Blue Sea 7147 - 187-Series 135 Amp Circuit Breaker Surface Mount

187-Series Thermal circuit breakers provide heavy duty circuit protection for 135 Amp loads when switching and circuit protection are both required.

Blue Sea 7147BSS Attributes

• Ampere Rating: 135 Amp
• Voltage Rating: 48 Volt
• Reset Type: Manual And Switchable
• Terminal Connection: Stud
• Type: Thermal
• Quantity: Single
• Estimated Install Time (Hours): 0.25

Blue Sea 7147BSS Features & Benefits

• Combines Switching And Circuit Protection Into A Single Device
• Clear, Single Lever Operation
• "Trip Free" Design Cannot Be Held "On" During Fault Current Condition
• Features Waterproof Circuit Breaker
• Recessed Mounting Holes For Clean Appearance
• Large Clearance Around Terminal Studs Accept Heavy Gauge Wire Lugs
• Robust 5/16 M8 Terminals Provide High Torque Connections
• Large Lever With Vertical/Horizontal Orientation Provides Indication Of Trip Status
• Ignition Protected: Safe For Installation Aboard Gasoline Powered Boats
• No Supplier Warranty

Blue Sea Systems 187-Series Circuit Breaker - Surface Mount 135A

Model: 7147-BSS

• Combines switching and circuit protection into a single device*
• Clear, single lever operation
• "Trip Free" design cannot be held "ON" during fault current condition
• Waterproof
• Recessed mounting holes for clean appearance
• Large Clearance around terminal studs accept heavy gauge wire lugs
• Robust 5/16 M8 terminals provide high torque connections
• Large lever with vertical/horizontal orientation provides indication of trip status
• Ignition protected - Safe for installation aboard gasoline powered boats
• Meets SAE J1171 external ignition protection requirements

* Do not use as a switch where high inrush currents are expected.

Specifications

Amperage	135A
Maximum Voltage	48vDC
Mounting	Surface Mount
Circuit Breaker Type	Thermally responsive Bi-metal blade
Terminal Stud Torque	75 in-lb (8.47 Nm)
Interrupt Capacity	5000A @ 12V 3000A @ 24V 1500A @ 42V
Minimum Operating Temperature	-40° C
Maximum Operating Temperature	85° C
Case Material	Thermoset Polyester
Circuit Breaker Class	Type III - switchable/manual reset - trip free
Mounting Hole	Accept #10 (M5) Screw
Terminal Stud Size	5/16" - 18

Do not use it as a switch in anticipation of high inrush current. What is more interesting and meaningful than boating in open water? This is your ideal solution.
SKU: NVN-1001833
MPN: 7147
UPC: 632085071479
