Blue Sea 7144BSS Circuit Breaker

Thermal circuit breakers provide heavy duty circuit protection for 25 to 200 Amp loads when switching and circuit protection are both required.

Blue Sea 7144BSS Attributes

• Ampere Rating: 100 Amp
• Voltage Rating: 48 Volt
• Reset Type: Manual And Switchable
• Terminal Connection: Stud
• Type: Thermal
• Quantity: Single
• Estimated Install Time (Hours): 0.25

Blue Sea 7144BSS Features & Benefits

• Clear, Single Lever Operation
• Combines Switching And Circuit Protection Into A Single Device
• Trip Free Design Cannot Be Held "ON" During Fault Current Condition
• Waterproof
• Recessed Mounting Holes For Clean Appearance
• Large Clearance Around Terminal Studs Accept Heavy Gauge Wire Lugs
• Robust 5/16 M8 Terminals Provide High Torque Connections
• Large Lever With Vertical And Horizontal Orientation Provides Indication Of Trip Status
• Ignition Protected - Safe For Installation Aboard Gasoline Powered Boats: Meets SAE J1171 External Ignition Protection Requirements
• No Supplier Warranty

SKU: NVN-2005732
MPN: 7144-BSS
UPC: 632085071448
