Blue Sea 4352BSS Power Distribution Box

Blue Sea Systems designs and manufactures AC and DC electrical products engineered to withstand the demanding applications in Marine and Specialized Vehicle electrical systems.

Blue Sea 4352BSS Attributes

• Voltage Rating: 12 Volt
• Power Rating: 45 Amp
• Receptacle Type: No Receptacle
• Number Of Connections: 6
• GFCI/ Overload Protection: No
• Length (IN): 4-1/2 Inch
• Width (IN): 1-3/4 Inch
• Height (IN): 6-1/2 Inch
• Color: Black
• Material: Polycarbonate/ ABS
• UL Listed: No
• With Flip Cover: No

Blue Sea 4352BSS Features & Benefits

• Two-Wire Connection For Powering All Panels Is Simple And Requires #10 Ring Terminals. Terminals Screw To Bus Bars For Secure Connections
• Quick Connect Bus Eliminates Wire Harness And Clutter Contributing To A Low-Profile Panel
• Polycarbonate And ABS Panel Surface Is UV-Stabilized, Flame Retardant, And Will Not Corrode
• Illuminated On Indication
• Red “On” Indicating LEDs For Safe Operation In Low Light Conditions
• 6 Carling Technologies™ 15 Ampere Circuit Breakers
• Fast-On Circuit Breaker Connectors Make It Quick To Wire
• Low Profile Makes It Easy To Install In Tight Spaces
• Molded Panel Frame Will Stand Up To UV And Salt Air
• No Supplier Warranty

Blue Sea 4352BSS Installation Instructions

• 980007430.pdf

Blue Sea 4352BSS Technical Bulletins

• 4352.pdf

SKU: NVN-2005921
MPN: 4352-BSS
UPC: 632085043520
