Airmar CM599C-LHW Chirp Wide Broadband - No Connector - Bare Wires
Airmar CM599C-LHW Chirp Wide Broadband - No Connector - Bare Wires — Product description
Get more coverage under your boat with Airmar's unique wide-beam, high-frequency, Chirp-ready transducer. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high-frequency band results in superior resolution. The constantly wide beam provides twice the coverage and excellent fish arches on the display compared to most high-frequency, narrow-beam transducer options.
The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat is essential down to 152 m (500').
The low-frequency band is rated to 3 kW and produces amazing deep-water performance to 3,048 m (10,000'). Get the best of both worlds with Airmar's dual-frequency, Chirp-ready transducer with wide-beam coverage.
CM599C-LHW Chirp Wide Broadband - No Connector - Bare Wires
Features:
- Pocket/Keel mount wide-beam model with 3000W power rating
- Depth and fast-response water temperature sensor
- Wide-beam model with 25° constant beamwidth in High band and 9°-23° beamwidth in Low band
- With Low (28-60kHz) and High (150-250kHz) frequency bands
CM599C-LHW Linear Frequency Modulation Broadband-No Connector-Bare Wire Function: Pocket/keel installation of rated power 3000W wide beam model depth and fast response water temperature sensor wide beam model, the beam width is constant at 25°, in the high frequency...
- Depth and fast-response water-temperature sensor
- 3 kW for superior deep-water performance
- 3 kW low frequency: 28 to 60 kHz
- 23° to 9° port-starboard beamwidth
- 11° to 5° fore-aft beamwidth
- Maximum depth performance to 3,048 m (10,000')
- 1 kW high frequency: 150 to 250 kHz
- 25° constant beamwidth
- Maximum depth of 152 m (500')
- 132 kHz of total bandwidth from one transducer
- Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth
- High frequency delivers superior shallow-water performance, bottom detail, and fish-target separation
- High wide beamwidth yields more coverage for detecting fish in the upper-water column
- Urethane housing with Curved-edge Design for wet-box installation
- Also available as an external (R509LHW) mount
- Exclusive Xducer ID technology
SKU: NVN-71189
MPN: CM599C-LHW
UPC: 801769001983
