-12-L Thru Hull 12 Deg Tilt
Airmar B175C-12-L Thru Hull 12 Deg Tilt — Product description
1 kW
Airmar's low-profile, Chirp-ready, transducers are the perfect addition to smaller boats such as center consoles. The B175L transmits across low-frequencies from 40 to 60 kHz, delivering excellent coverage and tracking. This transducer has up to 20 kHz of total bandwidth in just one installation for tremendous deep-water performance.
Tilted Element transducers have the ceramic element fixed at a 20°, 12°, or 0° angle within the housing. When the transducer is installed almost flush to the hull, the tilt of the element corrects for the hull deadrise, orienting the beam directly down. This ensures maximum echo returns to the transducer for more accurate depth readings.
The B175L is available in three Tilted Element models:
- Fixed 20° tilted version for 16 to 24° hull deadrise angles
- Fixed 12° tilted version for 8 to 15° hull deadrise angles
- Fixed 0° tilted version for 0 to 7° hull deadrise angles
Rely on Airmar's new broadband transducers for your ultimate fishing mission. Whether you're a commercial fisherman, charter captain, or tournament angler, there's a new game in town! CHIRP transducers enable bottom detection down to 3,000m (10,000') with 5 to 10 times greater detail and resolution so precise it's possible to distinguish between individual baitfish, game fish, and underwater structures. One transducer delivers up to 80 kHz of total bandwidth in just one installation, saving customers time and money.
A tilted element model in the CHIRP Thru-Hull product line, the B175 L/M/H CHIRPS across the following bandwidths:
L Model - Low Frequency 40-60 kHz
M Model - Medium Frequency 85-135 kHz
H Model - High Frequency 130-210 kHz
The B175 is available in 0 , 12 , and 20 tilted versions.
- Depth and fast-response water-temperature sensing
- 1 kW of power for great deep-water performance
- Low frequency: 40 to 60 kHz
- 32° to 21° beamwidth
- Maximum depth of 762 m (2500')
- Low-profile, thru-hull housing provides good display resolution at speed when installed properly
- Recommended for stepped, planing, or displacement hull
- Bronze housing for use in a fiberglass or wood hull
- Also available in a stainless steel housing (SS175L) for use with all hull materials
- Patented Xducer ID technology
SKU: NVN-1002428
MPN: B175C-12-L
UPC:
Technical specifications
| Brand | Airmar |
| Model | Airmar B175C-12-L Thru Hull 12 Deg Tilt |
| SKU / MFR# | 1002428 |
