Blue Sea 7047 187 - Series Thermal Circuit Breaker - 135Amp

187-Series Thermal circuit breakers provide heavy duty circuit protection for 135 Amp loads when switching and circuit protection are both required.

Blue Sea 7047BSS Attributes

• Ampere Rating: 135 Amp
• Voltage Rating: 48 Volt
• Reset Type: Manual And Switchable
• Terminal Connection: Stud
• Type: Thermal
• Quantity: Single
• Estimated Install Time (Hours): 0.25

Blue Sea 7047BSS Features & Benefits

• Combines Switching And Circuit Protection Into A Single Device
• Clear, Single Lever Operation
• "Trip Free" Design Cannot Be Held "On" During Fault Current Condition
• Features Waterproof Circuit Breaker
• Recessed Mounting Holes For Clean Appearance
• Large Clearance Around Terminal Studs Accept Heavy Gauge Wire Lugs
• Robust 5/16 M8 Terminals Provide High Torque Connections
• Large Lever With Vertical/Horizontal Orientation Provides Indication Of Trip Status
• Ignition Protected: Safe For Installation Aboard Gasoline Powered Boats
• No Supplier Warranty

187 - Series Thermal Circuit Breakers - Panel Mount

135 Amp Circuit Breaker

PN:  7047

Features:

• Combines switching and circuit protection into a single device

• All components meet SAE J1171 external ignition protection requirements

• Clear, single lever operation

• "Trip Free" design cannot be held "ON" during fault current condition

• Waterproof

• Recessed mounting holes for clean appearance

• Self-trimming case eliminates the need for mounting panels or trim bezels

• Round case permits easy installation with standard sized hole saw

• Large clearance around terminal studs accept heavy gauge wire lugs

• Robust 5/16 terminals provide high torque connections

• Large lever with vertical/horizontal orientation provides indication of trip status

• Ignition protected - safe for installation aboard gasoline powered boats

Specifications
Circuit Breaker Class:	Type III - Switchable / Manual Reset - Trip Free
Type:	Thermally Responsive Bi-Metal Blade
Case Material:	Thermoset Polyester
Voltage Rating:	48 Volts DC Maximum
Interrupt Rating:	5,000 Amperes @12 Volts DC
	3,000 Amperes @24 Volts DC
	1,500 Amperes @42 Volts DC
Operating Temperature Range:	-25C° to +82C°

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

"SwitchWhat can be more fun and rewarding than boating on the open waters? This is an excellent solution for your boating needs. This product is great for use in all marine applications. It will satisfy the needs of both pleasure boat enthusiasts and ambitious yacht owners. Get this excellent product for your vessel and prepare to embark on a thrilling adventure."
SKU: NVN-20532
MPN: 7047
UPC: 632085070472
